Quick Start Guide

TDTTP3300-RD
Reference Design
TDTTP3000-RD_0.1
02/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDTTP3300-RD and is the answer not in the manual?

Questions and answers

Summary of Contents for Transphorm TDTTP3300-RD

  • Page 1: Quick Start Guide

    Quick Start Guide TDTTP3300-RD +1 805 456 1300 Reference Design transphormusa.com TDTTP3300-RD For evaluation purposes only Design files and more at transphormusa.com/tp33kit 02/2018 © 2018 Transphorm Inc. All rights reserved. TDTTP3000-RD_0.1...
  • Page 2 Equipment Needed Typical Performance Curves g The TDTTP3300-RD board g High-voltage AC power supply for input g Electronic/resistive load • Power range: 350W to 3300W @230V 150W TO 1650W @115V Cautions and Warnings This reference design is intended as an educational tool for end customers developing their own bridgeless totem-pole PFC products.
  • Page 3 Step 2: Power-up the Board g Connect an electronic/resistive load to the corresponding marking (CN2). The requirements for the resistive load are: • At 115V input: 150W to ≤1250W • At 230V input: 350W to ≤3300W g With the high-voltage power off, connect the high-voltage AC power input to the corresponding marking (CN1) on the PCB;...
  • Page 4 Step 0: Before Power Up g Connect XDS100-V2 emulator to the PFC board (JTAG) and to computer USB port The TDTTP3300-RD is intended as an educational tool for end customers developing g Apply 5V auxiliary power(GND-TP58, 5V-TP61) their own bridgeless totem-pole PFC products. The reference board kick starts end product development by providing a digital control design framework.
