Echo PE-311 Operator's Manual

Power edger
Hide thumbs Also See for PE-311:
Table of Contents

Advertisement

Quick Links

Download this manual
Power Edger
Operator's Manual
MODEL
Read rules for safe operation and instructions carefully. ECHO provides an
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation.
X7502129900
PE-311
WARNING
P
OWER
O
'
M
PERATOR
S
DANGER
X750009590
12/06
E
DGER
1
ANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PE-311 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo PE-311

Summary of Contents for Echo PE-311

  • Page 1 ANUAL Power Edger Operator's Manual MODEL PE-311 WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X750009590 X7502129900 12/06...

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual, and the SAFETY MANUAL you found in the same package. You will find both easy to use, and full of helpful operating tips and SAFETY messages.

  • Page 3: Safety

    OWER DGER PERATOR ANUAL AFETY ANUAL AFETY YMBOLS AND MPORTANT NFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.
  • Page 4 Wear no-slip, heavy duty work gloves to improve your grip on the edger handles. Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing Wear snug fitting, durable clothing;...
  • Page 5 OWER DGER PERATOR ANUAL Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment

    Use only ECHO approved attachments. Serious injury may result from the use of a non approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 7: Description

    Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER- ING instructions for specific information.
  • Page 8 POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System, and Recoil Starter. GRIP - Rear (right hand) handle. THROTTLE TRIGGER LOCKOUT - This lever must be held during aceleration. Operation of the throttle trigger is prevented unless throttle trigger lockout lever is engaged. STOP SWITCH - "SLIDE SWITCH"...

  • Page 9: Contents

    OWER DGER PERATOR ANUAL ONTENTS After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. __ 1 Edger Assembly __ 1 Power Head...

  • Page 10: Throttle Linkage And Ignition Leads

    / low idle extremes are adjusted properly. Tighten nut (A). If adjustment cannot be achieved by adjusting nuts, consult with your Echo Dealer for correct adjustment procedure. Connect 2 ignition leads from throttle cable (C, D) tubing to 2 ignition leads (C, D) on engine.

  • Page 11: Operation

    Universal 2-Stroke Oil meets these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD and J.A.S.O. FC certified oil, such as Echo premium Power Blend will void the two-stroke engine warranty. (Emission related parts only are covered for two years, regardless of two- stroke oil used, per the statement listed in the Emission Defect Warranty Explanation.)
  • Page 12 Mixing Instructions Fill an approved fuel container with half of the required amount of gasoline. Add the proper amount of 2-stroke oil to gasoline. o l l Close container and shake to mix oil with gasoline. Add remaining gasoline, close fuel container, and remix. IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions.

  • Page 13: Starting Cold Engine

    DANGER The cutting attachment should not rotate at idle. If attachment rotates, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. Stop Switch Move stop switch button (A) forward away from the STOP position.

  • Page 14: Starting Warm Engine

    Move stop switch (A) backward to STOP position. WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using edger again.

  • Page 15: Operating Techniques

    OWER DGER PERATOR ANUAL OPERATING TECHNIQUES Before edging, water the area to soften the ground to make edging easier. Before edging, check the area and remove all obstacles and objects that could be thrown. Plan to edge regularly to make it easier to keep a neat edge and to avoid having to make more than one pass.

  • Page 16: Maintenance

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs.

  • Page 17: Air Filter

    OWER DGER PERATOR ANUAL WARNING DANGER Allow the unit to completely cool before performing any mainte- nance activity. AIR FILTER Tools required: 25-50 mm (1 or 2 in.) Cleaning brush. Parts required: 90030 REPOWER AIR & FUEL FILTER KIT. Close choke (Cold Start Position [ ]).

  • Page 18: Spark Plug

    SPARK PLUG Level 2. Tools required: T-Wrench, feeler gauge, soft metal brush Parts Required: REPOWER Tune-Up Kit P/N 90075 IMPORTANT Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada) otherwise severe engine damage may occur. Remove spark plug and check for fouling, worn and rounded center electrode.

  • Page 19: Exhaust System

    OWER DGER PERATOR ANUAL Use the brush to remove dirt from the cylinder fins. Assemble components in reverse order. EXHAUST SYSTEM Spark Arrestor Screen Level 2. Tools Required: Cross Head Screwdriver, Soft metal brush, 4 mm Hex Wrench Parts Required: Screen, Gaskets Remove three (3) screws from muffler cover and remove.

  • Page 20: Carburetor Adjustment

    See page 24, "Specifications," for correct idle speed. Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). NOTE Every unit is run at the factory and the carburetor is set in compli- ance with emission regulations. This carburetor does not have acceleration and high speed adjustment needles.

  • Page 21: Blade Replacement/Lubrication

    BLADE REPLACEMENT GEAR CASE LUBRICATION Level 1. Tools Required: T-wrench, Locking Tool, Needle Nose Pliers, 13 mm Open End Wrench Parts Required: ECHO LUBE 8 oz. (P/N 91014) or Lithium Base ® Grease, Blade P/N 69601552632, split pin P/N 90030020022 NOTE Grease gear case every 15 - 25 hours of use.

  • Page 22: Troubleshooting

    ROUBLESHOOTING n i l n i l n i l t l i f l f f t ' n c t i c t i t n I c t i i t c t l i f t l i f / s t t l i f t l i f...

  • Page 23: Storage

    OWER DGER PERATOR ANUAL TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following:...

  • Page 24: Specifications

    PECFICATIONS MODEL ----------------------------------------------------- PE-311 Length ------------------------------------------------------- 1790 mm (70.5in.) Width -------------------------------------------------------- 300 mm (11.8 in.) Height ------------------------------------------------------- 310 mm (12.2 in.) Weight (dry w/cutter head) ------------------------------- 7.2 kg (15.9 lb.) Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine Bore ---------------------------------------------------------- 36.0 mm (1.42 in.)
  • Page 25 OWER DGER PERATOR ANUAL NOTES...
  • Page 26 NOTES...
  • Page 27 OWER DGER PERATOR ANUAL NOTES...

  • Page 28: Servicing Information

    • Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
