Generac Power Systems RTS Technical Manual page 19

ITEM PART NO.
1 0D9618
2 074908
3 0E3375
4 0F1252
5 022097
6 0A1495
7 0G6025
(5) 8 063617
(5) 9 0D2806
10 073590A
(5) 11 048850
12 0A1661
13 0C4449A
14 090388
15 0G51590AL08
16 0G51740AL08
17 0G55920AL08
(4) 18 0F0668
19 0G5968B
0G7101
20 067210A
21 0A9457
22 0A9517
23 0C2262
(1) 24 0E6190
25 081221
(3) 26 0G3274
27 0E6523
28 0C6748
29 026579
30 043180
31 085296
32 0F6165
33 085889
34 022473
35 058000E
36 0E6193
(2) 37 0E6155
38 0D6162
39 0E6303
41 0E6303B
42 0E6304
(1) CENTER DECAL ON INSIDE OF THE COVER (ITEM #16)
(2) SUPPLIED WITH TRANSFER SWITCH ITEM #1
(3) PLACE DECAL ON OUTSIDE OF COVER, LOWER RIGHT CORNER.
(4) NOT SHOWN ON THIS ASSEMBLY, CENTER DECAL ON FRONT OF COVER, 7" FROM TOP OF ENCLOSURE.
(5) SUPPLIED WITH HARNESS (P/N 0G6025)
Section 7 — Exploded Views and Parts List
200A Transfer Switch Assembly – Drawing No. 0G6037$-D
QTY. DESCRIPTION
1 XFRSW HSB 200A 2P 250V
5 SCREW HHTT M5-0.8 X 10 BP
6 LUG SLDLSS 250-#6 AL/CU
6 SCREW BHSC 1/4-20 X 3/8
10 WASHER LOCK M6-1/4
4 SCREW HHTT M4-0.7 X 10 BP
1 WIRING HARNESS HSB (NOT SHOWN)
1 RELAY PNL 12VDC DPDT
1 FUSEBLOCK 30A 600V 2 POLE
2 FUSE 5A X BUSS HLDR73591
1 BLOCK, TERM 20A 5 X 6
2 RIVET, POP .156 X .67
1 ASSY NEUTRAL BL150-200A
2 SCREW HHTT M6-1.0 X 12 MM
1 ENCLOSURE, 100/200A TRANSFER SWITCH
1 COVER, TRANSFER SWITCH
1 SUBPLATE, 100/200A XFER SW
1 DECAL, FRONT COVER ATS NEMA3R
REF. DECAL,XFER SW NON 200A 120/240
REF. DECAL TRANSFER SWITCH DATA 200
1 DECAL, GROUNDING LUG
1 DECAL, NEUTRAL
1 DECAL, MANUAL 5A FUSE
1 DECAL, TERMINAL STRIP
1 DECAL, TEST SEQUENCE (NOT SHOWN)
1 DECAL, UL LIST HSB
1 DECAL, LIVE CIRCUIT ENG/FRN/SPN
1 GROUND BAR (5) 4-14 AWG CONN
2 NUT HEX LOCK M4-0.7 SS NYL INS
2 WASHER SHAKEPROOF EXT #8 STEEL
2 WASHER FLAT M4
1 SCREW HHC 1/4-20 X 1/2 SS
1 WASHER M6 NYLON INT HEX
4 NUT HEX 1/4-20 SS
8 WASHER FLAT 1/4-M6 ZINC
1 NUT TRIC 1/4-20 X .525
1 BRACKET, ARM EXTENDER
1 ARM EXTENDER PIN
2 RIVET POP .156 X .362 AL
2 WIRE-A
1 WIRE-E1
1 STRAIGHT SPADE CONNECTOR
RTS "HS" Type Transfer Switch
17
