Minuteman E1000RM1U User Manual

Enterprise 1u rackmount series
Hide thumbs Also See for E1000RM1U:
Table of Contents

Advertisement

Quick Links

Download this manual
1-866-207-6631 | www.rackmountsolutions.net
sales@rackmountsolutions.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1000RM1U and is the answer not in the manual?

Questions and answers

Related Manuals for Minuteman E1000RM1U

Summary of Contents for Minuteman E1000RM1U

  • Page 1 1-866-207-6631 | www.rackmountsolutions.net sales@rackmountsolutions.net...

  • Page 2: Table Of Contents

    Enterprise 1U Rackmount Series User's Manual Introduction Controls and Indicators Installation Operation Troubleshooting Replacing the Battery Obtaining Service Specifications Configurable Parameters & Settings Limited Product Warranty Declaration of Conformity © Copyright Para Systems, Inc., 2005...

  • Page 3: Installation

    SAVE THESE INSTRUCTIONS ! Please read this manual before installing your Enterprise 1U Rackmount Se- ries UPS, models E700RM1U, E1000RM1U, E1500RM1U, as it provides im- portant information that should be followed during installation and maintenance of the UPS and batteries allowing you to correctly set up your system for the maximum safety and performance.
  • Page 4 Reconnect the power cord only after all signaling connections are made. WARNING: This Uninterruptible Power Supply contains potentially hazardous voltages. Do not attempt to disassemble the UPS beyond the battery replacement procedure. This UPS contains no user ser- viceable parts. Repairs and Battery replacement must be performed by QUALIFIED SERVICE PERSONNEL ONLY.

  • Page 5: Receiving Inspection

    NOTICE: This equipment has been tested and found to comply with the limits for a Class A computing device in accordance with the speci- fications in Subpart J of Part 15 of FCC Rules and the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference of the Canadian Department of Communications.
  • Page 6 Para Systems Life Support Policy As a general policy, Para Systems Inc. (Para Systems) does not recommend the use of any of its products in life support applications where failure or mal- function of the Para Systems product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effective- ness.

  • Page 7: Control Panel

    CONTROL PANEL The AC normal (green) LED illuminates in a steady state when the UPS is on and operating in the AC normal mode. The AC normal LED will extinguish when operating in the Battery mode. The On-Battery (green) LED illuminates in a steady state when the UPS is operating in the Battery mode.
  • Page 8 The Load Level Bar Graph operates as follows: LED #10: >10% load (green/red/yellow) LED will be green and illu- minated when there is at least 10% of the rated capacity. LED #30: >30% load (green/yellow) LED will be green and illumi- nated when there is at least 30% of the rated capacity.

  • Page 9: Installation & Placement

    REAR PANEL 1. The input power cord has a NEMA 5-15P Plug. 2. The input circuit breaker will trip in the event the load exceeds the UPS’s power rating. 3. The Battery Backup output power receptacles are NEMA 5-15R type. The output receptacles are electrically wired into two segments to support the "Load Shedding Function".

  • Page 10: Installation

    INSTALLATION Be sure to read the installation placement and all the cautions before installing the UPS. Place the UPS in the final desired location and complete the rest of the installation procedure. These UPSs are shipped with the internal batteries disconnected.

  • Page 11: Operation

    Installing the UPS in a 4-post rack USE CAUTION: The UPS is heavy. Use the appropriate number of personnel when installing the UPS. 1. Install the rails in the 4-post rack. (FIG. 1) 2. Install the rack ears on the UPS. (FIG. 2) 3.
  • Page 12 CONNECTING YOUR EQUIPMENT Plug the equipment into the output receptacles on the rear panel of the UPS. Do not use extension cords, adapter plugs or surge strips on the output of the UPS. Ensure that you do not exceed the maximum output rating of the UPS (refer to the information label on the UPS or the Electrical Specifications in this manual).

  • Page 13: System Overview

    SYSTEM OVERVIEW This Line-Interactive 1U Rackmount model UPS protects internetworking and telecommunications equipment from blackouts, brownouts, overvoltages, and surges. The AVR function continuously corrects the voltages, in-between the brownout and overvoltage transfer points (85 - 150VAC), to a safe usable level. When the UPS is operating in the AVR mode the audible alarm will remain silent and the Boost or the Buck indicator will blink.

