Summary of Contents for ROHS SM812CH-MV3(T)
- Page 1 Digital Indoor Monitor Installation and Operation Guide SM385CH-MV3(T) SM385CH-MV3 SM812CH-MV3(T) SM812CH-MV3 SM328CH-MV3(T) SM328CH-MV3 2013-V01...
-
Page 2: Table Of Contents
SM328/812CH indoor monitor operation guide..30-49 CONTENTS System startup............30 Main menu interface..........31 System setting............32 User setting...............36 Plan of indoor monitor............1 Intercom..............38 Technical parameters............4 Call the guard station..........38 Basic functions..............5 Call the other apartment.........39 Installation of indoor monitor...........6 Intercom within the same apartment......39 Connection for indoor monitor.........7 Call transfer............40 SM385CH indoor monitor operation guide....9-29... - Page 3 SM385CH-MV3/MV3(T) SM812CH-MV3/MV3(T) 4" screen 7" screen Dimension: 230x152x21mm Dimension: 222x170x30mm...
-
Page 4: Technical Parameters
SM328CH-MV3/MV3(T) Function Function Power on/off return key screen Call management centre 7" screen Unlock door/Monitor Indicator light of power Talk Indicator light of network numeric key delete key Indicator light of message confirm Speaker Volume adjustment Down ringtone adjustment call lift Mounting bracket hole Technical parameters Voltage: DC 12V 10%... -
Page 5: Basic Functions
Installation of indoor monitor Basic functions 1.Locate the bracket on the installation place, keep it horizontal and mark the drilling positions; Colour LCD touch screen(SM385CH is button operation); 2.Drill holes according to the marked drilling positions and pad Eight section alarms with password arm/disarm; with screw anchors;... - Page 6 Connection for SM328/812CH Connection for SM385CH Network cable White video for second Doorbell confirmed White Black Doorbell Black Power Black Black second confirmed outdoor station Brown Blue Notice: The ports in the dashed line box exist only in the indoor Notice: The ports in the dashed line box exist only in the indoor monitor with (T) in the back of the model number.
-
Page 7: Sm385Ch Indoor Monitor Operation Guide
SM385CH indoor monitor operation guide System setting In the main menu, press number 6 to choose the 6th option. Press System startup the number again to confirm the selection. Picture 1-3 the system password interface pops up. Enter the correct system password Before turn on the power, make sure the indoor monitor is (factory default password is 0000. - Page 8 in the blanks. Press * to delete. Press # to confirm. Press 2.Equipment address setting to return. In picture 1-4, press number 2 to choose the second option. Press number 2 again to confirm the selection. Picture 1-6 will show. Press to move from upper to lower frame and fill in the blanks.
- Page 9 4.System password modification In picture 1-4, press number 4 to choose the second option. Notice Press number 4 again to confirm the selection. Picture 1-8 In the same network, the MAC address and IP address will show. can not be the same in any equipment (including Enter the correct 4-digit password, then the cursor will move outdoor station, indoor monitor and slave indoor to the lower blank NEW PASSWORD.
-
Page 10: User Setting
User setting off and the status icon will be shown in the upper right corner of the main interface. When the outdoor station calls the In picture 1-2, press number 5to choose the option. Press number indoor monitor, the indoor monitor will not ring. 5 again to confirm the selection. -
Page 11: Intercom
Intercom 2.Call the other apartment In picture 1-2 the main menu interface, press number 1 to choose Users in the same network can call each other. In picture 1-12, the option. Press number 1 again to confirm the selection. Picture enter the series number of the apartment: building number, 1-12 will show. -
Page 12: Call Transfer
5.Call the indoor monitor Notice When indoor monitor is called by other equipments, indoor When user calls all the indoor monitors, all indoor monitor will ring. Press to pick up the call. Press monitors ring in the same time. When one of the to end the call. -
Page 13: Monitor/Unlock
Monitor/unlock In picture 1-2 the main menu interface, press number 2 to choose Notice the option. Press number 2 again to confirm the selection. Picture A. The maximum monitor time is 30 seconds. After 30 1-13 will show the view from outdoor station 1. seconds, the indoor monitor will hang up automatically. -
Page 14: Home Security
Home security 1.Set defence In picture 1-2 the main menu interface, press number 3 to choose In picture 1-14, press the number in front of the mode, then the option. Press number 3 again to confirm the selection. press the number again to confirm the selection. The chosen Picture1-14 will show the home security. -
Page 15: Information Check
Information check In picture 1-2 the main menu interface, press number 4 to choose Notice the option. Press number 4 again to confirm the selection. Picture Home mode: defence zones 1-5 are cancelled. 1-17 will show the information check. There are community Out mode: defence zones 1-5 are set. - Page 16 1. Information check In picture 1-17, choose the number of the icon and press the number again to confirm the selection. The screen will show Are you sure to delete picture 1-18 information list. Press to turn the page. Press the number in front of each message and confirm, then the message text will display as picture 1-19.
