- Page 1 04/03/2015 Orion - Gulliver User Manual Orion – Gulliver Vertical Platform Lift User Manual USO-OR04-EN-04 ThyssenKrupp Encasa...
- Page 2 04/03/2015 Orion - Gulliver User Manual...
- Page 3 04/03/2015 Orion - Gulliver User Manual Dear Customer, We would like to congratulate you for having chosen this ThyssenKrupp Encasa product. This manual contains the instructions for the proper use of the system you have purchased. Read this manual carefully. It contains simple information, advice and warnings which have been illustrated in a clear and concise manner.
-
Page 4: Table Of Contents
04/03/2015 Orion - Gulliver User Manual Index General warnings ____________________________________________________________ 5 1.1. Declaration of Conformity __________________________________________________ 7 General precautions __________________________________________________________ 8 2.1. Precautions _____________________________________________________________ 8 2.2. Positioning the machinery _________________________________________________ 8 2.3. Electrical connection ______________________________________________________ 8 2.4. Learning procedure ______________________________________________________ 8 Commands and signals _______________________________________________________ 9 3.1. -
Page 5: General Warnings
04/03/2015 Orion - Gulliver User Manual General warnings The Platform Lift may only be used by people who are able to manoeuvre it safely or who are accompanied by another person that has been properly instructed as to its use. - Page 6 04/03/2015 Orion - Gulliver User Manual USER: The User is intended as the person who, having received the user manual and read and understood its contents, is suitable for operating and using the machine safely. EDUCATED PERSON: Educated person/s who have received information from the authorised installer/maintenance worker regarding the execution of emergency manoeuvres as shown below in this manual.
-
Page 7: Declaration Of Conformity
04/03/2015 Orion - Gulliver User Manual 1.1. Declaration of Conformity... -
Page 8: General Precautions
04/03/2015 Orion - Gulliver User Manual General precautions 2.1. Precautions Never leave the floor doors open. Before shutting-down the system (i.e. for a foreseen extended period of disuse), bring the Platform lift to its lowest served floor and make sure that all of the doors are perfectly closed. -
Page 9: Commands And Signals
04/03/2015 Orion - Gulliver User Manual Commands and signals All of the Platform Lift’s commands and signals are located inside the cabin, on the pushbutton panel. A list of the Platform Lift's commands and signals along with their names and functions, in reference to the figures shown, is provided below. -
Page 10: Display
Close the door to recover the normal operation of the platform). Automatic descent to the ground floor (optional). ThyssenKrupp Logo: visible in stand-by situations or in the case of the automatic levelling movement at a floor. It shuts itself off after a maximum time of 30 seconds. -
Page 11: Elegance Cabin Push Button Panel
04/03/2015 Orion - Gulliver User Manual 3.5 Elegance Cabin Push Button Panel 1. Emergency button 2. Alarm button Press this button to activate the acoustic alarm. 3. Automatic emergency lighting 4. Call button 5. Emergency Telephone button Press this button to activate the safety device which... -
Page 12: Siren
04/03/2015 Orion - Gulliver User Manual 3.7 Siren Apart from when the alarm button is pressed (not present in the case of autodialer system) the siren sounds in the following cases: The platform is not level with the floor and one or more doors are open or unlocked ->... -
Page 13: Machines With Manual Doors Or With "Evo" Motorised Door Openers
04/03/2015 Orion - Gulliver User Manual 4.2. Machines with manual doors or with “EVO” motorised door openers 4.2.1. How to call he Platform Lift from the floors If the green light is on, the Platform Lift has arrived at the floor. -
Page 14: Safety Features
04/03/2015 Orion - Gulliver User Manual 4.3 Safety features 4.3.1 Sensitive edges The sensitive edge is a device that stops the running of the plant system and is located on the edges of the flooring. In the event that a person or an object is located in an excessively external position and therefore not suitable for safety, the running is stopped and on the display the symbol for “safety stop”... -
Page 15: Light Maintenance
Memorandum no. 157296 dated 14/04/1997, must be stipulated with a service company which has been approved by THYSSENKRUPP ENCASA for all operations which the user cannot carry out. Regular maintenance of the Platform Lift, including at least two annual overhauls, will guarantee the continued efficiency of all of the parts which make up the Platform Lift and is indispensable for its safe and proper function. -
Page 16: Accessories
04/03/2015 Orion - Gulliver User Manual Accessories 8.1. Telephone The Platform Lift is equipped with a telephone, with an on-board keypad, which is mounted upon the push button panel. Connection of the telephone to the normal telephone network must be carried out by and under the responsibility of the client within 5 days. -
Page 17: Emergency Telephone Helpy (Standard Only For The Elegance Cabin)
04/03/2015 Orion - Gulliver User Manual 5. If you need to restart the call process, press the alarm button again. 8.4. Emergency telephone Helpy (standard only for the Elegance cabin) Sending a message By pressing the request assistance button (the “telephone” button in the cabin), the device automatically dials, in sequence, the programmed telephone numbers which have been associated with that type of alarm. -
Page 18: Malfunctions
04/03/2015 Orion - Gulliver User Manual 9. Malfunctions The Table below lists the problems which could occur during the machine's working life. The possible cause of each problem is indicated along with the relative action required to resolve the situation. -
Page 19: Emergency Devices
04/03/2015 Orion - Gulliver User Manual 10. Emergency devices Emergency stop To stop the Platform Lift, just press the emergency button (red button) on the push button panel. To start the Platform Lift again, turn the mushroom-head emergency button clockwise. -
Page 20: Safety Functions
04/03/2015 Orion - Gulliver User Manual Emergency descent Emergency descent Hydraulic unit “type B“ Hydraulic unit “type W“ Emergency descent Hydraulic unit “type T“ 11. Safety functions Never tamper with the safety devices. Do not activate the safety devices without cause. -
Page 21: Final Checks
04/03/2015 Orion - Gulliver User Manual 12. Final Checks Before releasing the lift for use, all of the verifications indicated in the end-installation list found in the user manual, must be performed. The list of tests found in the user manual must be filled out and signed by the installer. - Page 22 04/03/2015 Orion - Gulliver User Manual...
