- Page 1 ALLIANCE SERIES OWNER'S MANUAL...
-
Page 2: Table Of Contents
1. INTRODUCTION ……………………………………………………………... 2. RECEIVING INSPECTION …………………………………………………. 3. WARRANTY REGISTRATION ……………………………………………... 4. IMPORTANT SAFETY INSTRUCTIONS …………………………………... 5. ELECTRICAL SPECIFICATIONS …………………………………………… 6. TYPICAL RUN TIME VERSUS LOAD ……………………………………… 7. PHYSICAL SPECIFICATIONS ……………………………………………… 8. UNIT DESCRIPTION ………………………………………………………… 9. INSTALLATION AND TEST ………………………………………………… 10. -
Page 3: Introduction
INTRODUCTION The MINUTEMAN ALLIANCE Series Uninterruptible Power Supply (UPS) has been designed to be maintenance-free, and to provide years of excellent service. It will provide superior power protection for personal computers, telephone systems and other critical electronic equipment against all commercial power anomalies. Output waveform is a synchronized, simulated sinewave. - Page 4 These UPS units are intended for use in a temperature-controlled, indoor area free of conductive contaminants. Select a location, which will provide good air circulation for the UPS at all, times. Avoid locations near heating devices, water or excessive humidity, or where unit is exposed to direct sunlight.
-
Page 5: Electrical Specifications
ELECTRICAL SPECIFICATIONS RATED OUTPUT FREQ MODEL # WATTS A300 A300/2 A425 A425/2 A500 A500/2 A750 A750/2 A900 A900/2 A1250 1250 A1250/2 1250 A2000 1440 1400 A2000-41 1900 1400 A2000-43 1900 1400 A2000-44 2000 1400 A2000/2 2000 1400 * With maximum boost and maximum charge current. NOTE: 220VAC, 50 Hz models supply an output voltage of 220VAC, making them compatible with 220VAC, 230VAC and 240VAC utility systems. - Page 6 Input Voltage (AC Mode Function) 120 VAC Models 220 VAC Models Boost Capability (AC Mode Function) Transfer Voltage Adjustment Transfer Time Input Frequency Deviation for Synchronization Inrush Current Surge Protection RFI/EMI Filtering Inverter mode (Backup Operation) Waveform Crest Factor (Non-Linear Load) Overload Capacity (50 msec Maximum) Voltage Regulation Frequency Regulation...
-
Page 7: Typical Run Time Versus Load
TYPICAL RUN TIME vs. TYPICAL COMPUTER LOAD Computer A300 A425 Load 100VA 150VA 200VA 250VA 300VA 425VA 500VA 600VA 700VA 750VA 800VA 900VA 1000VA 1100VA 1250VA 1400VA 1600VA 1800VA 2000VA PHYSICAL SPECIFICATIONS Net Wt. Model (lbs.) A300 A425 A500 A750 A900 46.5 A1250... -
Page 8: Unit Description
Operating Temperature Storage Temperature Relative Humidity Maximum Altitude without Derate Acoustic Noise UNIT DESCRIPTION 1. Main Power Switch: Turns on all UPS functions except the internal battery charger. Charger operates when UPS is connected to commercial power. 2. Test Button: Depressing this button causes the UPS to switch to the Inverter mode (backup) for test. -
Page 9: Installation And Test
6. Input Fuse/Breaker: A300, A425, A900 and A1250 use a separate fuse holder for the input fuse; A2000 models use an input breaker. Other models have the input fuse located in the IEC 320 socket. 7. Output Receptacles: All 120VAC models use NEMA 5-15R receptacles (standard). The A2000 120VAC model has one receptacle position, which can be converted, to a locking receptacle. -
Page 10: Operation
SYSTEM BATTERIES The internal batteries used in the MINUTEMAN ALLIANCE UPS UNITS are sealed maintenance- free, lead-acid batteries with electrolyte totally absorbed in the plates and separator material. For maximum battery like, temperature should be kept as cool as practical indoors, and at proper trickle charge voltage. -
Page 11: Ups Monitoring Configurations
UPS MONITORING CONFIGURATIONS All models except A300 provide a UPS monitoring capability which will allow direct interface with many different computer operating systems. This capability permits an unattended, orderly shutdown of the computer system when commercial power is lost for a long period. Some configurations also provide for a shut down of the UPS after the computer has been shut down, thereby conserving UPS battery capability. -
Page 12: Service
SERVICE If any problem is encountered with your MINUTEMAN ALLIANCE UPS, contact your supplier or Para Systems customer service department. Prior to calling, please write down and be prepared to discuss UPS status indications and if the UPS supplies power in any mode. Following is a guide to assist you in locating some common problems. -
Page 13: Fuse Replacement
POLICY AND INSTRUCTION FOR RETURN OF PRODUCT TO PARA SYSTEMS Call Technical Support if you experience any problems with MINUTEMAN ALLIANCE Units. 1. If you wish to file a Platinum Protection Plan claim, request a claims packet from the Technical Support Representative. - Page 14 NOTE: Units returned for repair are found to have no function problem other than a blown, replaceable input fuse, tripped, re-settable input breaker (a2000) or discharged batteries will incur charges as stated in the above paragraph, even if these units are under warranty. PARA SYSTEMS, INC.
- Page 15 Model # _______________________ Date Purchased __________________________ UPS PRODUCT AND MINUTEMAN PLATINUM PROTECTION PLAN LIMITED UPS Model # _________________________ Serial # ___________________________ Date Purchased __________________________ Dealer's Name ___________________________________________________________ City/State ___________________________________ Zip ________________________ Your Name __________________________________ Tel. ________________________ Company Name (if applicable) _______________________________________________ Address ________________________________________________________________ City/State __________________________________ Zip __________________________ CONNECTED EQUIPMENT (Necessary for Platinum Protection)
