SI-002 User Manual
Version 1.0 , Jun 2016
Service and usage information for
SI-002
Written by Raiden Lan

Advertisement

Table of Contents
loading

Related Manuals for ICP DAS USA SI-002

Summary of Contents for ICP DAS USA SI-002

  • Page 1 SI-002 User Manual Version 1.0 , Jun 2016 Service and usage information for SI-002 Written by Raiden Lan...
  • Page 2 If you have any problem, please feel free to contact us. You can count on us for quick response. Email: service@icpdas.com SI-002 User Manual, version 1.0 Page: 2 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 3: Table Of Contents

    2. Getting Started ................13 2.1. Connecting to Network, PC and Power ............13 2.2. Installing the MicroSIP Utility ..............14 2.3. Using SI-002 connect to MicroSIP Utility ............ 15 3. Web Applications ................19 3.1. Connect to SI-002 web site ................ 19 3.1.1.

  • Page 4: Introduction

    1. Introduction SI-002 is video intercom door station that supports VoIP technology and SIP communication protocol. With HA-401 product, households can see visitors' images and have a video conversation with them when the door bell ringing, after identity confirmation, they can open the door remotely. Using...

  • Page 5: Features

    Digital Input Channels Input Type Dry contact (Source) Dry Contact Level Off Voltage Level: On Voltage Level: Open Close to GND SI-002 User Manual, version 1.0 Page: 5 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
  • Page 6 Power Supply +10 V ~ +48 V Input Range Power Consumption 1.5 W @ 24 V Max. Protection Reverse Polarity Protection SI-002 User Manual, version 1.0 Page: 6 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 7: Dio Wiring Connection

    1.3. DIO Wiring Connection SI-002 User Manual, version 1.0 Page: 7 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 8: Overview

    Here is a brief overview of the components and its descriptions for module status. 1.4.1. Front Panel Speaker Camera Microphone Call Button SI-002 User Manual, version 1.0 Page: 8 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 9: Back Panel

    Current status High brightness On line Low brightness Off line 1.4.2. Back Panel Ethernet Port J1 Connector (Pin 1 ~ 8) SI-002 User Manual, version 1.0 Page: 9 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
  • Page 10 An Ethernet port is an opening on SIP network equipment that Ethernet cables plug into. Ethernet ports accept cables with RJ-45 connectors.  J1 Connector SI-002 User Manual, version 1.0 Page: 10 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
  • Page 11 GND of Power Supply Digital Input CH0 Digital Input CH1 DI.GND Digital Input GND RL.NO Relay Normally-Open RL.COM Relay Common RL.NC Relay Normally-Closed SI-002 User Manual, version 1.0 Page: 11 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 12: Dimensions

    1.5. Dimensions All dimensions are in millimeters. SI-002 User Manual, version 1.0 Page: 12 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 13: Getting Started

    SI-002. 2.1. Connecting to Network, PC and Power The SI-002 is equipped with an RJ-45 Ethernet port for connection to an Ethernet hub/switch and PC. Please set RSW of SI-002 and PC Network as below.

  • Page 14: Installing The Microsip Utility

    2.2. Installing the MicroSIP Utility The MicroSIP Utility is a open source portable SIP softphone based on PJSIP stack for Windows OS. The user can use this Utility to connect with SI-002. Step 1: Get the MicroSIP Utility tool The MicroSIP Utility can be obtained from below link: http://www.microsip.org/downloads...

  • Page 15: Using Si-002 Connect To Microsip Utility

    2.3. Using SI-002 connect to MicroSIP Utility When RSW of SI-002 set to B, SI-002 will use a default IP settings to connect PC. The default IP settings are as follows: SI-002 IP Address 192.168.72.30 Subnet Mask 255.255.0.0 PC side IP Address 192.168.255.1...
  • Page 16 Select audio codec (enable PCMU, PCMA, GSM) and video codec (enable H.263+) Step 3: Making a Phone call Press call button of SI-002 to call MicroSIP and then the MicroSIP will show Incoming call. Press "Answer with video" button of MicroSIP to answer call. SI-002 User Manual, version 1.0 Page: 16 Copyright ©...
  • Page 17 Step 4: Answer call Press "Answer with video" button of MicroSIP to answer call. The PC will show local video and remote video and hear voice from SI-002. SI-002 User Manual, version 1.0 Page: 17 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
  • Page 18 SI-002 User Manual, version 1.0 Page: 18 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 19: Web Applications

    3. Web Applications The SI-002 contains an advanced web configuration system that provides users with configure SI-002 through a standard web browser. 3.1. Connect to SI-002 web site 3.1.1. Installing the eSearch Utility The user can get current IP of SI-002 by eSearch Utility.
  • Page 20 Double-click the eSearch Utility shortcut. Step 3: Choose “Search Servers” button After pressing "Search Servers' button, that will search all of the SI-002 modules on your network. After search, it will show all of SI-002 modules, the user can get IP of SI-002 SI-002 User Manual, version 1.0...

  • Page 21: Connecting

    3.1.2. Connecting You can log in to the SI-002 web site from any computer by web browser. Before you open the web browser to configure the module, it needs to connect the SI-002 and your PC to the same sub network, as shown in the below.

  • Page 22: Web Configuration

    3.2. Web Configuration When the browser connects with the SI-002, the first page is shown in the below. The left side is the function menu and the other side is the setup page. SI-002 User Manual, version 1.0 Page: 22 Copyright ©...

  • Page 23: Function Menu

     Audio Config  RFID Config  Information Reboot The “Reboot” button can provide the user to restart the SI-002 module. 3.2.2. Login The user login and logout interface 3.2.3. User Account The user account setting limits which user can configure the module settings. The super user (Account 1, name=”root”, password=”icpdas”) is an only the user that...

  • Page 24: Standard Config

    3.2.4. Standard Config When changing the setting in this page, the user must restart the SI-002 to enable new settings.  NetWork a. Intercom number (IP)：The user can set the Intercom number that the SI-002 wants to connect to. This field can be IP (ex: 192.168.255.1) or Intercom number with PBX IP (ex: 0101@192.168.255.1).

  • Page 25: Audio Config

    3.2.5. Audio Config The user can set the output volume and input volume in this page. When changing the setting in this page, the user must restart the SI-002 to enable new settings.  Output Volume：0~10 The maximum output volume is 10.

  • Page 26: Rfid Config

    RFID history by "RFID Log" button.  Set White List The user can fill Tag ID of RFID in this page, if SI-002 detect the same Tag ID, it will drive the relay from off to on status.  RFID Log In the page, the user can get RFID history, It will show time and Tag ID.

  • Page 27: Information

     Mac Address：Show current Mac address.  License Verify：Show the result that the license is verified. If it shows “OK”, it SI-002 User Manual, version 1.0 Page: 27 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...

  • Page 28: Si-002 User Manual, Version 1.0 Page

    SI-002 User Manual, version 1.0 Page: 28 Copyright © 2016 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
