HOW TO ADJUST THE AUGER CONTROL
CABLE
The auger control is adjusted at the factory. During
normal use, the auger control cable can become
stretched and the auger drive lever will not pro-
perly engage or disengage the auger.
1. (Figure 6) Remove the "Z" hook (1) from the
auger drive lever (2).
2
1
2. (Figure 7)
cable adjustment bracket (2).
3. Push the bottom of the auger control cable (3)
through the cable adjustment bracket (2) until
the "Z" hook (6) can be removed.
4. Remove the "Z" hook (4) from the cable adjust-
ment bracket (2). Move the "Z" hook (4) down to
the next adjustment hole.
5. Pull the auger control cable (3) up through the
cable adjustment bracket (2).
6. Put the cable boot (1) over the cable adjustment
bracket (2).
MAINTENANCE
Figure 6
HOW TO REMOVE THE BELT COVER
1. (Figure 8) If equipped, remove the heat shield (1)
2. Remove the four bolts and nuts (3) holding
3. Remove the one screw (4) holding the belt
4. To remove, hold the bottom portion of the
5. To install the belt cover (2), reverse the above
20
7. (Figure 6) Install the "Z" hook (1) to the
auger drive lever (2).
8. To check the adjustment, start the snowthrower.
Make sure the auger does not rotate when the
auger drive is released.
1
2
from the rear of the belt cover (2).
the belt cover (2) to the auger housing.
cover (2) to the bottom cover (5).
belt cover (2) and pull down and out.
steps.
3
4
2
Figure 7
