Front
1 3 5
2 4
4 21
1. Power button / Battery Status Indicator
2. Volume -
3. Volume +
4. Bluetooth Button / Status Indicator
®
5. Source Button
6. NFC touchpoint
7. Source Indicator
8. Button / Status Indicator
9. Equalizer Status Indicator
10. Previous Button
11. Next Button
Top
6 7
12. Play / Pause Button
13. Record Button / Recording Status Indicator
14. (Record) Play / Pause Button
15. MP3/FLAC Shuffle Button / Shuffle Playback
16. MicroSD Slot
17. Micro USB Connector
18. DC Out (USB 1.0A) / USB Flash drive Connector
19. Aux-In / External Microphone In
20. 15V DC In
21. Microphone
2
Overview
8 11 14
10 13
12
9 4
15
IPX6 (IEC 60529)
Indicator
17 19
16
18 20
