Franklin Wireless S600C User Manual

Hide thumbs Also See for S600C:

Need help?

Do you have a question about the S600C and is the answer not in the manual?

Page 1 S600C User Manual...
Page 2 FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 3 DC power jack, RF connectors. The S600C can be used to test the performance of the module. Both the wired connection test (connect the module to the each equipment) and the wireless connection test (connect the module to the antennas) can be implemented.
Page 4 2. Diagram of connecting the S600C and the antenna Figure-3. Diagram of connecting the module and the antenna Table-1. Port definition of RF connectors Port definition S600C CDMA Main CDMA Aux+GPS...
Page 5 Connect the devices and set up the test environment according to Figure-2. Then connect the S600C to the PC through a Micro-USB to Type A USB cable.. When performing the wired connection test, connect the E5515C to the RF interface of the S600C..
