SX-1141 USB LASER SCANNER
USER GUIDE V2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX-1141 and is the answer not in the manual?

Questions and answers

Related Manuals for Scandex SX-1141

Summary of Contents for Scandex SX-1141

  • Page 1 SX-1141 USB LASER SCANNER USER GUIDE V2...

  • Page 2: Table Of Contents

    INDEX Characteristics............... Output Mode..............Language Settings............Serial Interface Settings..........Enter and Line Skip Settings..........Prefix and Suffix............. Character Codes Table............ Number of Concealed Characters Table......Performance Parameters..........Content................Warranty................ Maintenance Record............

  • Page 3: Characteristics

    Please take time to read this user guide before using the barcode scanner. If you have any questions please contact us or alternatively support is available via the “Scandex Red Card”enclosed in the box. CHARACTERISTICS Ergonomic design. External soft rubber bumpers and rugged internal build superior to the average drop resistance.

  • Page 4: Output Mode

    OUTPUT MODE Ps2 Keyboard Mode USB Keyboard Mode USB Serial Port Mode Serial Port Mode Version Number Continuous Scanning Mode Recover Procedure BUZZER SETTINGS Sound Off 014200 Sound On 0B142...

  • Page 5: Language Settings

    LANGUAGE SETTINGS American Dutch-Belgium Portuguese-Brazil French-Canada Croatian Czech Slovakian Danish Finnish French German Hungarian Italian Latin American...
  • Page 6 Dutch-Netherlands Norwegian Polish Portuguese-Portugal Serbian Slovenian Spanish Swedish Swiss-French Swiss-German English General Turkish-F Turkish-Q...

  • Page 7: Serial Interface Settings

    SERIAL INTERFACE SETTINGS BAUD RATE 2400 4800 9600 19200 HANDSHAKE PROTOCOL XON/OFF ACK/NAK None RTS/CTS Handshake Signal Time Handshake Signal Time Response-2 Seconds Response-5 Seconds...
  • Page 8 DATA BITS STOP BITS 8-bit 7-bit 1-bit 2-bit CHECK MODE None Odd Check Even Check Label Check Blank Reset...
  • Page 9 LOWERCASE AND UPPERCASE SETTINGS Lowercase Uppercase Recover BARCODE TYPE SETTINGS Close ID character Open ID character Close ID character before barcode before barcode after barcode Open ID character Display barcode Type Hyde barcode Type after barcode after barcode after barcode...

  • Page 10: Enter And Line Skip Settings

    UPC/EAN ATTACHED CODE SETTINGS Add 2 Bits attached Add 5 Bits attached code UPC/EAN code UPC/EAN Close the attached Add 2 & 5 Bits attached code UPC/EAN code UPC/EAN ENTER AND LINE SKIP SETTINGS Enable Enter Line Skip Disable Enter...

  • Page 11: Prefix And Suffix

    ADD PREFIX Add Prefix Example: To add the prefix ‘AM’ scan the following codes: ‘Add Prefix’. Turn to page 11,from the ‘Character Codes Table’ scan the codes ‘A' and ‘M’. Maximum 32 characters. ADD SUFFIX Add Suffix Example: To add the prefix ‘AM’ scan the following codes: ‘Add Suffix’. Turn to page 11,from the ‘Character Codes Table’...
  • Page 12 CONCEAL INITIAL CHARACTERS Conceal Initial Characters Example: To conceal the two first characters of the barcodes we read, scan the following codes: ‘Conceal Initial Characters’. Turn to page 14, from the ‘Number of Concealed Character Table’ scan the code ‘02'. CONCEAL FINAL CHARACTERS Conceal Final Characters Example: To conceal the four last characters of the barcodes we read,...

  • Page 13: Character Codes Table

    CHARACTER CODE TABLE...
  • Page 14 & < > ‘...
  • Page 15 “...

  • Page 16: Number Of Concealed Characters Table

    NUMBER OF CONCEALED CHARACTERS TABLE...
  • Page 18 KEY FUNCTION SETTING Scroll Lock Insert Delete Home BS/Back Space Page Up Page Down Down Left Right Num Lock Caps Lock Enter Space...

  • Page 19: Performance Parameters

    PERFORMANCE PARAMETERS Optical Source: 650nm Visible red light diode Image Resolution: 4mil Minimum Contrast: Decoding capacity: UPC/EAN/JAN, UPC/EAN with supplements, UCC/EAN 128, Code 39, Code 39 ASCII complete, Code 39 TriOptic, Code 128, Code 128 ASCII complete, Codabar, Interleaved 2 of 5, Code 93, MSI, Code 11, variants IATA, RSS, chinese 2 of 5. Decoding Speed: 100 times/s Barcode Sens: +65°, +42°, +60°...
  • Page 20 MECHANICAL AND ELECTRIC PERFORMANCE Size (Length, Width, Height): 156 x 64 x 91 mm Weight (without cable): 108 g Indicator: Buzzer and LED light Max. Power: 450mw Working Voltage: DC5V Current: 62ma (Working) Max. Current: 90ma Stand By Current: 71ma Charging Current: 450ma...
  • Page 21 ENVIRONMENTAL PARAMETER Storage Temperature: -40°C ~ 60°C Working Temperature: 0° ~ 50°C Relative Humidity: 0 ~ 95% Height Range: 1.5m IP rating: IP52 CERTIFICATES CE, RoHS, EMC, LVD ISO9001:2008 ISO14001:2004...

  • Page 22: Content

    CONTENT ACCESSORY QUANTITY Scanner USB cable User guide...

  • Page 23: Warranty

    WARRANTY Enjoy a year of service and maintenance for the rubber or plastic parts of the scanner, 6 months of service repair battery and charger and 3 months for the data cable. During the warranty period, repair and maintenance of the product is free. Once the warranty has expired, maintenance costs and components replaced will be charged.

  • Page 24: Maintenance Record

    Name Name Address Address Postcode Postcode Sign Email Seal Part No. Serial No. Purchase Date Please be sure to carefully read the instructions for repair and complete the information correctly. The warranty card is only valid if it is signed with the official Distributor’s seal.
