Please read these instructions carefully before using this product, and save this manual for future use.

OPERATING INSTRUCTIONS

Contents
Getting Started
Introduction .................................................................
Read Me First ............................................................
(Precautions)
Description of Parts ..................................................
First-time Operation ..................................................

Useful Information

On-screen Manual ....................................................
Handling and Maintenance .......................................
Reinstalling Software ................................................

Troubleshooting

Troubleshooting (Basic) ............................................
Appendix
LIMITED USE LICENSE AGREEMENT ...................
Specifi cations ...........................................................
LIMITED WARRANTY ..............................................
Personal Computer
CF-31
series
2
3
10
13
17
18
20
22
27
29
33

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Toughbook CF-31AAA7L1M

Summary of Contents for Panasonic Toughbook CF-31AAA7L1M

  • Page 1: Table Of Contents

    OPERATING INSTRUCTIONS Personal Computer CF-31 series Model No. Contents Getting Started Introduction ..............Read Me First ............(Precautions) Description of Parts ..........First-time Operation ..........Useful Information On-screen Manual ............ Handling and Maintenance ........Reinstalling Software ..........Troubleshooting Troubleshooting (Basic) ..........Appendix LIMITED USE LICENSE AGREEMENT ....

  • Page 2: Introduction

    Introduction Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions carefully. Terms and illustrations in these instructions Conditions that may result in minor or moderate injury. CAUTION Useful and helpful information. NOTE Enter : Press [Enter] key.

  • Page 3: Read Me First

    6-M-1 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced radio/TV technician for help. Warning To assure continued compliance, use only shielded interface <Only for model with modem>...
  • Page 4 Read Me First 10. According to the FCC’s electrical safety advisory, we recom- <For USA-California Only> mend that you may install an AC surge arrestor in the AC outlet This product contains a Coin Cell Lithium Battery to which this equipment is connected. Telephone companies which contains Perchlorate Material - special handling report that electrical surges, typically lightning transients, are may apply.
  • Page 5 <Only for model with a “CE” mark on the bottom of the computer> Declaration of Conformity (DoC) “Hereby, Panasonic declares that this Personal Computer is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http://www.doc.panasonic.de...
  • Page 6 Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions. When in a hospital or other health care facility, observe the restrictions on the use of mobiles. Switch Personal Computer or Handheld Computer incorporating wireless WAN modem off, if instructed to do so by the guidelines posted in sensitive areas.
  • Page 7 Lithium Battery / Pile au lithium Lithium Battery! Pile au lithium! This computer contains a lithium battery to enable the date, Le micro-ordinateur renferme une pile au lithium qui permet de time, and other data to be stored. The battery should only be sauvegarder certaines données, notamment la date et l’heure.
  • Page 8 fi re. human life or safety. Panasonic cannot be held responsible in Keep SD Memory Cards Away from Infants and Small Chil-...
  • Page 9 Use of battery packs other than those manufactured and environments. ( Reference Manual “Battery Power”) A supplied by Panasonic may present a safety hazard (generation level corresponding to a 100% charge for high temperature of heat, ignition or rupture).

  • Page 10: Description Of Parts

    Description of Parts Left side : Caps lock : Numeric key (NumLk) : Scroll lock (ScrLk) : Hard disk drive status A: Wireless LAN Antenna : Power status of the multimedia pocket <Only for model with wireless LAN> : Battery status Reference Manual “Wireless LAN”...
  • Page 11 Right side 1394 Rear side Bottom A: Hard Disk Drive When they are connected, audio from the internal speakers is not heard. Reference Manual “Hard Disk Drive” N: Microphone Jack B: HDMI Port A condenser microphone can be used. If other types Reference Manual “External Display”...
  • Page 12 Description of Parts This computer contains a magnet and magnetic products at the locations circled in the illustration at right. Avoid leaving metallic object or magnetic me- dia in contact with these areas. Attaching the stylus to the computer (only for model with touchscreen) Use the tether to attach the stylus to the computer so you will not lose it.

  • Page 13: First-Time Operation

    First-time Operation Preparation A Check and identify the supplied accessories. If you do not fi nd the described accessories, contact Panasonic Technical Support ( page 33). • AC Adaptor ..1 • AC Cord ..1 •...

  • Page 14: Turn On The Computer

    CPU. Wait until the computer cools down, and then turn the power on again. If the computer does not power on even after cooling down, contact Panasonic Technical Support ( page 33). Any changes from the default setting of the Setup Utility must not be made until the First-time Operation is completed.
  • Page 15 Do not use the following words for user name: CON, PRN, AUX, CLOCK$, NUL, COM1 to COM9, LPT1 to LPT9, @. In particular, if you create a user name (ac- count name) that includes the “@” mark, a password will be requested at the log-on screen, even if no password has been set.
  • Page 16 First-time Operation Create a new account. Click [start] - [Control Panel] - [User Accounts] - [Create a new account]. CAUTION Remember your password. If you forget the password, you cannot use the Win- dows operating system. Creating a password reset disk beforehand is recom- mended.

  • Page 17: On-Screen Manual

    (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual]. Click [start] - [Reference Manual]. Alternatively click [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual]. Important Tips The Important Tips will provide you with the battery information so that you can use the battery pack in the optimum condition to obtain longer operation time.

