Attention! Reliability and life of the product are provided not only by the quality of product itself,
but also by the compliance with operating modes and conditions, therefore, this document
requirements is mandatory
GSM Wireless Communication Channel Control Panel
ORTUS Group
"Lun-7Т"
тм
/"Lun-73Т"
Installation Manual
GSMControl Panel
GSM Control Panel Confguration
Software
Central Monitoring Station
Product Compatibility Table
"Confgurator"
"Orlan-M11" modules-
«Lun-7Т»
тм
Version
«Lun-73Т»
Version
Version
based Orlan
Advertisement
Table of Contents
Related Manuals for Ortus LUN-7T
Summary of Contents for Ortus LUN-7T
-
Page 1: Installation Manual
“Lun-7Т” тм /”Lun-73Т” GSM Wireless Communication Channel Control Panel Installation Manual Product Compatibility Table GSMControl Panel «Lun-7Т» тм Version «Lun-73Т» GSM Control Panel Confguration "Confgurator" Version Software Central Monitoring Station “Orlan-M11” modules- Version ORTUS Group based Orlan... -
Page 2: Table Of Contents
Table of contents 1. Purpose..................................... 3 2. Safety precautions................................. 3 3. Installation and connection............................3 4. Technical specifcations...............................5 5. Functions of device terminals...........................5 6. Selection of detectors connected to Control Panel...................7 7. Tamper protection arrangement..........................7 8. LED Indicators on Control Panel Card........................7 9. -
Page 3: Purpose
Panel to the central monitoring station (CMS) of"Orlan" GSM wireless communication channel throughGSM communication channels. The master unit of the Control Panel has a board of "Lun-7T" device with an additional board of GSM module or a board of “Lun-73T” device with the integrated GSM module. The prime and back-up power supply sources are also installed in the master unit;... - Page 4 It is not recommended to install antenna on the metal surface. The installation shall be performed as follows: 1. Confgure the device in accordance with "Lun-7T" Confguration Instruction" and the diagrams of facility outftting design. The Instruction is delivered on “Phoenix-4” software installation disk, and it is also available for download at http:// ortus.io...
-
Page 5: Technical Specifcations
4. Technical specifcations The Control Panel has the following technical characteristics given in Table 1. Table 1. Basic technical parameters of Control Panel Characteristic Value МОN2 interface (connection of “Lun-5N”, “Lun-7N”, “Lun-73N” network devices and “ТК-7”, “ТК-17” telephone communicator according to MON protocol) Maximum number of “Lun-5N”, “Lun-7N”, “Lun-73N”... - Page 6 Table 2. Functions of terminals on the Control Panel board Terminal Function Marking Common contact (–) of device Connection of contact (BUS) of “Lind” indication and control device • (connection with foiled twisted pair up to 40m long); Connection of contact (BUS) of “MPB-8” relay-controlled output module •...
-
Page 7: Selection Of Detectors Connected To Control Panel
Tamper contacts of power supply unit, “Lind-7” indication and control devices, switched spur and all detectors connected to the Control Panel shall be connected to this zone. Attention! Tamper zone shall be confgured as a 24-hour, silent zone (see "Lun-7T" Confguration" instruction). -
Page 8: Control Panel Status Indication
Possible operation modes of Modem Status Indicator (green LED): continuous glowing – GSM modem could not be registered in GSM network (connection ● trouble); short fashes with short pause – GSM modem is in the process of registration in GSM ●... -
Page 9: Zone Status Indication By "Lind-7" Icd Indicators
description below); RESET (button) is designed to reset the status and indication memory of 24-hour zones. A short pressing of the button leads to extinction of ZONE 1…8 LEDs, which are the indicators of 24-hour protected zones (LEDs are lit if violations occurred in such zones, even after such violation was fxed). -
Page 10: Arming
ZONE 2 – Discharged battery; ZONE 3 – GSM channel glitch; ZONE 4 – Local bus trouble when network expanders are connected; ZONE 5 – Not sent events available. 1. Prime power fault (230V) – AC230V LED is OFF, SYSTEM LED fashes frequently, ZONE 1 LED is lit when TROUBLE button is pressed and held. -
Page 11: Disarming
In this case, “ARMED” LED and remote LED outside the facility will start fashing regularly (fashing interval – 1 sec, fash duration – 0.5 sec). At the same time, a repeated sound reminding of the need to leave the premises, will be enabled. When the countdown starts, you shall leave the house/object. -
Page 12: Lind-9" Indication And Control Device
9.2. "Lind-9" indication and control device "Lind-9" ICD can be in the scope of supply of the Control Panel. Connection diagram is shown in Figure 9. Attention! When Control Panel operates with "Lind-9" ICD, the remote LED is connected to AUX contact (see Figure 9). - Page 13 SYSTEM (yellow LED) – informs about failure of the internal program of device; READY (green LED) – blink while the Control Panel is disarmed, off – in the armed state; POWER (green LED) – informs of ICD power supply status; ACCESS LEVEL (yellow LED) –...
