Power Button: To power ON/OFF of the device
The default IP address is 192.168.188.253
Default user name & password are admin
RJ45 Connector
NC-AP233P with 1
NC-AP233 with 1
NC-AP231 with 1
:
WAN
The WAN port is used to connect to the power and Internet
NC-AP233P with 1
NC-AP233 with 1
NC-AP231 with 1
3. Login
Connect your PC to the In-Wall Access Point's LAN Port, then login Web
Management Page with default IP Address:
Default username & password: admin. Below base on Chrome browser.
Note:
Before login the Web Management Page, configure your PC with a fixed IP
address, 192.168.188.X (X between 2 to 252) since default mode is AP
Mode.
Login Steps:
O
pen Chrome browser, input http://192.168.188.253 in the address bar to login
Access Point
Input the default user name & password: admin, then click "Log In"
x 10/100Mbps auto-negotiation RJ45 LAN Port
x 10/100Mbps auto-negotiation RJ45 LAN Port
x 10/100Mbps auto-negotiation RJ45 LAN Port
x 10/100Mbps auto-negotiation RJ45 WAN Port
x 10/100Mbps auto-negotiation RJ45 WAN Port
x 10/100Mbps auto-negotiation RJ45 WAN Port
2
http://192.168.188.253
www.nc-link.cn
