  • Page 1 EVERLOC+ XL POWER TOOL ™ Product Instructions...

  • Page 3: Table Of Contents

    5. Tool Preparation 6. Using the Tool 7. Fitting Assembly 8. Important Notes 9. Maintenance Notes 10. Troubleshooting Notes 11. Safety Warnings For updates to this publication and the most current technical instructions, safety information and manufacturer’s recommendations, visit na.rehau.com/resourcecenter...

  • Page 4: Scope

    EVERLOC is a registered trademark of REHAU. ® The contractor should also review the REHAU PEXa Limited Warranty MAKITA is a trademark of Makita Corporation, or an affiliate thereof. ® and pertinent REHAU Technical Guidelines prior to installation of a REHAU hydronic system.

  • Page 5: Parts / Accessories

    - MAKITA 18V Li-ion battery (2 batteries per kit) - MAKITA 18V Li-ion charger 120VAC - Pipe cutter - Grease tube - Cleaning brush - Tool case - Operating instructions Accessories - EVERLOC+ XL Expander Tool Standard Kit, Art. 106096-001 - EVERLOC+ XL Expander Base Tool, Art. 105419-001...

  • Page 6: Technical Data / Equipment Description

    3. TECHNICAL DATA / EQUIPMENT DESCRIPTION Technical Data Battery voltage Battery technology MAKITA Lithium-ion ® ® BL1830B, BL1840B or BL1850B Battery charge time Approx. 30 mins. for BL1840B with DC18RC Tool and battery 14°F to 104°F operating temperature (-10°C to +40°C) Noise level <...

  • Page 7: Certifications

    If the red LED slowly flashes for about 20 seconds upon completion of a work operation, this means maintenance needs to be carried out. slow flash The tool should be sent to a REHAU authorized service center as soon as possible. Battery is empty!

  • Page 8: Using The Tool

    3. Slide the expansion adapter into the correct slot. prior to every use. Damaged tool components must not be used. Damaged tools should be sent back to the REHAU authorized service center for repair. WARNING! Improper handling of the tool can result in injury and property damage.
  • Page 9 6. Install the handle to the tool. The handle must be installed 8. If necessary, rotate the tool housing to make it easier to assemble securely before operation. the fitting. WARNING! Always hold the tool firmly with your second hand on the handle to avoid trapping your fingers from moving parts.
  • Page 10 11. If necessary, remove the expansion adapter to make it easier to 14. If necessary, press the reset button to return tool to initial compress the fitting assembly. Press the release lever and slide position. the adapter off the slot to remove. 15.

  • Page 11: Fitting Assembly

    7. FITTING ASSEMBLY Refer to the REHAU EVERLOC+ Compression-sleeve System Product Instructions for the assembly of EVERLOC+ fittings with this tool. 8. IMPORTANT NOTES Failure to observe these precautions may result in property damage - Do not operate the tool in extreme hot or cold conditions. Processing and damage to the tool.

  • Page 12: Troubleshooting Notes

    122°F (50°C). Damage can result. Transportation - Transport and store the tool with a fitted expander head to reduce Universal tool case for the storage of the EVERLOC+ XL power tool and components risk of injury or contamination. 10. TROUBLESHOOTING NOTES...

  • Page 13: Safety Warnings

    11. SAFETY WARNINGS The term "power tool" in the warnings refers to the mains-operated (corded) power tool or battery operated (cordless) power tool.
  • Page 16 Instructions de Sécurité Le terme "outil électrique" se réfère à votre outil alimenté par le réseau (branché) ou par la batterie (sans fi l).
  • Page 20 The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made as to its accuracy, suitability for particular applications or the results to be obtained therefrom. Before using, the user will determine suitability of the information for user’s intended use and shall assume all risk and liability in connection therewith. © 2017 REHAU...
