- Page 1 YACHT ROUTER NMEA0183 to LAN CONVERTER Installation Manual version 1.0...
- Page 2 YACHT ROUTER Read carefully. For better understanding check video tutorials on our website. Register your product for software update notifications. Thank you.
-
Page 3: Table Of Contents
12.1. Powering Converter ...9 12.2. Connecting NMEA device to NMEA-LAN Converter ...9 12.3. Connecting NMEA-LAN CONVERTER to Yacht Router, LAN Expander or WIFI Extender ...10 HOW TO RECONFIGURE NMEA-LAN CONVERTER ...10 LOCOMARINE LIMITED FACTORY WARRANTY ...11 DECLARATION OF CONFORMITY ...11 FCC INTERFERENCE STATEMENT ...11... -
Page 4: Copyright Notice
Yacht Router and NMEA-LAN Converter are used in a normal manner with a well-constructed network, the Yacht Router device should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. -
Page 5: Safety And Hazard
Failure to observe this instruction may lead to suspension or denial of cellular services to the offender, or legal action or both. Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. The Yacht Router and NMEA-LAN Converter may be used normally at this time. -
Page 6: About Nmea0183 To Lan Converter
NMEA-LAN Converter is a device that will convert data received in NMEA0183 format received from and device to TCP/IP (Transmission Control Protocol/Internet Protocol). Such converted datea can be read by any IP based device and software. NMEA-LAN Converter is perfect solution in combination with any Yacht Router model if you want to access NMEA0183 data on your wired LAN or wireless devices. -
Page 7: What Is In The Package
YACHT ROUTER WHAT IS IN THE PACKAGE When shipped, all devices are wrapped in plastic bags that protect them from humidity. Devices are then placed into a cardboard box. A bag containing accessory items is placed inside the box too. List of all included components is enclosed in the package. -
Page 8: Nmea-Lan Converter Introduction
YACHT ROUTER NMEA-LAN CONVERTER INTRODUCTION LAN PORT for RS232 - for NMEA0183 NMEA0183 - for DC power Power LED TCP/IP equipment socket equipment that use NMEA0183 equipment connection RS232 protocol that use standard RS422 or RS485 protocol INSTALLATION INSTRUCTIONS Install Converter in a dry indoor space that will meet Operating environment range specifications (chapter 9.3 on page 6). Follow the installation procedure as specified in this chapter. -
Page 9: Powering Converter
YACHT ROUTER 12.1. Powering Converter The easiest way it to power it is via PoE injector from Yacht Router, LAN Expander or WIFI Extender as it is shown on the following photo. IMPORTANT: Powering LAN Expander directly from Yacht Router via PoE Ethernet cable is preferred method of connection. -
Page 10: Connecting Nmea-Lan Converter To Yacht Router, Lan Expander Or Wifi Extender
YACHT ROUTER 12.3. Connecting NMEA-LAN CONVERTER to Yacht Router, LAN Expander or WIFI Extender Connect NMEA-LAN CONVERTER to any Vessel Network or Backbone port on Yacht Router, LAN Expander or WIFI Extender. Once connected, it will imidiately start transmit NMEA0183 data. -
Page 11: Locomarine Limited Factory Warranty
In addition, the Locomarine distributor, dealer and partner networks are obliged to support the products irrespective of who sold and installed the product. Locomarine Limited Factory Warranty for Yacht Router products can be downloaded from www.yachtrouter.com...
