Page 1: Instructions For Use
Instructions for use Cooker hood CI41238G / ES12ENTFE... - Page 2 Manual EN 3 - EN 23 Pictograms used: Important information...
-
Page 3: Table Of Contents
CONTENTS Your cooker hood Introduction Description Operation Cleaning filters Maintenance Cleaning Installation General Connection Build-in dimensions Technical specifications Appendix Disposal EN 3... -
Page 4: Your Cooker Hood
YOUR COOKER HOOD Introduction On reading these user manuals you will soon become familiar with the features of this appliance. Please read the appliance’s safety and maintenance instructions. Please retain the operating and installation instructions as these may be useful for future reference. Please read the separate safety instructions prior to use. -
Page 5: Use
Description 1. Switching on/off and dimming the lighting 2. Reducing air extraction capacity and switching off 3. Cleaning carbon filter indicator 4. Cleaning grease filter indicator 5. Display status 6. Timer function indicator 7. Clean Air function indicator 8. Switching on and increasing air extraction capacity 9. -
Page 6: Operation
Operation Switching extraction on and off • Press the ‘+’ button (8). The cooker hood will switch on at the lowest setting. • Press the ‘+’ button (8) again to set a higher extraction setting. Press and hold the ‘+’ button (8) for 2 seconds to select the highest setting (boost) (see switching on intensive setting). - Page 7 Switch on intensive setting: • Press and hold the ‘+’ button (8) for approximately 2 seconds. The intensive setting (setting ‘P’) is switched on for ten minutes (depending on the model). The display will flash (5) during this period. The original extraction setting will be reactivated after this period.
-
Page 8: Cleaning Filters
Cleaning filters Saturation grease and carbon filters The filters should be replaced or cleaned when the grease filter indicator (4) or the carbon filter indicator (3) are lit. Grease filter The grease filter indicator (4) will flash after 30 operating hours. •... -
Page 9: Maintenance
MAINTENANCE Cleaning Important! For all maintenance first switch off the mains power to the cooker hood by pulling the plug out of the socket or by turning off the home's master switch. The hood needs to be cleaned regularly, both inside as well as outside (at least in the same frequency as the grease filter cleaning). - Page 10 MAINTENANCE Removing cassette filter Switch off the motor and lighting. Grasp the front of the glass plate with both hands and pull it carefully (using some force) out of the seal. Tilt the glass plate downwards. Open the filter’s access hatch. Remove the filter from the hood.
- Page 11 MAINTENANCE Active carbon filters: The regenerable active carbon filter must be washed by hand with neutral cleaning products, or in the dishwasher at a maximum temperature of 65 °C (the washing should be done without any plates, dishes, cups, etc. in the machine). Remove the excess water without damaging the filter, remove the holder and let the filter dry in the oven for at least 15 minutes at a maximum temperature of 100 °C.
-
Page 12: Installation
INSTALLATION General This appliance should be connected to the mains power by a registered installer, who knows and applies the correct safety specifications. We hereby declare that our products satisfy the applicable European directives, orders and regulations, as well as the requirements stated in your country. -
Page 13: Connection
INSTALLATION Connection Electrical connection This appliance is manufactured in class I, it must therefore be connected to the earth system. Make sure the supply voltage ratings correspond with those stated on the appliance data plate. The connection to the mains is carried out as follows: BROWN = phase L BLUE = phase N... -
Page 14: Build-In Dimensions
INSTALLATION Build-in dimensions Installation height: The minimum distance between a gas hob’s pan supports and the lower edge of the hood should be 65 cm. For use with an electric, ceramic or induction hob this distance should be at least 55 cm. 55 cm 65 cm max 150 cm... - Page 15 INSTALLATION This hood could be heavy, therefore we advise to install this hood with at least two people. Fig.1 Fig.2 - Unpack the frame and remove the two - Take the template and screws A to separate the top section from place this against the ceiling with the arrow the bottom section (Fig.1).
- Page 16 INSTALLATION Fig.5 Fig.6 - To install the cooker hood fit the electric - Secure the bracket with the four screws G, unit D upright. as indicated in Figure 6. EN 16...
- Page 17 INSTALLATION - Secure the air outlet pipe H (not supplied) to the connection flange F as indicated in Figure 7. Fig.7 Fig.8 - Take the bottom section of the frame C and fix this to the motor housing (Fig.8). EN 17...
- Page 18 INSTALLATION - Fix the construction C to the motor housing Fig.9 using the 4 screws E (Fig.9). 55 cm 65 cm Fig.10a - Take the top section of the frame B and slot this in the bottom section C. - Adjust the height according to the sizes in Figure 10a and secure these with the 8 screws Fig.10 G supplied.
- Page 19 INSTALLATION - Connect the bottom shaft A with the top one B Fig.11 as indicated in Figure 11. EN 19...
- Page 20 INSTALLATION click Fig.13 - Please note! Secure the hood directly onto the bracket B with the 6 screws D (Fig.13). Fig.12 - Tilt the hood as indicated in Figure 12 – step 1. - Use the two pivot pins C that are Fig.14 already present in the construction to hang the hood on the bracket B.
- Page 21 INSTALLATION Fig.15 Fig.16 - Connect the pipe H (not supplied) to the air - Insert the plug into the disconnected wall outlet opening A (Fig.15). socket (Fig.16). - Test if the appliance operates correctly. Fig.17 - Connect the shaft B to the ceiling plate using the two screws F (Fig.17).
- Page 22 TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Hood type CI41238G Type / Approval Island / ES12ENTFE Control type Touch control Width 120 cm Supply 220-240 V, 50/60 Hz Voltage, Frequency Power 260 W Power motor 240 W Power lights 2 x LED 10 W Level 1 248 m³/h, 40 dB(A), 170 Pa...
-
Page 23: Disposal
APPENDIX Disposal Disposal of packaging and appliance Sustainable materials have been used during manufacture of this appliance. This appliance must be disposed of responsibly at the end of its life cycle. Ask your local authorities for more information about how to do this. The appliance packaging is recyclable. - Page 24 EN 24...
