CHAPTER 1:

STUDIO 64X OVERVIEW

Thank you for purchasing Opcode's
Studio 64X, a dual platform MIDI interface,
patchbay, and SMPTE processor. The
Studio 64X includes the following
capabilities:
• Compatible with notebook, laptop, and
desktop Macs or PCs;
• Serial port THRU connection (both MAC
and PC) for easy access to serial devices;
• 4 x 6 MIDI interface with support for 64
channels;
• Read and write all SMPTE formats, also
includes freewheeling and regeneration;
• Stand-alone MIDI patchbay—recall rout-
ings and filterings or even stripe SMPTE
from front panel;
• 4 user programs accessible from front
panel for MIDI routing and filtering;
• 4 preset programs accessible from front
panel: PANIC, SMPTE, ALL, and TUNE;
• Front panel status LEDs for SMPTE and
MIDI IN/OUT activity;
• Software, Mac and Windows, for on-
screen editing of Studio 64X user
programs;
• MME compatible driver for Windows
3.1, Windows 95, and Windows for
Workgroups;
• OMS driver for Macs, including support
for OMS Studio Patches.
Getting Started with the Studio 64X
Introduction
What's Included in the
Studio 64X Package
Your Opcode Studio 64X package includes:
•
•
•
•
•
•
•
•
•

System Requirements

To use the Studio 64X with a PC, you need:
•
•
•
To use the Studio 64X with a Macintosh, you
need:
•
•
•
•
Studio 64X MIDI Interface
DC power adapter
PC serial cable, with cable adapter
Macintosh serial cable
PC floppy disk
Macintosh floppy disks
Getting Started Manual for easy setup
Technical Support Information Sheet
Registration card
An IBM PC compatible with COM port;
Windows 3.1, Windows for Work-
groups, or Windows 95;
MIDI instruments and cables.
A 68020 Macintosh or faster, or a Power
Macintosh;
System 7.0.1 or later;
4 MB of available RAM;
MIDI instruments and cables.
