SX-1134 433 MHZ LASER SCANNER
USER GUIDE V2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX-1134 and is the answer not in the manual?

Questions and answers

Related Manuals for Scandex SX-1134

Summary of Contents for Scandex SX-1134

  • Page 1 SX-1134 433 MHZ LASER SCANNER USER GUIDE V2...

  • Page 2: Table Of Contents

    INDEX Characteristics............... Functions............... Pairing Mode..............Working Mode..............Prefix and Suffix............. Character Codes Table............ Number of Conceal Characters Table........ Operation Guide............. Performance Parameters..........Content................Warranty................ Maintenance Record............

  • Page 3: Characteristics

    Please take time to read this user guide before using the barcode scanner. If you have any questions please contact us or alternatively support is available via the “Scandex Red Card”enclosed in the box. CHARACTERISTICS Ergonomic design. External soft rubber bumpers and rugged internal build superior to the average drop resistance.

  • Page 4: Functions

    FUNCTIONS Automatic jumping frequency. Strong Anti-Interference ability. Transmission distance with obstacles under ‘Normal Mode’ is 20m-100m and over 400m with no obstacles. If the distance is exceeded 3 beeps will sound, indicating the data load has failed. Each scanner has a unique mechanical ID to avoid interferences with other devices in use. The customizable ID allows the user to distinguish the data source easily.

  • Page 5: Pairing Mode

    PAIRING MODE One to one One to one & storage One to more More to one INSTRUCTIONS Connect the receiver into the computer USB interface. The indicator on the cradle turns on while the drivers are being installed. Scan the code ‘One to One’ within 5 seconds, before the indicator on the scanner starts flashing indicating the installation is complete.
  • Page 6 On e to On e On e to On e On e to On e Sto re d Data Upload Sto re d Data Total Sto r e d Data Reset On e to On e On e to On e Stored Data Sto re d Data Restore Breakpoint Continuingly Clear All One to More Pairing...
  • Page 7 ID SETTINGS ID Se tti n gs D i sp l a y ID Hide I D ID PARAMETERS TABLE...
  • Page 8 SLEEP MODE SETTINGS Sleep Mode Settings 20 sec 30 sec 60 sec 2 min 5 min 10 min 20 min 8 hrs None By default the pre set time for the device to enter into ‘Sleep Mode’ is 20 seconds.

  • Page 9: Working Mode

    WORKING MODE SETTINGS Normal Mode No Losing Mode No Losing Mode Clear Stored Data No Losing Mode Total Stored Data Under the ‘No Losing Mode’, when exceeding the wireless transmission range the data will be stored and will be uploaded to the receiver when reaching the wireless transmission range. WORK STATUS Recovery Routine Wireless Mode...
  • Page 10 C h e ck Mo d e Checked D a ta Clear Checked D a ta Total Checked D a ta Restore Checked D a ta Upload Checked D a ta Upload Checked D a ta Upload Sound ON Sound OFF Bre a kp o i n t If the scanner losses connection during the upload process read the code ‘Breakpoint’...
  • Page 11 CHECKED DATA UPLOAD UNDER NO LOSING MODE TIME SETTINGS 0.1 sec 0.5 sec 1 sec 2 sec 3 sec 4 sec 5 sec...
  • Page 12 USB DATA UPLOAD INTERVAL TIME SETTINGS USB Upload Time S e tti n gs 0 ms 2 5 ms 5 0 ms 7 5 ms 1 2 5 ms 1 0 0 ms Note: Linux systems must set as ‘75ms’.
  • Page 13 LANGUAGE SETTINGS En g l i sh Ita l i a n Ge rma n Fre n ch Tu rki sh Fi n n i sh C ze ch Sp a n i sh...
  • Page 14 ‘UPC / EAN ATTACHED CODE’ SETTINGS Close the Attached Add 2 Bits Attached Code to UPC & EAN Code of UPC & EAN Add 5 Bits Attached Add 2 and 5 Bits Attached Code to UPC & EAN Code to UPC & EAN ‘ENTER’...

