- Page 1 Operating Instructions 939i ™ Monarch ® Intelligent Keyboard , ADTP1, 9416 XL ® ® 9906 ™ for use with 28028 and ADTP2 TC0939IOI Rev. AN 5/17 ©2004 Avery Dennison Corp. All rights reserved.
- Page 2 Each product and program carries a respective written warranty, the only warranty on which the customer can rely. Avery Dennison Corp. reserves the right to make changes in the product, the programs, and their availability at any time and without notice. Although Aver y Dennison Corp. has made ever y effort to provide complete and accurate information in this manual, Aver y Dennison Corp.
-
Page 3: Table Of Contents
T A B L E O F C O N T E N T S GETTING STARTED ..................1-1 Overview ....................1-1 About Scripts .................... 1-1 Unpacking the Keyboard ................1-2 Connecting the 939I to a 9416 Printer ............1-2 Connecting the 939I to 9906, ADTP1, ADTP2 Printer ........ - Page 4 CONFIGURING THE SYSTEM................. C-1 Accessing the Keyboard’s Main Menu ............C-1 Operating in Script Mode ................C-1 About the Scanner ................... C-1 Operating the Scanner ................C-2 Troubleshooting the Scanner ..............C-2 Cleaning ....................C-3 Configuring the Scanner ................C-3 Reset to Default Values ................
-
Page 5: Getting Started
G E T T I N G S T A R T E D The Monarch® 939i™ keyboard allows you to easily configure the printer and enter batch data. The keyboard works with the Monarch® 9416®, 9416® XL®, 9906, ADTP1, and ADTP2 printers. This keyboard also works with non-Monarch printers. -
Page 6: Unpacking The Keyboard
U n p a c k i n g t h e K e y b o a r d After unpacking the keyboard, look through all packaging material for parts. Keep the box and packaging material in case the keyboard ever needs repair. -
Page 7: Connecting The 939I To 9906, Adtp1, Adtp2 Printer
Connect the adaptor cable’s power connector to the keyboard power supply (5V). Connect the keyboard power supply (5V) to the power cord. Plug the power cord in to an electrical outlet. Note: Be sure that the printer’s power supply is also attached to the printer and plugged in to an electrical outlet. -
Page 8: Setting The Baud Rate
S e t t i n g t h e B a u d R a t e To print, the baud rate of the keyboard and printer must be the same. The default printer baud rate is 9600; the default keyboard baud rate is 19200. - Page 9 Button Description Escape. Returns the display to the previous menu or clears an error. Clear. Clears the entire field. Pause. Interrupts printing. Press Pause again to resume printing. Feed. Feeds a blank label if there is no print job. Prints a label in on-demand mode.
- Page 10 1-6 Operating Instructions...
-
Page 11: Troubleshooting
T R O U B L E S H O O T I N G This chapter provides solutions to keyboard problems and explains common status code messages you may receive when using the keyboard. Problem Action The keyboard display is Make sure the printer is ON. - Page 12 Problem Action Monetary symbols do not Make sure your font supports the selected print as expected. code page (Bold, ANSI, etc.). For more information, see Appendix B, “ Character .” Sets Script is not running. Turn the printer off and then back on. If this does not solve the problem, contact Technical Support for more information.
-
Page 13: Specifications & Accessories
S P E C I F I C A T I O N S & A C C E S S O R I E S Height: 4.0 inches (102 mm) Width: 8.25 inches (210 mm) Depth: 8.75 inches (222 mm) Weight: 2.33 lbs. -
Page 14: Flat Surface Mount
Flat Surface Mount Make sure all surfaces you apply the dual lock fasteners to are free from dirt and oil. If necessary, clean with isopropyl alcohol. Pull the cord through the large hole in the stand. Set the keyboard into the stand. Attach either the rubber pads or dual lock fasteners to the base of the keyboard stand. -
Page 15: Wall Mount
Wall Mount Hold the bottom of the stand against the wall (hinge side up). Mark the mounting holes with a pencil. Screw the stand onto the wall (screws not included). Pull the cord through the large hole in the stand. Set the keyboard into the stand. -
Page 16: Connecting The Scanner's Cables
C o n n e c t i n g t h e S c a n n e r ’ s C a b l e s A scanner is optional for the keyboard. You need to connect the cable to the scanner and keyboard before you can use it. -
Page 17: Character Sets
C H A R A C T E R S E T S This appendix contains a listing of the symbol sets and code pages the printer supports. S u p p o r t e d S y m b o l S e t s a n d C o d e P a g e s The CG Triumvirate™... -
Page 18: Internal (Standard And Reduced Font
Internal (Standard and Reduced Font) B-2 Operating Instructions... -
Page 19: Bold
Bold Character Sets B-3... -
Page 20: Ansi
ANSI B-4 Operating Instructions... -
Page 21: Code Page 437
Code Page 437 Character Sets B-5... -
Page 22: Code Page 850
Code Page 850 B-6 Operating Instructions... -
Page 23: Configuring The System
C O N F I G U R I N G T H E S Y S T E M This chapter contains information useful for your System Administrator: ♦ Accessing the Keyboard’s Main Menu. ♦ Operating in Script Mode. ♦... -
Page 24: Operating The Scanner
Operating the Scanner CAUTION Do not stare into the beam. To scan a bar code: 1. Point the scanner at a slight angle to, and approximately four to eight inches from the bar code symbol. 2. Press the button on the scanner. When the scanner is in the stand, it automatically scans any bar codes held in front of the scanner’s window. -
Page 25: Cleaning
Cleaning Clean the scanner window whenever it appears to be dirty or smeared. To clean it: 1. Moisten a soft cloth with water. 2. Wipe the window until it is completely clean. C o n f i g u r i n g t h e S c a n n e r The scanner may already be configured to work with your ADK script. -
Page 26: Set The Communications Port Defaults
Set the Communications Port Defaults To set the communications port to the same defaults as the keyboard, scan the following series of bar codes, one at a time, from top to bottom. C-4 Operating Instructions... - Page 27 You can also set the communication values by using the Keyboard’s Main Menu. The keyboard defaults are 9600 Baud, 8-bit Word Length, 2 Stop Bits, No Parity, and No Flow Control. Press X on the keyboard within the first two seconds when the printer/keyboard are turned on to see the Keyboard’s Main Menu.
-
Page 28: Set The Minimum Bar Code Width
Set the Minimum Bar Code Width To scan single-digit bar codes, scan the following series of bar codes, one at a time, from top to bottom. C-6 Operating Instructions... -
Page 29: Cable Pinouts
C A B L E P I N O U T S C a b l e P i n o u t s The following tables show the connector pins for the Keypad Auxiliary Cable (12662). Printer FCI 90312-010 D-Sub 9 pin (female) RTS 8... - Page 30 D-2 Operating Instructions...
- Page 32 28028 Avery Dennison Printer Systems Division 170 Monarch Lane Miamisburg, OH 45342 1-800-543-6650 (In the U.S.A.) 1-800-387-4740 (In Canada) www.monarch.averydennison.com...
