DA 40 NG AFM
Supplement S10
Following parameters are recorded with the installed system:
• Accelerometers (1-4)
• Absolute pressure
• Differential pressure
• Engine type
• Engine number
• RPM
• Coolant temperature
• Power load
• Fuel pressure
• Battery voltage
• Oil temperature
• Oil pressure
• Gearbox temperature
• Fuel Flow
• Autopilot engage status (Optional)
• Flaps (Optional)
• Audio data
Minimum and maximum values of each parameter for each individual flight of the
airplane are recorded and are stored for the whole life of the airplane/system. These
stored data cannot be erased.
Data Downloading
Data can be downloaded manually using a removable SD card. Manual data
download on the ground is done very simply by removing the SD card from the Data
Retrieval Unit and then uploading them into almost any personal computer equipped
with iaero's Analysis Software.
Doc. # 6.01.15-E Rev. 0 29 Jan 2016
Flight Data Logging
Device
Page 9-S10-11
