TopPage
Refrigerant; HFC-134a
Refer to "HFC-134a COOLING UNIT" Service Manual for handling this refrigerant.
[1]
EXTERNAL DESCRIPTION .................. . ....... 2-1
[2]
CONSTRUCTIONS................................ . ....... 2-2
[1]
CLEARANCE ......................................... . ....... 3-1
[2]
INNER DIMENTIONS ............................ . ....... 3-3
[1]
WIRING DIAGRAM................................ . ....... 5-1
[2]
ELECTRIC ACCESSORIES LAYOUT ... . ....... 5-2
[1]
OUTLINE OF CONTROL....................... . ....... 6-1
[2]
(Forced Defrosting) ................................ . ....... 6-1
[3]
POWER FAILURE ................................. . ....... 6-2
SERVICE MANUAL
Refrigerator-freezer
MODELS
SJ-D20N-SLG
SJ-D24N-SLG
SJ-D28N-SLG
SJ-D29N-SLG
CONTENTS
[4]
[5]
CONVERSION TABLE .................................. 6-3
[6]
[1]
CONTROL..................................................... 7-1
CHAPTER 8. ASSEMBLING PROCEDURES OF
MAIN PARTS AND CAUTIONS
[1]
F-LOUVER ASS'Y ......................................... 8-1
[2]
R CONTROL COV. ASS'Y ............................ 8-4
[3]
HOW TO REPLACE THE LAMP ................... 8-6
[4]
DEFROST HEATER ...................................... 8-7
[1]
COOLING UNIT ............................................ 9-1
[2]
LOCATION .................................................... 9-2
SJ-D20N/D24N/D28N/D29N-SLG
No. S9633SE26ATUTT
DESTINATION
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
T
