Trapeze MP-620 Quick Start Manual

Hide thumbs Also See for MP-620:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual, Installation Manual
Outdoor Mobility Point Quick Start Guide v.7.1
Trapeze Networks, Inc.
For the most current version of all documentation, go to
5753 W. Las Positas Blvd.
www.trapezenetworks.com
Pleasanton, CA 94588
Tel: +1 925-474-2200
Fax: +1 925-251-0642
Toll-Free: 877-FLY-TRPZ (877-359-8779)
Part Number: 730-9502-0293 Rev. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trapeze MP-620

Summary of Contents for Trapeze MP-620

  • Page 1 Outdoor Mobility Point Quick Start Guide v.7.1 Trapeze Networks, Inc. For the most current version of all documentation, go to 5753 W. Las Positas Blvd. www.trapezenetworks.com Pleasanton, CA 94588 Tel: +1 925-474-2200 Fax: +1 925-251-0642 Toll-Free: 877-FLY-TRPZ (877-359-8779) Part Number: 730-9502-0293 Rev. B...
  • Page 2 Trapeze Networks This guide provides basic hardware installation instructions for MP access point models MP-620, MP-622, and MP-632. The MP-620, MP-622, and MP-632 are suitable for installation outdoors Warning! Installation must be performed by qualified service personnel only. Read and follow all warning notices and instructions marked on the product or included in the documentation.
  • Page 3 Trapeze Networks ¡Advertencia! A instalação dever ser realizada exclusivamente por pessoal de serviço qualificado. Leia e siga todas as notas de advertência e instrucões no produto ou na documentação. Antes de instalar o produto deverá ler a parte restante do presente documento.
  • Page 4 Trapeze Networks Outdoor Mobility Point Quick Start Guide v.7.1...
  • Page 5 PDF format. MP-620 The MP-620 provides wireless access point services for clients in the local LAN area, and can provide point-to-point or point-to-multipoint wireless bridge links between remote Ethernet LANs. The MP is housed in a weatherproof enclosure for mounting outdoors and includes brackets for attaching to a wall, pole, radio mast, or tower structure.

  • Page 6: Package Checklist

    ❑ terminated. Contact Trapeze Networks if there are any incorrect, missing or damaged parts. If possible, retain the carton, including the original packing materials. Use them again to repack the product in case there is a need to return it.

  • Page 7: Installing And Connecting An Outdoor Mp

    If you are using RingMaster to plan your Trapeze Networks Mobility System installation, you might want to create and verify a network plan for the entire Trapeze network installation and generate an MP work order, before installing MP access points. A network plan and the MP work orders...

  • Page 8: Wind Velocity

    Ethernet Cabling When you have determined a suitable location for the MP-620, MP-622, or MP-632, you must plan a cable route from the MP outdoors to the power injector module indoors. Consider these points: The Ethernet cable length should never be longer than 328 ft (100 m) over CAT5, CAT5e, or CAT6 ❑...

  • Page 9: Mp Radio Safety Advisories

    Installing an MP-620 The MP-620 includes a bracket kit for mounting the unit to a 1.5 to 2 inch diameter steel pole or tube. The pole-mounting bracket allows the unit to be mounted to part of a radio mast or tower structure.

  • Page 10: Using The Wall-Mounting Bracket

    Use the included nuts to tightly secure the MP-620 to the bracket. Mounting on Larger Diameter Poles In addition, there is a method for attaching the pole-mounting bracket to a pole that is 2 to 5 inches in diameter using an adjustable steel band strap (not included in the kit).

  • Page 11: Connecting External Antennas

    5 GHz antenna. Perform these steps: Mount the external antenna to the same supporting structure as the MP-620, within 10 ft (3 m) distance, using the bracket supplied in the antenna package. If you are installing the optional lightning arrestor for an outdoor antenna, perform the following steps.
  • Page 12 Figure 1–4. Attaching the Ground-Wire Terminal Lug, Lock Washer, and Hex Nut to the Lightning Arrestor c. Connect one end of the short RF coaxial cable to the MP-620 N-type connector, and connect the other end to the lightning arrestor.

  • Page 13: Connecting Cables To The Unit

    Figure 1–5. Connecting External Antennas to the MP-620 Connecting Cables to the Unit Attach the Ethernet cable to the Ethernet port on the MP-620. The Ethernet cable included with the package is 30 m (100 ft) long. To wire a longer cable (maximum 100 m, 325 ft), use the connector pinout information in Appendix B.

  • Page 14: Connecting The Outdoor Power Supply

    MX and verify the link. You can use the CLI or RingMaster to configure an MP connection. If you are installing the MP-620 as a Mesh AP in a WLAN Mesh or wireless bridge configuration, you must configure the MP connection before deploying the MP-620 in its final location.