-
Page 14: Zone Status Indication By "Lind-9" Icd Indicators
“Electronic Keys” tab. See the details of confguring in "Lun Devices Confguration Manual". The Manual is available for download at http:// ortus.io Specify four-digit numeric codes of the "supervisor" and "installer" in the corresponding entry felds as shown on Figure 3. -
Page 15: Manual Password Control
Attention! When editing passwords using ICD keypad, the fourteenth password in the password (key) list is the Supervisor’s password. It allows for editing of users' passwords from the keypad. For example, the supervisor's password is 1253. In this case, to set this password in “Confgurator” program, “1253” password must be entered in the “Supervisor code”... -
Page 16: Confguring Of Device From Keypad
“#” button cancels the previous action. ¬¬9 Attention! Input « » to exit the Supervisor access level of the (password editing mode) and enter the standby mode. Example. Supervisor's password is 1253. User No.1 selected password 1546, User No.2 selected password 2357, User No.3 selected password 7852. 1253 ¬5 ¬01... -
Page 17: Arming
¬242097 ¬¬9 The assignment and content of cells is described in the "Instructions on confguring of “Lun-7T” Control Panel using keypad". 9.2.7. Arming 1. To arm the facility, you shall shut all the doors and windows equipped with detectors. Attention! If at least one detector (zone) is alarmed, the facility shall not be armed. -
Page 18: Disarming
See the details of confguration in "Confgurator Manual". The Manual is delivered on the installation disk of “Phoenix-4” software, it is also available for download at http:// ortus.io 11. Remote control The Control Panel responses to the incoming calls and controls the number of the calling telephone. -
Page 19: Battery Monitoring Arrangement
13. Arrangement of main power supply monitoring (230V) The board of “Lun-7T” Control Panel has a main power supply control contact 230V – АСТ. When using UPS manufactured by Ortus Group for powering of “Lun-7T” Control Panel, the control is provided by means of the built-in sensor with АСТ... -
Page 20: Lun-5N", "Lun-7N", And "Lun-73N" Expanders
Attention! When using "NES-35-15" UPS, its maximum load shall not exceed 1.2А! Connection of protective earth to UPS is required. When using third-party transformer power units, the main power can be controlled by means of the relay, the coil of which is connected to the primary or secondary coil of the transformer (see Figure 11). -
Page 21: Mpb-8" Relay Output Module
trembling signal will be heard on the keyboard of "Lind-9", and if using "Lind-7", ARMED LED will fash once. Attention! If there is no connection between the basic device and "zone expander", only the basic device and the connected “zone expanders” can be disarmed. Arming will not be possible until the connection of the basic device with all the “zone expanders”... -
Page 22: Maintenance
16. Maintenance This product does not require any maintenance. 17. Operating conditions The device shall be used at the temperature of –5°С to +40°С and relative humidity of 5% to 85%. 18. Storage 1. Product storage in terms of the climate impact shall be under conditions 2 according to GOST 15150. -
Page 23: Appendices
GSM-module board mounting. The appearance of module is shown in Figure 4. Fiiure 4. General view of Control Panel "Lun-7T" "Lun-73T" Control Panel (see Figure 5) is an improved construction of the existing "Lun-7T" Control Panel, namely: ● Integrated GSM-module with antenna;... - Page 24 Fiiure 5. General view of Control Panel "Lun-73T" Table 5. Diairams of connection of zone termination resistor Connection circuit Description Connection of zone termination resistor when using normally open contacts Connection of zone termination resistor when using normally closed contacts Connection of zone termination resistor when using normally opened contacts and normally closed contacts simultaneously БААИ.425523.003ИУ...
- Page 25 Attention! Adherence to these electric circuit diagrams is mandatory. Failure to comply with this requirement may lead to warranty disclaimer. Fiiure 6. Diairam of connection of external devices and detectors without "Lind" control and indication device by usini the "armini" zone Fiiure 7. "Lun-7T" power supply connection БААИ.425523.003ИУ Rev. en_19...
- Page 26 Attention! Adherence to this electric circuit diagram is mandatory. Failure to comply with this requirement may lead to warranty disclaimer. Fiiure 8. Diairam of connection of external devices and detectors usini "Lind-7" indication and control device БААИ.425523.003ИУ Rev. en_19...
- Page 27 Attention! Adherence to these electric circuit diagrams is mandatory. Failure to comply with this requirement may lead to warranty disclaimer. Fiiure 9. Diairam of connection of external devices and detectors usini “Lind-9” indication and control device Fiiure 10. “Lun-73T” power supply connection БААИ.425523.003ИУ...
- Page 28 Fiiure 11. Diairam of connection of “Lun-7T” main power control relay usini third-party power supply units Attention! Adherence to this electric circuit diagram is mandatory. Failure to comply with this requirement may lead to warranty disclaimer. Fiiure 12. Extension modules connection diairam БААИ.425523.003ИУ...
- Page 29 Attention! Adherence to these electric circuit diagrams is mandatory. Failure to comply with this requirement may lead to warranty disclaimer. Fiiure 13. MPB-8 module connection diairam Fiiure 14. Phone communicator connection diairam БААИ.425523.003ИУ Rev. en_19...
- Page 30 Fiiure 15. Place of installation of device assemblies for "monoblock unit" version БААИ.425523.003ИУ Rev. en_19...
- Page 31 Fiiure 16. Mountini elements for "sinile unit housini” version БААИ.425523.003ИУ Rev. en_19...
- Page 32 Fiiure 17. Installation of anti-obstruction contacts in version "sinile unit housini" БААИ.425523.003ИУ Rev. en_19...
- Page 33 Fiiure 18. eequence of power supply unit installation for "sinile unit housini" version Fiiure 19. "Lind-7” ICD uncovered Fiiure 20. "Lind-9" ICD uncovered (rear view) БААИ.425523.003ИУ Rev. en_19...
-
Page 34: Appendix 2. Warranty Service Regulations
● equipment with external defects (obvious mechanical damages, cracks, chips on the housing and inside the ● device, broken antenna or connector pins). Manufacturer: ORTUS Group 5624 California st, San Francisco, CA 94121, USA Tel.:+1 650 240 27 62 mail: info@ortus.io...
