Page 1: Notebook Computer
ORDER NO. CPD1105201CE Notebook Computer CF-31JEGAXDM Model No. This is the Service Manual for the following areas. M …for U.S.A. and Canada © Panasonic Corporation 2011. Unauthorized copying and distribution is a violation of law. - Page 2 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
-
Page 3: Laser Safety Information
LASER SAFETY INFORMATION Class 1 LASER Product PRODUCT COMPLIES WITH DHHD RULES 21 CFR CHAPTER 1,SUBCHAPTER J. 130KS This equipment is classified as a class 1 level LASER product and there is no hazardous LASER radiation. Caution (1) Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous exposure. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS 1. Before servicing, unplug the power cord to prevent an electric shock. 2. When replacing parts, use only manufacture's recommended components for safety. 3. Check the condition of the power cord. Replace if wear or damage is evident. 4. - Page 5 This computer has a high temperature mode function that product. Use of battery packs other than those manufactured and supplied by Panasonic may present a safety hazard (gen- prevents the degradation of the battery in high temperature eration of heat, ignition or rupture).
- Page 6 CF-AA5713A POUR UTILISER AVEC MODELE Use Only the Specified AC Adaptor With This Product Using an AC adaptor other than the one supplied (attached to your product or supplied by Panasonic) may result in a fire. Model No: CF-AA5713A 6 / 31...
-
Page 7: Disassembling Flow Chart
Disassembling Flow Chart HDD Unit, Preparation MP Unit DIMM Cover, EXT ANT PCB, DIMM, Keyboard WWAN RFSW PCB Bottom Case BT PCB, USB PCB, FPC(2nd Battery) Main Chassis, MP Chassis, Wireless FPC(MP), LCD Block LAN Module HDD Cable Cover Antenna PCB FPC(HDD/Battery) (WWAN Main/ Ass'y... -
Page 8: Exploded View
K32-1 K115 K32-2 K1-10 K115 K115 K32-5 K116 Screw tightening torque 0.45 ± 0.05 N . m K121 (4.5 ± 0.5 kgf . cm) 0.30 ± 0.03 N . m (3.0 ± 0.3 kgf . cm) CF-31JEGAXDM 8 / 31... - Page 9 (2.0 ± 0.2 kgf . cm) (15 ± 1.5 kgf . cm) H 0.3 ± 0.5 N . m 0.45 ± 0.05 N . m (3.0 ± 0.5 kgf . cm) (4.5 ± 0.5 kgf . cm) CF-31JEGAXDM 9 / 31...
- Page 10 0.19 ± 0.02 N . m K110 (2.0 ± 0.2 kgf . cm) K185 D 0.45 ± 0.05 N . m (4.5 ± 0.5 kgf . cm) 0.40 ± 0.05 N . m (4.0 ± 0.5 kgf . cm) CF-31JEGAXDM 10 / 31...
- Page 11 0.45 ± 0.05 N . m G 1.5 ± 0.15 N . m (4.5 ± 0.5 kgf . cm) (15 ± 1.5 kgf . cm) F 1.47 ± 0.2 N . m (15 ± 2.0 kgf . cm) CF-31JEGAXDM 11 / 31...
- Page 12 E32-4 E32-3 E32-5 E32-3 K132 K131 K184 E26-1 E26-1-1 E26-3 CF-31JEGAXDM 12 / 31...
-
Page 13: Replacement Parts List
Replacement Parts List Note : Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-31JEGAXDM REF. NO and AREA PART NO. DESCRIPTION Q'TY Main Block Unit... - Page 14 DFBS0081ZA-0 LCD LATCH DFDF5030ZA LCD LATCH SHAFT DFUN0094ZA LCD LATCH SPRING S DFKM8211YA-0 LCD REAR ASS'Y DFGB0131YA-0 PANASONIC BADGE S DFKE1019ZAT0 LCD DMP SIDE COVER R S DFKE1018ZAT0 LCD DMP SIDE COVER L DFHE0843ZA LCD MAGNET DFHR6532YA-0 ANTENNA COVER R...
- Page 15 DFMX0634ZA CD EDGE SHEET DFMD7C28YA HDD FPC HOLDER (SECC) DFHR6247ZB BATT GUIDE DFHR8521ZA BATT CN PIN CUSHION DFHM0396ZA BATT CN PIN S DFKM8217YA-0 TOP CASE ASS'Y K50-5 S DFKE0876ZB SPEAKER CASE B K50-6 S DFKE0856ZB-0 SPEAKER CASE A K50-7 DFHG1892YA SPEAKER CASE CUSHION K50-8 DFHR3Q90ZA...
