DR. BENDER BELUGA WX2 Manual

Beluga wx2 series; beluga wx8 series. driving machines 230 v/400 v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DR. BENDER
Innovative Elektrowerkzeuge
Manual for
driving machines
Valid from 06.2005 WX2
WX2 FH
WX2 B
WX8
WX8 FH
WX8 B
BELUGA WX2 230V
All rights reserved
DR. BENDER
Our website address is: http://www.dr-bender.de
GmbH
1750
Art.-No.
Art.-No.
Art.-No. 101382
Art.-No.
Art.-No.
Art.-No. 101305
GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91
beluga wx2
beluga wx8
1500
2400
101187
101188
101096
101092
101085
101183
101118
101093
BELUGA WX8 400V
• e-mail:
230 V
400 V
-1
3750
min
Subject to alterations
100387
info@dr-bender.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BELUGA WX2 and is the answer not in the manual?

Questions and answers

Related Manuals for DR. BENDER BELUGA WX2

Summary of Contents for DR. BENDER BELUGA WX2

  • Page 1 101183 100387 WX8 FH Art.-No. 101118 101093 WX8 B Art.-No. 101305 BELUGA WX2 230V BELUGA WX8 400V All rights reserved DR. BENDER GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91 info@dr-bender.de Our website address is: http://www.dr-bender.de • e-mail:...

  • Page 2: Conformity Declaration

    Innovative Elektrowerkzeuge EC Conformity Declaration for the following DR.BENDER stone processing machines BELUGA WX2, WX2 FH, WX2 B BELUGA WX8, WX8 FH, WX8 B DR.BENDER GmbH, as manufacturer, hereby declares that the electrical stone drilling machines mentioned above comply with the requirements of the following guidelines:...

  • Page 3: Table Of Contents

    4.1.6 Beluga WX8 B, 400V Technical Data 4.2.1 Beluga WX2, WX2 FH, WX2 B, 230V 4.2.2 Beluga WX8, WX8 FH, WX8 B, 400V Noise emissions and vibrations [EN 50144] WX2, WX2 FH Noise emissions and vibrations n [EN 50144] WX2 B, WX8, WX8 FH, WX8 B...

  • Page 4: Symbol- And Pictograph Description

    Warning It is compulsory to observe the safety instructions included in this manual! Special designs and versions may differ from the standard models in terms of their technical details. If any points are unclear, we urgently recommend that you contact DR.BENDER GmbH, indicating the machine type and machine number.

  • Page 5: General Instructions

    (even if it contains thick reinforcement steel) sandstone and limestone all building materials for solid walls asphalt carpets The machines must be connected as follows: BELUGA WX2: to the PB WX2 type Powerbox; BELUGA WX8: to the PB WX8/10 or PB WX8/10 VB type Powerboxes.

  • Page 6: Safety

    Safety Warning Before using the machine for the first time, check the conformity of the data on the model plate with the mains voltage and frequency. Voltage deviations of ± 5 % and/or voltage deviations of ± 2 % are permissible. Repairs may be carried out only by adequately qualified persons, based on their training and experience.

  • Page 7: Main Dimensions And Technical Data

    Main dimensions and technical data Dimensions 4.1.1 Beluga WX2, 230V 4.1.2 Beluga WX2 FH, 230V 4.1.3 Beluga WX2 B, 230V...

  • Page 8: Beluga Wx8, 400V

    4.1.4 Beluga WX8, 400V 4.1.5 Beluga WX8 FH, 400V 4.1.6 Beluga WX8 B, 400V...

  • Page 9: Technical Data

    Technical Data 4.2.1 Beluga WX2, WX2 FH, WX2 B, 230V Gearbox variant 1500 1750 2400 3750 Rated voltage Current consumption Power requirement 3,500 Frequency 1000 Idling speed 0 - 1500 0 – 1750 0 - 2400 0 – 3750 Full speed 0 - 1500 0 –...

  • Page 10: Operating Temperatures

    400V connection cable - WX8, WX8 FH Art.-No. 801792 The Beluga WX2 B and WX8 B type driving machines are designed for freehand cutting applications in terms of their sense of rotation. This means that in case of a drilling application, there appears an incorrect sense of rotation for drilling.

  • Page 11: Water Connection

    The PB WX2 type Powerbox and the Beluga WX2, WX2 FH type driving machines are air-cooled and consequently require no water connection.

  • Page 12: Handle Adjustment - Wx8 Fh

    Handle adjustment - WX8 FH Saw blades and core bits You may use any saw blade having a connection bore of 1“ ( 25.4 mm). Use only saw blades that are suitable for the type of stone. You will keep the driving machine in good condition if you use only saw blades that are concentric and not deformed ones.

  • Page 13: Maintenance And Care

    Maintenance and care Warning Pull out the mains plug before beginning any maintenance or repair work. You must have the equipment checked by a specialized electrician after every repair (statutory regulation pursuant to VBG4 since 1.1.1990). Daily care Make sure no water flows out of the tool. This will cause gear damage and may adversely affect the electrical safety of the equipment.

  • Page 14: General Safety Instructions

    The periodical maintenance and cleaning of the products according to the directions of the operating instructions is absolutely necessary. The intervention of third persons (opening the machine) renders any warranty claim void. Maintenance and cleaning operations cannot be claimed on the basis of warranty. Make sure only original spare parts and original accessories are used.
  • Page 15 Earth” Professional Association must be satisfied. 25. Electrical safety and fire safety: just as DR. BENDER did in the last 20 years, the new version of VDE 0100 also recommends the additional safety protection and fire protection of each tool achieved by...

