8
Undo the fixing screw, remove the
controller assembly away from the
back plate and set aside.
9
Place the bath control back plate onto the finished wall surface in
the desired location and mark the fixing and data cable entry
points.
!
Care should be taken to ensure the mounting holes do not pierce
the data cable conduit.
10
Drill and prepare the fixing points and 15mm data cable entry point
using the fixings provided, if suitable.
11
Apply a thin bead of mastic to the mas-
tic groove at the rear of the
back plate. Secure the back plate
to the wall using the screws provided,
if suitable.
12
Connect the data cable to the rear of the controller.