- Page 16 DFHR9186ZA 5 FLAPS ASS'Y DFHR3Q03VA SERIAL COVER WP SHEET DFHR3Q04VA SIDE IO COVER WP SHEET DFHR3Q98YA DC WP SHEET DFHR6530ZAT0 FAN COVER DFHG2288ZA SUB ANT RUBBER DFMY0530ZA SUB HP HEAT RUBBER DFMY5054YA HEATSINK L6FCYYYD0007 DFMD7C29YA FAN FILTER DFHR3Q48ZA EX CARD EDGE SHEET DFHR6529ZA HDD CABLE COVER S DFKE0996YA...
- Page 17 DRQT2+E8FKLT SCREW XSB2+3FNL SCREW DXQT2+D4FNL SCREW DRSB26+8HKK SCREW DRQT26+E4FKK SCREW DRQT26+E6FKK SCREW DRSB26+3FKLT SCREW DRQT2+G6FKL SCREW DXSN26+6FNS SCREW DRQT26+E3FNK SCREW DRQT26+E3KLT SCREW DRYN4+J10KLT SCREW DFHE5025XAT SCREW DRHM0182ZA SCREW DRHM0186ZA SCREW DRHM5025YAT SCREW DRHM5054XAT SCREW XTB2+12GFJK SCREW XTB26+8GFJK SCREW 17 / 31...
- Page 18 Replacement Parts List Note: Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components use only manufacturer's specified parts. CF-31JEGAXDM PART NO. DESCRIPTION REF. NO and AREA Q'TY MAIN PCB C 1, 2, 3, 4, 5, 6, 7, 8, 9, F1G0J105A035 CAPACITOR, 6.3V, 1µF...
- Page 19 C 74, 92, 141, 142, 143, F1G1C104A048 CAPACITOR, 16V, 0.1µF 144, 151, 154, 157, 160, 173, 176, 179, 182, 216, 236, 237, 238, 239, 240, 241, 242, 243, 404, 405, 406, 407, 408, 423, 427, 429, 430, 432, 433, 436, 505, 506, 508, 510, 517, 525, 529, 531, 532, 534, 535, 537, 539, 541, 542,...
- Page 20 C 438 F1G1H8R0A544 CAPACITOR, 50V, 8pF C 1022, 1023, 1024, 1025 F1J2A103A018 CAPACITOR, 100V, 0.01µF C 1026 F1L3D1020008 CAPACITOR, 2KV, 1000pF C 1030, 1031, 1032, 1033, F1H1A105A092 CAPACITOR, 10V, 1µF 1048, 1059, 1060, 1103, 1115, 1215, 1278, 2010, 2050, 2071, 2072, 2102, 2165, 2166, 2179, 2180 C 1035 F1L0J107A017...
- Page 21 C 2041 F1G1H220A542 CAPACITOR, 50V, 22pF C 2053, 2124, 2128, 2130, F1G1C473A004 CAPACITOR, 16V, 0.047µF 2132 C 2056, 2060, 2076, 2093, F1H1C224A074 CAPACITOR, 16V, 0.22µF 2100, 2143, 2171, 2185 C 2069, 2078, 2168, 2169, F1G1H182A496 CAPACITOR, 50V, 1800pF 2182, 2183 C 2088 F1G1H680A542 CAPACITOR, 50V, 68pF...
- Page 22 F 11 S K5H153A00001 FUSE, 15A, 65V F 20, 21 S ERBSE0R50U FUSE, 0.5A, 32V F 2000 S K5H123Y00001 FUSE, 12A, 65V IC 3 C1CB00003647 IC 4 C2GBD0000100 IC 5 C2DBYY001053 MICRO CONTROLLER IC 16 C1CB00003086 SECURITY CHIP IC 17 C0JBAZ003072 LOGIC IC IC 19...
- Page 23 L 1014, 1016, 1026, 1027, J0JJC0000015 INDUCTOR 1030 L 1017, 1018 J0JAD0000028 CHIP COMMON MODE CHALK COIL ARRAY L 1019, 1021, 1022 J0JCC0000186 INDUCTOR L 1023, 1024, 1025 J0JDC0000095 CHIP BEADS L 1032, 1033, 1034 J0MAB0000229 CHIP COMMON MODE CHALK COIL L 2001, 2003 ETQP4LR36AFM POWER CHOKE COIL...