  • Page 16: Spare Parts Lists

    11.0 Spare parts lists 11.1 Beluga WX2, 230V 11.2 Beluga WX2 FH, 230V...
  • Page 17 Pos. Art.-No. Art.-No. Art.-No. Description Pcs. Grb. 1500 2400 3750 101187 101188 Driving machine, complete 101185 Motor, complete 101181 100292 101378 Gear, complete 900231 Washer 900181 Elastic washer 900412 Countersunk screw 301427 Pipe, complete 301425 Pipe 301426 Cover 800076 Lock washer 801699 Fillister screw 100379...

  • Page 18: Beluga Wx2 B, 230V

    11.3 Beluga WX2 B, 230V 11.4 Beluga WX8, 400V...
  • Page 19 Pos. Art.-No. Description Pcs. Grb. 1750 101382 Driving machine, complete 101380 Motor, complete 101350 Gear, complete 802082 Blank cover Wearing parts ** Pos. Art.-No. Art.-No. Art.-No. Description Pcs. Grb. 1500 2400 3750 101085 101183 Driving machine, complete 101089 Motor, complete 101181 100292 100378...

  • Page 20: Beluga Wx8 Fh, 400V

    11.5 Beluga WX8 FH, 400V...
  • Page 21 Pos. Art.-No. Art.-No. Art.-No. Description Pcs. Grb. 1500 2400 3750 101118 101093 Driving machine 101089 Motor, complete 101181 100292 101378 Gear, complete 900231 Washer 900181 Elastic washer 900412 Countersunk screw 101095 Casing, complete 100379 Cable gland 902094 O ring 1 ** 800076 Lock washer 900337...

  • Page 22: Beluga Wx8 B, 400V

    11.6 Beluga WX8 B, 400V...
  • Page 23 Pos. Art.-No. Description Pcs. Grb. 1750 101305 Driving machine, complete 101306 Motor, complete 101350 Gear, complete 802082 Blank cover Wearing parts **...

  • Page 24: Motor Compl. Wx2, Wx2 Fh, 230V

    11.7 Motor compl. WX2, WX2 FH, 230V...
  • Page 25 Pos. Art.-No. Description Pcs. 101185 Motor, complete 100738 Motor casing 801545 Stator 101184 Rotor, complete 901015 Deep-groove ball bearing 900801 Circlip 801885 Spring ring 901030 Adjusting spring 101186 Bearing cap 800036 Shim 801921 Shaft sealing ring 100985 900181 Elastic washer 902026 Allen screw 901012...

  • Page 26: Motor Compl. Wx8, Wx8 Fh, 400V

    11.8 Motor compl. WX8, WX8 FH, 400V...
  • Page 27 Pos. Art.-No. Description Pcs. 101089 Motor, complete 101090 Motor casing 802022 Stator 101087 Rotor complete 901015 Deep-groove ball bearing 2 ** 900801 Circlip 801885 Spring ring 901030 Adjusting spring 801574 Ball bearing shim 401429 Flat gasket 101091 Bearing cap 802028 O ring 2 ** 401421...

  • Page 28: Motor Compl. Wx2 B, 230V

    11.9 Motor compl. WX2 B, 230V...
  • Page 29 Pos. Art.-No. Description Pcs. 101380 Motor, complete 101090 Motor casing 801545 Stator 101381 Rotor complete 901015 Deep-groove ball bearing 2 ** 801574 Ball bearing shim 900801 Circlip 801885 Spring ring 901030 Adjusting spring 401429 Flat gasket 101307 Bearing cap 900571 Screwed cable joint 900231 Washer...

  • Page 30: Motor Compl. Wx8 B, 400V

    11.10 Motor compl. WX8 B, 400V...
  • Page 31 Pos. Art.-No. Description Pcs. 101306 Motor, complete 101090 Motor casing 802022 Stator 101087 Rotor complete 901015 Deep-groove ball bearing 2 ** 801574 Ball bearing shim 900801 Circlip 801885 Spring ring 901030 Adjusting spring 401429 Flat gasket 1 ** 101307 Bearing cap 900571 Screwed cable joint 900231...

  • Page 32: Gear Compl. Wx2, Wx8

    11.11 Gear compl. WX2, WX8...
  • Page 33 Pos. Art.-No. Art.-No. Art.-No. Description Pcs. Gear 1500 2400 3750 101181 100292 101378 Gear, complete 200896 Gear casing 900639 Ball bearing shim 1 ** 900737 Deep-groove ball bearing 2 ** 901031 Shaft sealing ring 1 ** 800001 Circlip 900000 Deep-groove ball bearing 1 ** 301163 Drive spindle...

  • Page 34: Gear Compl. Wx2Fh, Wx8B

    11.12 Gear compl. WX2FH, WX8B...
  • Page 35 Pos. Art.-No. Art.-No. Art.-No. Art.-No. Description Pcs. Gear 1500 1750 2400 3750 101731 101350 101732 101752 Gear, complete 200898 Gear casing 900639 Ball bearing shim 1 ** 900737 Deep-groove ball bearing 2 ** 901031 Shaft sealing ring 1 ** 800001 Circlip 900000 Deep-groove ball bearing...
