- Page 1 SY-HS12 4K HDMI Splitter Installation Guide SY-HS12 4K HDMI Splitter 1x2 SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom – – Tel: +44 (0) 161 868 3450 Fax: +44 (0) 161 868 3459 www.sy.co.uk...
-
Page 2: Panel Description
SY-HS12 4K HDMI Splitter The SY-HS12 is an HDMI splitter that allows the user to repeat a single HDMI or DVI source to 2 displays simultaneously. It is compliant with HDMI 1.4 & HDCP1.4 and supports all HDMI and DVI resolutions up to 4K & 1080p 3D. The SY-HS12 will automatically recognize the resolution and HDCP compliance status of the input signal. -
Page 3: Rear Panel
The following diagram illustrates the typical input and output connections for the SY-HS12: Connection Procedures Connect a HDMI / DVI source device (e.g. BluRay DVD) to the HDMI INPUT socket of SY-HS12 with HDMI cable. Connect HDMI displays to HDMI OUTPUT sockets of SY-HS12 with HDMI cable. -
Page 4: Edid Management
(detecting from output 1~2). For example: when output 1 connects with a 1080p display, SY-HS12 will select 1080p as output resolution and distribute 1080p signal to displays connected to output 1~2. - Page 5 3840 x 2160i @ 25Hz 3840 x 2160i @ 30Hz 1080p 3D @ 60Hz Note: SY-HS12 supports 4k & 3D HDMI signals, please use quality HDMI cables that are compliant with HDMI1.4 for better transmission when connecting 4K or 3D sources. www.sy.co.uk...
-
Page 6: Safety Instructions
Online registration of this product is required to activate the full three year extended warranty. For full details please refer to our Terms and Conditions. SY Product warranty is automatically void under any of the following conditions: The product is already outside of its warranty period ... - Page 7 SY-HS12 4K HDMI Splitter NOTES www.sy.co.uk...