- Page 24 Q 2001, 2003, 2005, 2007, B1CFRD000050 2009, 2011 Q 2027 B1MBADA00007 Q 2061, 2062, 2063, 2064 B1CHGD000014 TRANSISTOR Q 2094 B1CFND000011 Q 2097 B1GBCFEN0013 TRANSISTOR Q 2122 B1CFRD000080 SILICON N CHANNEL MOSFET Q 2901, 2903, 2927, 2928 B1CDRD000002 TRANSISTOR R 1, 17, 23, 66, 79, 80, D0GA102JA023 RESISTOR, 1/16W, 1KΩ...
- Page 25 R 38, 171, 186, 187, 194, D0GA103JA023 RESISTOR, 1/16W, 10KΩ 195, 204, 243, 293, 294, 295, 419, 420, 425, 437, 438, 441, 443, 448, 454, 491, 510, 511, 629, 666, 667, 1048, 1049, 1077, 1083, 1084, 1087, 1090, 1091, 1094, 1101, 1138, 1139, 1155, 1161, 1163, 1176, 1183, 1185, 1188, 1195, 1208, 1209, 1234,...
- Page 26 R 174, 230 D1H83304A042 NETWORK CHIP RESISTOR R 177 D1BA37R4A023 RESISTOR, 1/16W, 37.4Ω R 178, 220 D1BA49R9A023 RESISTOR, 1/16W, 49.9Ω R 179, 219 D1BA7500A023 RESISTOR, 1/16W, 750Ω R 184, 185, 1055, 1056, D1H81034A042 NETWORK CHIP RESISTOR 1098, 1099, 1241, 1242, 1306 R 198 D1BA90R9A023...
- Page 27 R 2012 D1BA1201A023 RESISTOR, 1/16W, 1.2KΩ R 2013, 2020 D1BA2742A023 RESISTOR, 1/16W, 27.3KΩ R 2014 D1JB1M00A036 RESISTOR, 1W, 1mΩ R 2016, 2021 D1BA3831A023 RESISTOR, 1/16W, 3.83KΩ R 2017, 2018, 2057, 2067, D0GA100JA023 RESISTOR, 1/16W, 10Ω 2263, 2282 R 2022, 2252 D1BA1503A022 RESISTOR, 1/16W, 150KΩ...
- Page 28 R 2227 D1BA1432A022 RESISTOR, 1/16W, 14.3KΩ R 2228, 2229, 2230 D1BDR047A111 RESISTOR, 1/3W, 0.047Ω R 2231 D1BA3652A022 RESISTOR, 1/16W, 36.5KΩ R 2232 D1BA4701A022 RESISTOR, 1/16W, 4.7KΩ R 2233 D1BA1802A053 RESISTOR, 1/16W, 18KΩ R 2234 D1BA6041A023 RESISTOR, 1/16W, 6.04KΩ R 2236 D1BA6800A022 RESISTOR, 1/16W, 680Ω...
- Page 29 R 500, 501, 502, 503, 505, D0GA104JA023 RESISTOR, 1/16W, 100KΩ R 504 D0GA564JA023 RESISTOR, 1/16W, 560KΩ ZA 300, 301 K1YGZZ000078 MINI PCI EXPRESS STUD BOS USB PCB C 100, 101, 102, 109 EEFCX0J121R CAPACITOR, 6.3V, 120µF CN 100 K1MY20BA0430 CONNECTER CN 101, 102, 103, 104 K1FY104BA024 CONNECTOR, USB...
- Page 30 FL 703, 704, 705 J0HAAC000059 FILTER IC 701 C0JBAR000565 VIDEO SWITCH IC 702 C0JBAU000031 LOGIC IC IC 703 C0JBAA000362 IC, LOGIC JK 700, 701 K2HC103B0197 JACK L 700, 701, 702, 703, 704, J0JBC0000033 INDUCTOR 705, 706, 707 L 708, 709, 710, 724 J0MAB0000236 CHIP COMMON MODE CHALK COIL L 711, 712...
- Page 31 R 213, 214, 215, 216 D0GA822JA023 RESISTOR, 1/16W, 8.2KΩ R 218 D0GA562JA023 RESISTOR, 1/16W, 5.6KΩ R 227, 228 D0GA270JA023 RESISTOR, 1/16W, 27Ω R 229 D0GA152JA023 RESISTOR, 1/16W, 1.5KΩ R 233 D0GAR00J0005 RESISTOR, 1/16W, 0Ω X 200 H2D600400005 OSCILLATOR, 6MHz SD WIRELESS OFF PCB C 700, 701, 703, 705, 707, F1G1C104A048 CAPACITOR, 16V, 0.1µF...
