OM 2015 Gulliver - D
Operating Manual
Travel Bed
"GULLIVER"
Read carefully before assembling!
Advertisement
Related Manuals for FreiStil Tischlerei GULLIVER
Summary of Contents for FreiStil Tischlerei GULLIVER
- Page 1 FreiStil Tischlerei Böhm und Kinstler GmbH & Co. KG Ruppenkampstraße 16 D-49084 Osnabrück ++49 - 541-800 3969 0 ++49 - 541-800 3969 99 E-mail info@freistil.com Homepage: www.freistil.com Operating Manual Travel Bed “GULLIVER” Read carefully before assembling! OM 2015 Gulliver - D...
- Page 2 (Fig. 1 and Fig. 2) and screw them together with the screws (8 x 30mm) provided. Tighten up all the screws and, after you have used the travel bed for some time, check to make sure they are still tight! OM 2015 Gulliver - 01...
- Page 3 1.2 Join up the bottom, short lateral pieces with the upright posts as shown in the diagrams (Fig. 3 and Fig. 4) and screw them together with the screws (8 x 60mm) provided. Fig. 3 Fig. 4 OM 2015 Gulliver - 02...
- Page 4 (Fig. 5 and Fig. 6). If the travel bed is to stand with its long side against a wall, then the rails must be adjusted (offset) accordingly as shown (Fig. 7). Fig. 5 Fig. 6 Fig. 7 OM 2015 Gulliver - 03...
- Page 5 1.4 Insert the top, long lateral pieces into the sleeves of the net as shown (Fig. 8) and connect the lateral pieces with the pre-assembled side pieces (see 1.2) as shown in the diagram (Fig. 9). Fig. 8 Fig. 9 OM 2015 Gulliver - 04...
- Page 6 1.6 Fasten the net to the bottom, long lateral pieces via the Velcro tapes attached to the net. Fig. 11 FreiStil Tischlerei Manufacturer: , Ruppenkampstraße 16, D - 49084 Osnabrück Fon ++49 541-800 3969 0, Fax ++49 541-800 3969 99 email: info@freistil.com OM 2015 Gulliver - 05...
