Sharp LC-13B2E Service Manual page 39

Ref. No. Part No.
DUNTKA696FE01
MAIN UNIT (Continued)
R708 VRS-CY1JF272F J 2.7k 1/16W Metal Oxide
R709 VRS-CY1JF123F J 12k 1/16W Metal Oxide
R711 VRS-CY1JF184J J 180k 1/16W Metal Oxide
R712 VRS-CY1JF683F J 68k 1/16W Metal Oxide
R713 VRS-CY1JF133F J 13k 1/16W Metal Oxide
R715 VRS-CY1JF000J J 0
R717 VRS-CY1JF152F J 1.5k 1/16W Metal Oxide
R718 VRS-CY1JF274J J 270k 1/16W Metal Oxide
R719 VRS-CY1JF563F J 56k 1/16W Metal Oxide
R720 VRS-CY1JF473J J 47k 1/16W Metal Oxide
R721 VRS-CY1JF103J J 10k 1/16W Metal Oxide
R722 VRS-CY1JF105J J 1.0M 1/16W Metal Oxide
R723 VRS-CY1JF682J J 6.8k 1/16W Metal Oxide
R729 VRS-TQ2BD000J J 0
R731 VRS-TQ2BD000J J 0
R732 VRS-TW2ED222J J 2.2k 1/4W
R733 VRS-TQ2BD683J J 68k 1/8W
R734 VRS-CY1JF393J J 39k 1/16W Metal Oxide
R735 VRS-CY1JF223J J 22k 1/16W Metal Oxide
R736 VRS-CY1JF1R0J J 1.0
R741 VRS-TQ2BD000J J 0
R742 VRS-CY1JF000J J 0
R747 VRS-CY1JF000J J 0
R748 VRS-CY1JF000J J 0
R751 VRS-CY1JF1R0J J 1.0
R752 VRS-CY1JF154J J 150k 1/16W Metal Oxide
R753 VRS-CY1JF274J J 270k 1/16W Metal Oxide
R777 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R787 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide
R788 VRS-TW2ED102J J 1.0k 1/4W
R789 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R790 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R791 VRS-TW2ED1R0J J 1.0
R801 VRS-CB1JF221J J 220 1/16W Metal Oxide
R802 VRS-CB1JF220J J 22
R803 VRS-CB1JF220J J 22
R804 VRS-CA1JF101J J 100 1/16W Metal Oxide
R810 VRS-CB1JF220J J 22
R811 VRS-CY1JF222J J 2.2k 1/16W Metal Oxide
R812 VRS-CY1JF000J J 0
R813 VRS-CB1JF220J J 22
R814 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide
R815 VRS-CY1JF000J J 0
R816 VRS-CY1JF470J J 47
R817 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide
R818 VRS-CY1JF331J J 330 1/16W Metal Oxide
R819 VRS-CY1JF000J J 0
R820 VRS-CA1JF102J J 1.0k 1/16W Metal Oxide
R821 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R822 VRS-CY1JF101J J 100 1/16W Metal Oxide
R824 VRS-CY1JF000J J 0
R825 VRS-CY1JF000J J 0
R826 VRS-CY1JF101J J 100 1/16W Metal Oxide
R827 VRS-CY1JF563J J 56k 1/16W Metal Oxide
R828 VRS-CY1JF153J J 15k 1/16W Metal Oxide
R830 VRS-CY1JF561J J 560 1/16W Metal Oxide
R836 VRS-CY1JF000J J 0
R838 VRS-CY1JF000J J 0
R840 VRS-CY1JF221J J 220 1/16W Metal Oxide
R850 VRS-CY1JF470J J 47
R901 VRS-CY1JF101J J 100 1/16W Metal Oxide
R902 VRS-CY1JF101J J 100 1/16W Metal Oxide
R903 VRS-CY1JF101J J 100 1/16W Metal Oxide
R905 VRS-CY1JF000J J 0
R906 VRS-CY1JF100J J 10
R907 VRS-CY1JF222J J 2.2k 1/16W Metal Oxide
R909 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R910 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R911 VRS-CY1JF000J J 0
R912 VRS-CY1JF000J J 0
R913 VRS-CY1JF000J J 0
Description Code
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
1/8W Metal Oxide AA
1/8W Metal Oxide AA
Metal Oxide AA
Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
1/8W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
Metal Oxide AA
AA
AA
1/4W Metal Oxide AB
AC
1/16W Metal Oxide AC
1/16W Metal Oxide AC
AA
1/16W Metal Oxide AC
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AC
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
51
Ref. No. Part No.
