Main Menu

Press MENU/ESC key to access the main menu. To move between the
options listed on the main menu page, press UP and DOWN arrow keys to move
the cursor. Press ENTER to select the sub-menus, activate features and enter
values. Within sub-menus UP, DOWN, LEFT and RIGHT arrow keys will also
change numerical values. Press ESC to return to the main menu page.
AUTO-OFF If desired, the Auto-Off function can be enabled to conserve
battery power. "AO" will appear on the main display when this feature has been
activated. The following steps can be used to enable or disable this feature.
1. Press the MENU key, notice that the display now shows Main Menu 1/2
(indicating page 1 of 2) in the navigation bar at the top of the screen.
2. Use UP and DOWN to move the cursor to highlight AUTO-OFF.
3. Press the ENTER key. Notice the Auto-Off Menu appears in the
navigation bar.
4. From this menu, one of the available Auto-Off time periods can be
selected and enabled or this function can be set to OFF.
5. Press the ESC key to return to the Main Menu page.
11
MAIN MENU

1) AUTO-OFF

2) PASS-FAIL
3) MEMORY
4) CALIBRATION
5) DIAGNOSTIC
6) SELECT OUPUT
Figure 4 Main Menu
AUTO-OFF MENU
1) OFF
2) 5 MINUTE
3) 10 MINUTE
4) 15 MINUTE
Figure 5 Auto-Off Menu
DFS series User's Manual REV 3.8 November 2016
1/2