  • Page 15: Prefix And Suffix

    ADD PREFIX Add Prefix Example: To add the prefix ‘AM’ scan the following codes: ‘Add Prefix’. Turn to page 15,from the ‘Character Codes Table’ scan the codes ‘A' and ‘M’. Maximum 32 characters. ADD SUFFIX Add Suffix Example: To add the prefix ‘AM’ scan the following codes: ‘Add Suffix’. Turn to page 15,from the ‘Character Codes Table’...
  • Page 16 CONCEAL INITIAL CHARACTERS Conceal Initial Characters Example: To conceal the two first characters of the barcodes we read, scan the following codes: ‘Conceal Initial Characters’. Turn to page 18, from the ‘Number of Concealed Character Table’ scan the code ‘02'. CONCEAL FINAL CHARACTERS Conceal Final Characters Example: To conceal the four last characters of the barcodes we read,...

  • Page 17: Character Codes Table

    CHARACTER CODE TABLE...
  • Page 18 & < > ‘...
  • Page 19 “...

  • Page 20: Number Of Conceal Characters Table

    NUMBER OF CONCEALED CHARACTERS TABLE...
  • Page 22 KEY FUNCTION SETTING Scroll Lock Inert Delete Home BS/Back Space Page Up Page Down Down Left Right Caps Lock Space Num Lock Enter...

  • Page 23: Operation Guide

    OPERATION GUIDE PAIRING MODE Connect the receiver into the computer USB interface. The indicator turns on while the drivers are being installed. Scan the code ‘One to One’ within 5 seconds, before the indicator on the scanner starts flashing indicating the installation is complete. The scanner is ready to be used.
  • Page 24 CHARGING Please use the charging equipment supplied to charge the scanner. The red light indicates the scanner is charging. When the red light is off indicates the scanner is fully charged. Note: Under ‘No Losing Mode’, when the signal exceeds the transmission distance and the receiving terminal cannot receive signals, the read barcode data will be stored automatically, this guarantees no data lost.

  • Page 25: Performance Parameters

    PERFORMANCE PARAMETERS Wireless Transmitting Distance: 300 - 400m (without obstacles) Optical Source: 650nm Visible red light diode Image Resolution: 4mil Minimum Contrast: Decoding capacity: UPC/EAN/JAN, UPC/EAN with supplements, UCC/EAN 128, Code 39, Code 39 ASCII complete, Code 39 TriOptic, Code 128, Code 128 ASCII complete, Codabar, Interleaved 2 of 5, Code 93, MSI, Code 11, variants IATA, RSS, chinese 2 of 5.
  • Page 26 MECHANICAL AND ELECTRIC PERFORMANCE Size (Length, Width, Height): 92.5 x 70 x 154.6 mm Weight (without cable): 162 g Indicator: Buzzer and LED light Battery Capacity: 600mah Max. Power: 345mw Working Voltage: DC5V Current: 83ma (Working), 60ua (Sleeping) Max. Current: 85ma Stand By Current: 60ma Charging Current: 450ma...
  • Page 27 ENVIRONMENTAL PARAMETER Storage Temperature: -40°C ~ 60°C Working Temperature: 0° ~ 50°C Relative Humidity: 0 ~ 95% Height Range: 1.5m IP rating: IP52 CERTIFICATES CE, RoHS, EMC, LVD ISO9001:2008 ISO14001:2004...
  • Page 28 CONTENT ACCESSORY QUANTITY Scanner Receiver (433MHZ) USB data line (1m) User guide...

  • Page 29: Content

    WARRANTY Enjoy a year of service and maintenance for the rubber or plastic parts of the scanner, 6 months of service repair battery and charger and 3 months for the data cable. During the warranty period, repair and maintenance of the product is free. Once the warranty has expired, maintenance costs and components replaced will be charged.

  • Page 30: Warranty

    Name Name Address Address Postcode Postcode Sign Email Seal Part No. Serial No. Purchase Date Please be sure to carefully read the instructions for repair and complete the information correctly. The warranty card is only valid if it is signed with the official Distributor’s seal.
