CONTENT Your canopy hood Description Introduction Controls Maintenance Cleaning Removing the grease filters Replacing the carbon filter Changing the light bulbs Installation General Electrical connection Mounting the canopy hood Technical specifications Appendice Disposal of appliance and packaging EN 3...
YOUR CANOPY HOOD Description Switch lighting on/off Switch on/off + fan speed 1 Switch on fan speed 2/switch on carbon filter indicator Switch on fan speed 3/reset grease filter indicator Switch on intensive setting Filter indicator Introduction This user manual gives you a quick overview of all the possibilities offered by the appliance.
Controls Switching the fan on and off • Use the On/Off button (T1) to switch on the fan and select the extractor setting desired with the ‘T2’, ‘T3’ or ‘T4’ buttons. The LED indication on the buttons shows which setting has been selected.
Page 6
Carbon filter indicator • Press and hold the ‘T2’ button for 3 seconds • to activate the carbon filter contamination indication. The LED indication on the ‘T2’ button flashes 2 times in confirmation. • After the extractor hood has been in use for 200 hours with the carbon filter contamination indication activated, the ‘S1’...
MAINTENANCE Cleaning Attention! Before performing any maintenance operation, isolate the hood from the electrical supply by switching off at the connector and removing the connector fuse. Or if the appliance has been connected through a plug and socket, then the plug must be removed from the socket.
MAINTENANCE Grease filters Removing the grease filters Switch off the electricity! Remove the plug from the socket or switch the electricity off at the mains. Open the panel and pull the special handle to remove the filter. Replacing the carbon filter The carbon filter must always be used if the cooker hood is not ducted.
INSTALLATION General This appliance should be connected to the power supply by a recognized fitter who is familiar with, and works according to the correct safety regulations. This appliance meets the European requirements. Important that you know: • The minimum distance between the supporting surface for the cooking vessels on the gashob and the lowest part of the range hood must be not less than 65 cm.
INSTALLATION Electrical connection This appliance is manufactured in class I, it must therefore be connected to the earth system. Make sure the supply voltage ratings correspond with those stated on the appliance data plate. The connection to the mains is carried out as follows: BROWN = phase L BLUE = phase N...
Page 11
INSTALLATION Montage • Open the panel. • Remove the grease filter. • Interrupt the plug connection of the controls. • First remove the 6 screws, followed by the frame. • Use a saw to create a recess in the bottom side of the cupboard (at a distance of at least 650 mm from a gas hob).
Page 12
TECHNICAL SPECIFICATIONS Hood type CC4525S Built in hood Type / Approval 4000 Control type Electronic push buttons Width Supply (Voltage, frequency) 220~240 V / 50 Hz Power Power motor Power lights (W) 2 x LED 1 W Level 1 330 m³/h, 53 dB(A), 320 Pa Air flow, Noise, Pressure...
APPENDICE Disposal Disposal of appliance and packaging By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The local authorities can provide you with the relevant information.
