- Page 1 SX-1141 User Guide...
-
Page 2: Table Of Contents
Catalogue Characteristic…………………………………………………………………1 Output Mode…………………………………………………….…………………2 Languages Setting………………………………………….………………2-3 Serial Interface Setting…………………………………..……………4-5 Lowercase And Uppercase Setting…………………………...…………………5 Barcode Type Setting………………………………………..…………………5 UPC/EAN-attached code Setting……………………………...……………………6 Line Skip and Enter Setting……………………………………...…………………6 Add Prefix And Suffix……………………………………..…………………7 Hide The Front/Behind Part Characters Of Barcode…………..……………8 Prefix and Suffix Character………………………………..….………………9-10 The Number of The Hidden Characters…….……………...…………………11-12 Statement of Warranty…………………….………...……………………13... -
Page 3: Characteristic
The SX-1141 has two auto-induction modes and a standard trigger mode. See below modes: 1.Auto-induction A When mounted in the stand, the scanner will be in continuous scan mode, out of the stand the scanner is trigger operated. 2.Auto-induction B Press &... -
Page 4: Output Mode
Output Mode Version Number Recover Procedure PS 2 Keyboard Mode Serial Port Mode USB Keyboard Mode USB Serial Port Mode Continuous Scanning Mode Language setting America Belgium Brazil Canada -French Croatia Czech Republic Slovakia Denmark Finland France Germany Hungary... - Page 5 Italy Latin America Netherlands Norway Poland Portugal Yugoslavia/Serbia Slovenia SpaIn Sweden Switzerland - French Switzerland-German General Turkey -F Turkey-Q Buzzer settings Sound Off Sound On...
-
Page 6: Serial Interface Setting
Serial Interface Settings Baud Rate 2400 4800 9600 19200 Handshake Protocol None Handshake Signal Time Handshake Signal Time Response-2 Seconds Response – 5 Seconds Data bits Stop Bit 8-bit 7-bit 1-bit 2-bit... -
Page 7: Lowercase And Uppercase Setting
Check Mode None Odd Check Even Check Label Check Blank Reset Lowercase And Uppercase Settings Lowercase Uppercase Recover Barcode Type Settings Close ID Close ID Character Open ID Character Character after Barcode before Barcode before Barcode... -
Page 8: Upc/Ean-Attached Code Setting
Hide Barcode Open ID Character Display Barcode Type after Barcode after Barcode Type after Barcode UPC/EAN-attached code Settings Add Two Bit & Five Bit Add Five Bit Attached Close the Attached Add Two Bit Attached Attached Codes to Codes to UPC/EAN Code of UPC/EAN Codes to UPC/EAN UPC/EAN... -
Page 9: Add Prefix And Suffix
1.Add Prefix The first step: scan “add prefix” setting code (this step will clear the prefix previously set) Add Prefix The second step:scan the needed “prefix and suffix ”,(no more than 32 characters). 2.Add Suffix The first step:scan“add suffix” setting code (this step will clear the suffix previously set). Add Suffix The second step:scan the needed “prefix and suffix ”,(no more than 32 characters). -
Page 10: Hide The Front/Behind Part Characters Of Barcode
3.Hide The Front Part Characters Of Barcode Scan “Hide The Front Part Characters of Barcode” setting code(This step will clean the previous setting) Hide The Front Part Characters Of Barcode Scan“The Number Of The Hiding Characters”(It can hide 32 character at most) 4.Hide The Behind Part Characters Of Barcode Scan “Hide The Front Part Characters Of Barcode”... -
Page 11: Prefix And Suffix Character
5.Prefix And Suffix... -
Page 13: The Number Of The Hidden Characters
6.The Number Of The Hiding Characters... - Page 15 About the Warranty The product is covered by a 12 months RTB (return to base) UK warranty. The warranty covers all parts, labour & return carriage. Exceptions to warranty a. The warranty period has expired. b. Accidental damage and/or operator error c.
