- Page 1 Instructions Instrucțiuni de utilizare - RO Anleitung - D Eredeti használati utasítás - HU Ръководство за употреба - BG Instrukcja obsługi - PL www.heinner.com VMF001...
-
Page 2: Table Of Contents
GASOLINE CHAIN SAW SAFETY FIRST Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. ... -
Page 3: Parts Location
GASOLINE CHAIN SAW 1. PARTS LOCATION 1 - Front guard 8 - Throttle lock button 2 - Starter knob 9 - Engine switch 3 - Air cleaner 10 - Fuel tank 4 - Choke knob 11 - Oil tank 5 - Throttle lever 12 - Left handle 6 - Right handle 13 - Saw chain... -
Page 4: Symbols On The Machine
GASOLINE CHAIN SAW IMPORTANT If warning seals peel off or become soiled and impossible to read. you should contact the dealer from which you purchased the product to order new seals and affix the new seals in the required location. WARNING Never remodel the product. - Page 5 GASOLINE CHAIN SAW it from skilled worker. f. Lack of sleep, tiredness or physical exhaustion results in lower attention spans, and this in turn leads to accidents and injury. Limit the amount of time of using the machine continuously to somewhere around 10 minutes per session, and take 10-20 minutes or rest between work sessions.
- Page 6 GASOLINE CHAIN SAW of the cutting object. Inspect the machine for worn, loose, or damaged parts. Never operate the machine that is damaged, improperly adjusted, or is not completely and securely assembled. Make sure that the saw chain stops moving when the throttle control trigger is released. ...
-
Page 7: Installing Guide Bar And Saw Chain
GASOLINE CHAIN SAW MAINTENANCE In order to maintain your product in proper working order, perform the maintenance and checking operations described in the manual at regular intervals. Always be sure to turn off the engine before performing any maintenance or checking procedures. WARNING The metallic parts reach high temperatures immediately after stopping the engine. -
Page 8: Fuel And Chain Oil
GASOLINE CHAIN SAW 5. Fit the chain cover to the power unit and fasten the nuts to finger tightness. 6. While holding up the tip of the bar, adjust the chain tension by turning the tensioner screw until the tie straps just touch the bottom side of the bar rail. -
Page 9: Operating The Engine
GASOLINE CHAIN SAW 7. OPERATING ENGINE STARTING ENGINE 1. Fill fuel and chain oil tanks respectively, and tighten caps securely. (F7) 2. Put the switch to “l” position. (F8) 3. While holding the throttle interlock. push in the side throttle lock button and release the throttle lever to hold it at the starting position. - Page 10 GASOLINE CHAIN SAW The chain oil flow can be changed by inserting a screwdriver in the hole on bottom of the clutch side. Adjust according to your work conditions. (F13) (1) Adjuster NOTE The oil tank should become nearly empty by the time fuel is used up. Be sure to refill the oil tank every time when refueling the unit.
- Page 11 GASOLINE CHAIN SAW HOW TO SWITCH BETWEEN OPERATING MODES (F15) 1. Flip the engine switch to turn off the engine. 2. Remove the air cleaner cover form the cylinder cover 3. Loosen a screw and remove the screen on the back of the air cleaner cover. 4.
-
Page 12: Sawing
GASOLINE CHAIN SAW STOPPING ENGINE 1. Release the throttle lever to allow the engine idling for a few minutes 2. Put the switch to the “O”(stop) Position. (F18) (1) Switch 8. SAWING WARNING Before proceeding to your job, read “For Safe Operation” section it is recommended to first practice sawing easy logs. - Page 13 GASOLINE CHAIN SAW WARNING When you fell a tree, be sure to warn your neighboring workers of the danger. (1) Notch cut (2) Felling cut (3) Felling direction BUCKING AND LIMBING WARNING Always ensure your foothold. Do not stand on the leg. ...
-
Page 14: Maintenance
GASOLINE CHAIN SAW 9. MAINTENANCE WARNING Before cleaning, inspecting or repairing your unit, make sure that engine has stopped and is cool. Disconnect the spark plug to prevent accidental starting. MAINTENANCE AFTER EACH USE 1. Air filter Dust on the cleaner surface can be removed by tapping a comer of the cleaner against a hard surface. - Page 15 GASOLINE CHAIN SAW 2. Spark plug (F30) Clean the electrodes with a wire brush and reset the gap to 0.65 mm as necessary. 3. Sprocket (F31) Check for cracks and for excessive wear interfering with the chain drive. If the wearing is found obviously. Replace it with new one.
-
Page 16: Maintenance Of Saw Chain And Guide Bar
GASOLINE CHAIN SAW 10. MAINTENANCE OF SAW CHAIN AND GUIDE BAR SAW CHAIN WARNING It is very important for smooth and safe operation to keep the cutters always sharp. Your cutters need to be sharpened when: Sawdust becomes powder-like. ... -
Page 17: Specifications
GASOLINE CHAIN SAW GUIDE BAR Reverse the bar occasionally to prevent partial wear. The bar rail should always be a square. Check for wear of the bar rail. Apply a ruler to the bar and the outside of a cutter. If a gap is observed between them, the rail is worn. Such a bar needs to be corrected or replaced. - Page 18 GASOLINE CHAIN SAW - Do not throw away the item with household waste at the end of life; - Take the item to a collecting point where it will be collected for free; - Please contact the local authorities for details on the collecting centers. Conformity with the RoHS Directive: the item you purchased is in conformity with the EU Directive RoHS (2011/65/UE).