-
Page 17: Call Lift
Call lift SM328/812CH indoor monitor operation guide Press on the left of the indoor monitor to call the lift. System startup Before turn on the power, make sure the indoor monitor is connected correctly. Then turn on the power switch on the side of Ring the indoor monitor. -
Page 18: Main Menu Interface
Main menu interface System setting After the system starts successfully or it is in the standby mode, In picture 2-2 main menu interface, press system setting icon. Picture 2-3 system password will pop up. Enter the system press any place of the touch screen, main menu interface will show. password (factory default password is 0000) and press # to confirm. - Page 19 Click the option for modification. Press keypad to enter the the blank. Press * to delete. Press # to confirm. Press Return information Press * to delete. Press # to confirm. Press Return to return. to return. MAC address: Building number: 0001 (4-digit) 145236 (address must be unique IP address: 192.168.010.101 Unit number: 01 (2-digit) (address must be unique)
-
Page 20: User Setting
User setting 4.Time setting In picture 2-2, click user setting icon and picture 2-9 will pop In picture 2-4, press time setting icon and enter picture 2-8. up. Enter user password (factory default password is 1234). Press # Click the blank and enter the information by keypad. Press * to confirm.In picture 2-10, there are ringtone, no interruption and to delete. -
Page 21: Intercom
Intercom 2. User password setting In picture 2-2 main menu interface, click intercom and enter In picture 2-10, click user password setting icon and enter to picture 2-12. User can call the guard station, intercom with other picture 2-11. apartments, intercom within the same house, call transfer and call Enter 4-digit password (factory default password is 1234), indoor monitor. -
Page 22: Call Transfer
2.Intercom with other apartments Notice In the same network, users can call each other with the indoor monitors. When user calls all the indoor monitors, all indoor In picture 2-12, enter the building number,unit number, floor monitors ring in the same time. When one of the number and room number of the receiver' s indoor monitor. -
Page 23: Monitor/Unlock
Monitor / unlock In picture 2-2 main menu interface, click to enter picture 2-13 Notice: monitor view of outdoor station 1. (1) The maximum monitor time is 30 seconds. After 30 seconds, indoor monitor will hang up automatically. (2) When simulated outdoor station is connected. press number 0 to monitor this outdoor station. -
Page 24: Home Security
Home security 1.Set defence In picture 2-2 main menu interface, press to enter picture 2-14 In picture 2-14, press the mode icon.The chosen icon turns to home security setting. There are home,out,sleep and SOS modes. orange and show "defence delay". After the 60 seconds default delay time, the indoor monitor will show "set defence successfully". -
Page 25: Information Check
Information check In picture 2-2 the main menu interface, click to enter Picture Notice 1-17. There are community information, visitor pictures, defence Home mode: defence zones 1-5 are cancelled. record, alarm record. Out mode: defence zones 1-5 are set. Sleep mode: defence zones 1 & 2 are set.defence zones 3-5 are cancelled. - Page 26 1. Information check Notice In picture 2-17, click the icon to enter the information list as picture 2-18. Press to turn the page. Double UP 0 Down# The storage is maximum 1000 text and 200 pictures. clicks the information title to read the message text as When the storage is full, once new information comes picture 2-19.
-
Page 27: Call Lift
Notice Call lift Press on the left of the indoor monitor to call the lift. Do not close to the strong Avoid water. magnetic fields Ring When the indoor monitor connects to the ring, once visitor calls, the indoor monitor will ring. Avoid sun.