  • Page 15: Aligning Antennas For Bridge Or Mesh Links

    To start, you can just point the antennas at each other, using binoculars or a compass to set the general direction. For accurate alignment, you must connect a DC voltmeter or RSSI meter to the BNC connector on the MP-620 and monitor the voltage as the antenna moves horizontally and vertically.
  • Page 16 MP radio, link calibration packets are sent at a rate of 5 per second. When the MP-620 receives a link calibration packet, it emits a voltage to the RSSI meter proportional to the received signal strength of the packet. This can aid in positioning the MP-620 where it has a strong signal to the MP sending out the packets.
  • Page 17 Voltmeter Pan the antenna horizontally back and forth while checking the RSSI voltage. If using the pole-mounting bracket with the MP-620, you must rotate the mounting bracket around the pole. Other external antenna brackets may require a different horizontal adjustment.
  • Page 18 Trapeze Networks Installing an MP-622 The MP-622 includes a bracket kit for mounting the unit to a 1.5 to 2 inch diameter steel pole or tube. The pole-mounting bracket allows the unit to be mounted to part of a radio mast or tower structure.
  • Page 19 Trapeze Networks Place the V-shaped part of the bracket around the pole and tighten the securing nuts just enough to hold the bracket to the pole. (The bracket may need to be rotated around the pole during the alignment process.) Figure 1–10.
  • Page 20 Trapeze Networks Attach the adjustable rectangular plate to the bridge with supplied screws. Attach the bridge with bracket to the plate already fixed to the pole. Use the included nuts to secure the wireless bridge to the pole bracket. Note that the wireless bridge tilt angle may need to be adjusted during the antenna alignment process.
  • Page 21 Trapeze Networks Mounting on Larger Diameter Poles There is also a method for attaching the pole-mounting bracket to a pole that is 2 to 5 inches in diameter using an adjustable steel band strap (not included in the kit). A steel band strap up to 0.5 inch (1.27 cm) wide can be threaded through the main part of the bracket to secure it to a larger...
  • Page 22 Trapeze Networks Position the bracket in the intended location and mark the position of the four mounting screw holes. Drill four holes in the wall that match the screws and wall plugs included in the bracket kit, then secure the bracket to the wall.
  • Page 23 Solder the ground wire to the ground-wire terminal lug supplied with the lightning arrestor. Trapeze Networks recommends that you use 6-gauge cable for the ground wire. The ground wire must be properly earthed in order to provide adequate protection.
  • Page 24 Trapeze Networks Figure 1–14. Connecting External Antennas to the MP-622 Connecting Cables to the Unit Attach the Ethernet cable to the Ethernet port on the MP-622. For extra protection against rain or moisture, apply weatherproofing tape (not included) around the Ethernet connector.
  • Page 25 Trapeze Networks Figure 1–15. Attaching an Ethernet Cable to the MP-622 Connecting the Outdoor Power Supply For instructions on connecting the outdoor power supply to the MP-622, refer to Installing an Outdoor Power Supply (Model XPS-620x-OUT). Be sure to contact a fully qualified electrician to perform the installation.
  • Page 26 Trapeze Networks Connect the Ethernet cable from the wireless bridge to the RJ-45 port labeled “Output” on the power injector. Connect a straight-through unshielded twisted-pair (UTP) cable from a local LAN switch to the RJ-45 port labeled “Input” on the power injector. Use Category 5e or better UTP cable for 10/ 100BASE-TX connections.

  • Page 27: Checking The Led Indicators

    Trapeze Networks Checking the LED Indicators The 11a and 11b/g LEDs on the MP-622 operate in two display modes, which are configurable through the software. The default AP mode indicates data traffic rates. The RSSI mode indicates the received signal power and is used when aligning antennas in a bridge link.
  • Page 28 Trapeze Networks You can use the CLI or RingMaster to configure an MP connection. If you are installing the MP-622 as a Mesh AP in a WLAN Mesh or wireless bridge configuration, you must configure the MP connection before deploying the MP-622 in its final location. (See the Mobility System Software Configuration Guide.)