  • Page 18: Handling And Maintenance

    Handling and Maintenance Operation environment Place the computer on a fl at stable surface. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become damaged. Temperature: Operation : 5 °C to 35 °C {41 °F to 95 °F} Storage : -20°C to 60 °C {- 4 °F to 140 °F} Humidity: Operation : 30% to 80% RH (No condensation)
  • Page 19 Preventing your computer from unauthorized use via wireless LAN/Bluetooth/wireless WAN <Only for model with wireless LAN/Bluetooth/wireless WAN> Before using wireless LAN/Bluetooth/wireless WAN, make the appropriate security settings such as data encryp- tion. Maintenance To clean the LCD panel <Only for model with touchscreen> Use the soft cloth included with the computer.

  • Page 20: Reinstalling Software

    Turn off the computer and insert the CD/DVD drive into the multimedia pocket Reference Manual “Multimedia Pocket”). Turn on the computer, and press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.
  • Page 21 Start the Setup Utility and change the settings as necessary. Perform Windows Update. Press to execute [1. [Recovery]]. The License Agreement screen appears. To cancel partway, press 0 . Press to select [1. Yes, I agree to the provisions above and wish to continue!]. Select the settings.

  • Page 22: Troubleshooting (Basic)

    (The screen stays black.) You have forgotten the pass- Supervisor Password or User Password: Contact Panasonic Technical Support page 33). word. Administrator password: If you have a password reset disk, you can reset the administrator password. Set the disk and enter any wrong password, then follow the on-screen instructions and set a new password.
  • Page 23 A Click [start] - [My Computer] and right-click [Local Disk(C:)], and click [Properties]. B Click [Tools] - [Check Now]. C Select the option in [Check disk options] and click [Start]. Start the computer in Safe Mode and check the error details. When the [Panasonic] boot screen disappears at startup, press and hold...
  • Page 24 Troubleshooting (Basic) Entering Password On the [Enter Password] The computer may be in ten-key mode. NumLk screen, the password cannot If the NumLk indicator lights, press to disable the ten-key mode, and then input. be entered. Even after entering the pass- The computer may be in ten-key mode.
  • Page 25 Turn off the external display. Operate the following steps. <Only for model with GPS> A Restart the computer and press while [Panasonic] boot screen is dis- The cursor cannot be con- played. trolled properly.
  • Page 26 Troubleshooting (Basic) Connecting Peripherals Using a conventional port When using a conventional port replicator (such as the CF-VEB272AW / replicator CF-VEB272A2W), refer to the following cautions instead of the ones in Reference Manual “Port Replicator / Car Mounter”. • Use CF-AA5713A or CF-AA1653A. If you use an AC adaptor other than the above, the computer may become battery operation state, the battery status indicator may blink red, etc.

  • Page 27: Limited Use License Agreement

    DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE. Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intend- ed results, and for the installation, use and results obtained therefrom.
  • Page 28 En utilisant les logiciels, vous vous engagez de manière défi nitive à respecter les termes, clauses et conditions des présentes. Panasonic Corporation a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.

  • Page 29: Specifi Cations

    Specifi cations This page provides the specifi cations for the basic model. The model number is different according to the unit confi guration. To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. To check CPU speed, memory size and the hard disk drive (HDD) size: Run the Setup Utility ( Reference Manual “Setup Utility”) and select [Information] menu.
  • Page 30 , Atheroth Client Utility , Protector Suite QL , Aptio Setup Utility, Hard Disk Data Erase Utility , PC Diagnostic Utility, Concealed mode Utility Panasonic Power Plan Extension Utility Icon Enlarger, Power Saving Utility Wireless LAN ® ® Wireless LAN...
  • Page 31 Click [start] - [Run] and input “c:\util\drivers\ tpm\README.pdf” and click [OK]. This slot is compatible with High-Speed Mode. Operation has been tested and confi rmed using Panasonic SD/SDHC Memory Cards with a capacity of up to 8 GB. Operation on other SD equipment is not guaranteed.
  • Page 32 Operations of this computer are not guaranteed except for the pre-installed OS and the OS which is installed by using the Prod- uct Recovery DVD-ROM provided by Panasonic. Some parts of the software in the Product Recovery DVD-ROM may not be installed depending on a model.

  • Page 33: Limited Warranty

    Panasonic Solutions Company (referred to as “Panasonic”) will repair the products listed below with new or rebuilt parts, free of charge in the U.S.A. or other Panasonic approved location for the period specifi ed below from the date of original purchase in the event of a defect in materials or workmanship.
  • Page 34 Section 2 - Limited Warranty - Software Panasonic Solutions Company (referred to as “Panasonic”) warrants to you only that the disk(s) or other media on which the Pro- grams are furnished will be free from defects in material and workmanship under normal use for a period of sixty (60) days from the date of delivery thereof to you, as evidenced by your purchase receipt.
  • Page 35 No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product, or in environmental conditions other than those specifi ed by PCI or the manufacturer, or if subjected to misuse, neglect, mishan- dling, modifi...
  • Page 36 GARANTIE LIMITÉE – SUPPORTS DES LOGICIELS Couverture – Panasonic Canada Inc. (« PCI ») garantit à l’acheteur original que la ou les disquettes ou tout autre support sur lequel le ou les programmes sont fournis sont exempts de défauts de pièces et de fabrication dans des conditions normales d’utili- sation au Canada, et ce, pour une période de soixante (60) jours suivant la date de réception indiquée sur la preuve d’achat.
  • Page 37 MEMO...