R914 VRS-CY1JF000J J 0
R915 VRS-CY1JF000J J 0
R916 VRS-CY1JF000J J 0
R917 VRS-CY1JF105J J 1.0M 1/16W Metal Oxide
R918 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide
R919 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide
R920 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide
R921 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide
R922 VRS-CY1JF223J J 22k 1/16W Metal Oxide
R923 VRS-CY1JF223J J 22k 1/16W Metal Oxide
R924 VRS-CY1JF473J J 47k 1/16W Metal Oxide
R925 VRS-CY1JF473J J 47k 1/16W Metal Oxide
R951 VRS-CY1JF000J J 0
R952 VRS-CY1JF104J J 100k 1/16W Metal Oxide
R954 VRS-CY1JF000J J 0
R955 VRS-CY1JF104J J 100k 1/16W Metal Oxide
R958 VRS-CY1JF433J J 43k 1/16W Metal Oxide
R959 VRS-CY1JF433J J 43k 1/16W Metal Oxide
R960 VRS-CY1JF433J J 43k 1/16W Metal Oxide
R961 VRS-CY1JF433J J 43k 1/16W Metal Oxide
R962 VRS-CY1JF153J J 15k 1/16W Metal Oxide
R963 VRS-CY1JF223J J 22k 1/16W Metal Oxide
R964 VRS-CY1JF473J J 47k 1/16W Metal Oxide
R965 VRS-CY1JF473J J 47k 1/16W Metal Oxide
R966 VRS-CY1JF153J J 15k 1/16W Metal Oxide
R967 VRS-CY1JF153J J 15k 1/16W Metal Oxide
R968 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide
R969 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide
R1101 VRS-CA1JF333J J 33k 1/16W Metal Oxide
R1102 VRS-CA1JF103J J 10k 1/16W Metal Oxide
R1103 VRS-CA1JF103J J 10k 1/16W Metal Oxide
R1104 VRS-CA1JF333J J 33k 1/16W Metal Oxide
R1105 VRS-CY1JF104J J 100k 1/16W Metal Oxide
R1106 VRS-CA1JF333J J 33k 1/16W Metal Oxide
R1107 VRS-CA1JF103J J 10k 1/16W Metal Oxide
R1108 VRS-CA1JF103J J 10k 1/16W Metal Oxide
R1109 VRS-CA1JF333J J 33k 1/16W Metal Oxide
R1110 VRS-CY1JF104J J 100k 1/16W Metal Oxide
R1111 VRS-CY1JF104J J 100k 1/16W Metal Oxide
R1112 VRS-CY1JF103F J 10k 1/16W Metal Oxide
R1113 VRS-CA1JF333J J 33k 1/16W Metal Oxide
R1114 VRS-CY1JF103F J 10k 1/16W Metal Oxide
R1115 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R1116 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R1117 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R1118 VRS-CY1JF823F J 82k 1/16W Metal Oxide
R1119 VRS-CY1JF472F J 4.7k 1/16W Metal Oxide
R1120 VRS-TX2HF8R2J J 8.2
R1121 VRS-CY1JF181J J 180 1/16W Metal Oxide
R1123 VRS-CY1JF181J J 180 1/16W Metal Oxide
R1124 VRS-CY1JF472F J 4.7k 1/16W Metal Oxide
R1125 VRS-TX2HF101J J 100 1/2W
R1126 VRS-CY1JF000J J 0
R1127 VRS-TX2HF1R0J J 1.0
R1128 VRS-CY1JF105J J 1.0M 1/16W Metal Oxide
R1129 VRS-CY1JF563F J 56k 1/16W Metal Oxide
R1130 VRS-TX2HF5R6J J 5.6
R1131 VRS-CY1JF105J J 1.0M 1/16W Metal Oxide
R1132 VRS-CY1JF000J J 0
R1133 VRS-CY1JF223F J 22k 1/16W Metal Oxide
R1134 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide
R1135 VRS-CY1JF561J J 560 1/16W Metal Oxide
R1136 VRS-CY1JF000J J 0
R1137 VRS-CY1JF000J J 0
R1138 VRS-CY1JF000J J 0
R1139 VRS-CY1JF563J J 56k 1/16W Metal Oxide
R1143 VRS-CY1JF103J J 10k 1/16W Metal Oxide
R1144 VRS-CY1JF103J J 10k 1/16W Metal Oxide
R1145 VRS-CY1JF103J J 10k 1/16W Metal Oxide
R1146 VRS-CY1JF123J J 12k 1/16W Metal Oxide
R1147 VRS-CY1JF100J J 10
R1148 VRS-CY1JF820J J 82
R1202 VRS-CB1JF220J J 22
R1203 VRS-CA1JF220J J 22
R1204 VRS-CB1JF220J J 22
LC-13B2E
Description Code
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/2W Metal Oxide AA
AA
AA
AA
Metal Oxide AA
1/16W Metal Oxide AA
1/2W Metal Oxide AA
AA
AA
1/2W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AC
1/16W Metal Oxide AA
1/16W Metal Oxide AC