  • Page 29: Aligning Antennas For Bridge Or Mesh Links

    Trapeze Networks The MX 10/100 Ethernet ports are configured as wired network ports by default. You must change the port type for an MX port directly connected to an MP to activate the link. (See the Mobility Exchange Installation and Basic Configuration Guide.)
  • Page 30 Trapeze Networks Figure 1–17. Aligning the MP-622 Antenna According to Signal Strength Vertical Scan Remote Antenna Maximum Signal Horizontal Scan Strength Position for Vertical Alignment Main Lobe RSSI Value Maximum RSSI Value Side Lobe Maximum Maximum Signal Strength Position for Horizontal Alignment When aligning the antennas the MP with the antenna that is being aligned to must be set to send link-calibration packets.
  • Page 31 Trapeze Networks To align the antennas in the link using the output LEDs, start with one antenna fixed and then perform the following procedure to align the other antenna: Pan the antenna horizontally back and forth while checking the RSSI LEDs. If using the pole-mounting bracket with the MP-622, you must rotate the mounting bracket around the pole.
  • Page 32 The unit also has a wall-mounting bracket kit that can be used to install the unit on a building wall. You also have the option to mount the MP on a larger pole (up to 12-inch diameter) using the bracket kit and two metal band straps (straps not provided by Trapeze). Hardware installation of the MP-632 involves these steps: Mount the unit on a wall, pole, mast, or tower using the mounting bracket.
  • Page 33 Trapeze Networks Insert the four large screws (included in kit) through the four circular holes in the bracket as shown below. Position the flat bracket behind the pole as shown below and align the screws on the front bracket with the holes in the flat bracket.
  • Page 34 Trapeze Networks Insert the four screws into the holes on the flat bracket and secure the brackets to the pole using the provided nuts. Position the MP-632 unit so that the mounting holes overlap with the same-sized holes on the pole-mounting bracket.
  • Page 35 Trapeze Networks Use the 2 small bolts and washers (included in kit) to tightly secure the MP-632 to the pole-mounting bracket. This pole mounting procedure can also be used to attached the MP-632 unit to a horizontal pole. Mounting on Larger Diameter Poles There is also a method for attaching the pole-mounting bracket to a larger diameter pole using two adjustable steel band straps (not included in the kit).
  • Page 36 Trapeze Networks Figure 1–18. Attaching the Bracket Using Steel Band Straps Using the Wall-Mounting Bracket Perform the following steps to mount the unit to a wall using the wall-mounting bracket. Always attach the bracket to a wall with the flat side flush against the wall (see following figure) Figure 1–19.
  • Page 37 Trapeze Networks Position the MP-632 unit so that the mounting holes overlap with the same-sized holes on the wall-mounted bracket.. Use the 2 small bolts and washers (included in kit) to tightly secure the MP-632 to the wall-mounted bracket. Outdoor Mobility Point Quick Start Guide v.7.1...

  • Page 38: Multiple External Antenna Support

    Trapeze Networks Connecting External Antennas The supported antennas models are: 802.11bgn Radio ❑ ANT-7360A-OUT (stick, N-type jack) ❍ If this antenna is used the unused center antenna port must be terminated. ANT-77555-OUT (3 RP-SMA jack) ❍ ANT-74520-OUT (3 RP-SMA) ❍...
  • Page 39 Ethernet input connector. The MP is configured as auto MDI/MDIX and is powered from the XPS-6201-OUT or XPS-6202-OUT power supplies. The MP-632 must only be used with a Trapeze-approved XPS-6201-OUT or XPS-6202-OUT outdoor power supply in order to prevent possible damage to the unit.
  • Page 40 Trapeze Networks Figure 1–20. Attaching the Ground-Wire Terminal Lug, Lock Washer, and Hex Nut to the Lightning Arrestor e. Connect one end of the short RF coaxial cable to the MP-632 N-type connector, and connect the other end to the lightning arrestor.

  • Page 41: Connecting The Power Injector

    IEEE 802.3af PoE. Always connect the unit to the included power injector module. The MP-632 must only be used with a Trapeze-approved XPS-6201-OUT or XPS-6202-OUT outdoor power supply in order to prevent possible damage to the unit.
  • Page 42 Trapeze Networks Insert the power cable plug directly into the standard AC receptacle on the power injector. Plug the other end of the power cable into a grounded, 3-pin socket, AC power source. For International use, you may need to change the AC line cord. You must use a line cord set that has been approved for the receptacle type in your country.
  • Page 43 Trapeze Networks Connecting an MP to an MX For lightning protection at the power injector end of the cable, consider using a lightning arrestor immediately before the cable enters the building. You can connect an MP directly to an MX or indirectly to the MX through an intermediate Layer 2 or Layer 3 network.
  • Page 44 Trapeze Networks MX Port LEDs for MP Meaning Connections Solid green For an MP access point active link, all the following are true: MP has booted. ❑ MP has received a valid configuration from the MX switch. ❑ Management link with an MP is operational.

  • Page 45: Rssi Meter Functionality

    Trapeze Networks Figure 1–22. Aligning the MP-632 Antenna According to Signal Strength Vertical Scan Remote Antenna Maximum Signal Horizontal Scan Strength Position for Vertical Alignment Main Lobe RSSI Value Maximum RSSI Value Side Lobe Maximum Maximum Signal Strength Position for Horizontal Alignment When aligning the antennas the MP with the antenna that is being aligned to must be set to send link-calibration packets.
  • Page 46 Flashing Fast Strong signal © 2009 Trapeze Networks, Inc. All rights reserved. Trapeze Networks, the Trapeze Networks logo design, Trapeze Smart Mobile, Trapeze Networks Mobility System Software, RingMaster, Mobility System, Mobility Exchange, Mobility Point, SafetyNet, MX, and MP are registered trademarks and/or registered service marks of Trapeze Networks, Inc.
  • Page 47 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 48 This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor environment only. FCC NOTICE: To comply with FCC part 15 rules in the United States, the system must be professionally installed to ensure compliance with the Part 15 certification.
  • Page 49 To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p) is not more than that permitted for successful communication. This device has been designed to operate with the antennas listed below, and having a maximum gain of [23.5] dB.
