LOGICOM M bot 52 Quick Start Manual page 4

3. Inserting a MicroSD
It is possible to increase the internal memory of the Smartphone
device with a MicroSD card. (Maximum 32GB MicroSD card).
Switch off the phone and remove the rear cover and
battery.
Insert the memory card into the relevant slot.
Then replace the battery and cover.
CAUTION: Inserting or removing a SIM card or a MicroSD card
requires the Smartphone to be completely switched off. The SIM
slot 2 is shared with the MicroSD slot, so you use a card (Nano SIM
or microSD) at a time.
4. Charging the battery
Installing the battery:
Remove the rear cover of your Smartphone.
Insert the battery ensuring that the image shown here is facing you.
Replace the rear cover of the Smartphone.
CAUTION
: Risk of explosion if battery is replaced by an incorrect type.
Model: PH HS365874AR (Li-­‐ion – 3,8V – 2150mAh)
To replace the battery, please enquire with the after-­‐ s ales service of your dealer.
Dispose of used batteries according to the instructions.
To replace the battery, please enquire with the after-­‐ s ales service of your dealer.
Dispose of used batteries according to the instructions.
Charging the battery:
To charge the battery, connect the USB cable (supplied) to the USB port
of your Smartphone and the other end to the mains adaptor (supplied).
Then connect the mains adaptor to a power outlet.
The battery charge icon illuminates during charging and indicates the
charge status.
When the battery is fully charged, you can disconnect the USB cable from
the device then from the power outlet.
IMPORTANT:
The Smartphone is only recharged via its USB port.
Ensure your Smartphone is fully discharged before charging it for the first time.
The battery must be charged for at least 5 to 8 hours when first charged.
After a long period without use, It should be necessary to do many cycles of charging / discharging to
obtain maximum power capacity
Note: You can use the device when it is being charged. In this case, the battery may take longer to charge fully.
Safety information for charging the battery:
To recharge the battery, only use the mains adaptor supplied with your device. Do not use any other
power supply or electrical device.
The power outlet to which the device is connected must be near the equipment and must always be
easily accessible.
4