  • Page 14: Dip Switch Settings

    SELF TEST The self test feature is useful to verify the correct operation of the UPS and the condition of the batteries. With the UPS in the AC normal mode, press and hold the On/Off/Test Button for four beeps, then release the button. The UPS will perform a ten-second self test.

  • Page 15: Power Monitoring Software

    OVERLOAD When the amount of load attached to the UPS exceeds its power rating, the Overload LED will illuminate and the UPS will sound a constant alarm. This alarm will remain on until the excess load is removed or the UPS’s self protec- tion circuit shuts the UPS down.
  • Page 16 Symptom On/Off/Test button not UPS will not turn on pushed Input AC circuit breaker is UPS operates in tripped battery mode only, even though there is normal AC present Fault LED is UPS has detected an illuminated internal fault Site Wiring Fault Incorrect service wiring LED is illuminated The AC normal...

  • Page 17: Replacing The Battery

    NOTE: If there is a power interruption while replacing the hot-swappable batteries, with the UPS on, the load will not be backed up. This Uninterruptible Power Supply contains potentially hazardous WARNING! voltages. Do not attempt to disassemble the UPS beyond the battery replacement procedure.

  • Page 18: Battery Replacement Procedure

    5. Unplug the computer interface cable from the rear panel of the UPS. 6. Grasp the front panel and gently pull the front panel off the UPS. (FIG. 2) 7. Lay the front panel on top of the UPS. FIG. 1 E1500RM1U E1000RM1U 4-6V9Ah HR9-6 UP-RW0645Ch1 UP-RW0645Ch1...
  • Page 19 8. Remove the four retaining screws for the battery retaining bracket. (FIG. 3) 9. Remove the battery retaining bracket. (FIG. 3) 10. Grasp the battery tray and gently pull the battery tray out far enough to get to the battery connectors (red and black). (FIG. 4) 11.

  • Page 20: Troubleshooting

    IF THE UPS REQUIRES SERVICE 1.Use the TROUBLESHOOTING section to eliminate obvious causes. 2.Verify there are no circuit breakers tripped. A tripped circuit breaker is the most common problem. 3.Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem call or fax MINUTEMAN Technical Support at the following numbers;...

  • Page 21: Specifications

    Nominal Voltage Voltage Regulation Frequency Voltage T.H.D. Dynamic Response Transfer Time Slew Rate Overload Capacity Protection SYSTEM SPECIFICATIONS E700RM1U E1000RM1U Line-Interactive, Sine Wave 700VA 1000VA 700W 490W INPUT Single (1∅ 2W +G) 120VAC 0 - 165VAC 85 - 150VAC 50 or 60 Hz, +/-6Hz, autosensing...

  • Page 22: Regulatory Compliance

    Battery Type Typical Recharge Time Typical Battery Life System Voltage Battery Quantity/Rating Runtime: Half Load Runtime: Full Load SURGE PROTECTION AND FILTERING Surge energy rating Surge current capability Surge response time Surge voltage let-through (as a percentage of an applied ANSI C62.41 Cat.
  • Page 23 (These items may require optional software or hardware) Factory Function Default UPS ID Enterprise 1U RM Series Date of Battery manufacture install date Battery 1826 life in days Enable/ Enabled Disable auto restart Enabled audible alarm state Shut- Entire UPS down Type 120VAC...
  • Page 24 Para Systems Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three years from the date of purchase. For equip- ment sites within the United States and Canada, this warranty covers repair or replacement of defective equipment at the discretion of Para Systems.

  • Page 25: Limited Product Warranty

    LIMITED PRODUCT WARRANTY (Continued) EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL PARA SYSTEMS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUEN- TIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, Para Sys- tems is not liable for any costs, such as lost profits or revenue, loss of equip- ment, loss of use of equipment, loss of software, loss of data, cost of substi- tutes, claims by third parties, or otherwise.

  • Page 26: Declaration Of Conformity

    Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) Manufacturer’s Address: 1455 LeMay Drive Type of Equipment: Uninterruptible Power Supplies (UPS) Model No: E700RM1U (Y), E1000RM1U (Y), E1500RM1U (Y) Year of Manufacture: Beginning August 1, 2005 I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s).
  • Page 27 Notes:...
  • Page 28 Para Systems, Inc. 1455 Lemay Dr. Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com PN - 34000256 Rev.1...
