Introduction
Thank you for choosing the Nextech DFS series instrument. With
correct use and regular re-calibration it can give many years of accurate and
reliable service.
The DFS can measure tensile and compressive forces accurately, while
being simple to use by the operator. It may be used handheld or mounted to a
fixture or test stand.
Software and accessories are included to make your force gauge even
more versatile.
Before Use
Warning: Please read the entire manual carefully before using the Nextech
gauge. Make certain that any person using or having access to the gauge reads
and understands the entire manual beforehand. Improper use of the gauge
could cause damage and/or void its warranty.
Never attempt to remove the rear cover nor repair the gauge yourself.
*Do not overload the load sensor. Whether the DFS is powered ON or Off,
overloading the sensor will cause irreparable damage. When powered ON,
forces greater than 120% of full-capacity will produce an audible beep and an
OL symbol will blink on the display until the load is released and the RESET key
is pressed.
3
DFS series User's Manual REV 3.8 November 2016
