DA 40 NG AFM
Supplement S10
TO THE AIRPLANE FLIGHT MANUAL
FLIGHT DATA LOGGING DEVICE
Doc. No.
Date of Issue
Design Change Advisory
This Supplement to the Airplane Flight Manual has been approved under the authority
of DOA No. EASA.21J.052.
DIAMOND AIRCRAFT INDUSTRIES GMBH
N.A. OTTO-STR. 5
A-2700 WIENER NEUSTADT
AUSTRIA
SUPPLEMENT S10
DA 40 NG
:
:
:
Flight Data Logging
6.01.15-E
29 Jan 2016
OÄM 40-337/b
Device
Page 9-S10-1, Rev. 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA 40 NG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Diamond Aircraft DA 40 NG

Summary of Contents for Diamond Aircraft DA 40 NG

  • Page 1 DA 40 NG AFM Flight Data Logging Supplement S10 Device SUPPLEMENT S10 TO THE AIRPLANE FLIGHT MANUAL DA 40 NG FLIGHT DATA LOGGING DEVICE Doc. No. 6.01.15-E Date of Issue 29 Jan 2016 Design Change Advisory OÄM 40-337/b This Supplement to the Airplane Flight Manual has been approved under the authority of DOA No.
  • Page 2 DA 40 NG AFM Flight Data Logging Supplement S10 Device Intentionally left blank. Doc. # 6.01.15-E Rev. 0 29 Jan 2016 Page 9-S10-2...
  • Page 3 DA 40 NG AFM Flight Data Logging Supplement S10 Device 0.2 RECORD OF REVISIONS Rev. Date of Approval Date of Date Reason pter Page(s) Signature Revision Note Approval Inserted Doc. # 6.01.15-E Rev. 0 29 Jan 2016 Page 9-S10-3...
  • Page 4 DA 40 NG AFM Flight Data Logging Supplement S10 Device 0.3 LIST OF EFFECTIVE PAGES Chapter Page Date 9-S10-1 29 Jan 2016 9-S10-2 29 Jan 2016 9-S10-3 29 Jan 2016 9-S10-4 29 Jan 2016 9-S10-5 29 Jan 2016 9-S10-6 29 Jan 2016...

  • Page 5: Table Of Contents

    DA 40 NG AFM Flight Data Logging Supplement S10 Device 0.4 TABLE OF CONTENTS Page GENERAL ..........9-S07-6 OPERATING LIMITATIONS .

  • Page 6: General

    DA 40 NG AFM Flight Data Logging Supplement S10 Device 1. GENERAL This Supplement describes the function of the Flight Data Logging Device and supplies all information for the safe and efficient operation of the system. The Flight Data Logging Device is NOT covered by a TSO, but it has proven fire and crash resistance.

  • Page 7: Operating Limitations

    DA 40 NG AFM Flight Data Logging Supplement S10 Device 2. OPERATING LIMITATIONS No change. 3. EMERGENCY PROCEDURES No change. NORMAL OPERATING PROCEDURES No change. ABNORMAL OPERATING PROCEDURES No change. 5. PERFORMANCE No change. Doc. # 6.01.15-E Rev. 0 29 Jan 2016...

  • Page 8: Mass And Balance / Equipment List

    DA 40 NG AFM Flight Data Logging Supplement S10 Device 6. MASS AND BALANCE / EQUIPMENT LIST 6.5 Equipment List and Equipment Inventory Airplane Serial No.: Registration: Date: Description Type Part No.: Manufacturer stalled INDICATING / REC. SYSTEM Sensor Interface Unit...

  • Page 9: Description Of The Airplane And Its Systems

    Analysis Software provided with the system. Refer also to the iaero, APIBOX System, Diamond DA 40 NG User Manual. SYSTEM OVERVIEW The APIBOX SYSTEM consists of five main components: •...
  • Page 10 DA 40 NG AFM Flight Data Logging Supplement S10 Device • The CAN/ARINC Interface Unit (i2060-002) receives data from the engine CAN busses and from the Garmin G1000 via ARINC 429 busses. • The Data Retrieval Unit (APISD-001), receives all data from the Memory and Data Processing Unit and stores the data on a removable SD card.
  • Page 11 DA 40 NG AFM Flight Data Logging Supplement S10 Device Following parameters are recorded with the installed system: • Accelerometers (1-4) • Absolute pressure • Differential pressure • Engine type • Engine number • • Coolant temperature • Power load •...

  • Page 12: Airplane Handling, Care And Maintenance

    DA 40 NG AFM Flight Data Logging Supplement S10 Device Data Analysis Each APIBOX SYSTEM is provided with iaero’s Analysis Software that can be installed on almost any personal computer. When data are uploaded from an SD card into a Personal Computer, the recorded data are analyzed by the program and displayed on a synthetic and user-friendly display.
