Mio C710 User Manual

Hide thumbs Also See for C710:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Mio C710
Mio DigiWalker
User's Manual
Trademarks
All brand and product names are trademarks or registered trademarks of their
respective companies.
Note
The information in this manual is subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C710 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mio C710

Summary of Contents for Mio C710

  • Page 1 Mio C710 Mio DigiWalker User’s Manual Trademarks All brand and product names are trademarks or registered trademarks of their respective companies. Note The information in this manual is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Getting Started................1 1.1 Performing the Initial Start Up .............. 1 1.2 Connecting to AC Power and Charging the Battery......2 1.3 Using Your Device in a Vehicle............3 Using the Car Holder................3 Connecting the Car Charger ..............4 1.4 Understanding Hardware Features ............
  • Page 4 Regulatory Information..............31 4.1 Regulations Statements ..............31 Class B Regulations ................31 European Notice................. 33 4.2 Safety Precautions ................34 About Charging................... 34 About the AC Adapter ................ 34 About the Battery................35...

  • Page 5: Before You Begin

    Before You Begin Precautions and Notices For your own safety, do not operate the controls of the product while driving. Use this product prudently. The product is intended to be used only as a navigation aid. It is not for precise measurement of direction, distance, location or topography.
  • Page 6 A car holder is needed when using the device in a car. Be sure to place the device in an appropriate place, so as not to obstruct the driver’s view, or deployment of airbags. Do not mount where the driver’s Do not place unsecured field of vision is blocked.

  • Page 7: Getting Started

    Getting Started This chapter tells you step by step how to perform the initial startup and introduces the components of your device. 1.1 Performing the Initial Start Up 1. Use a pointed pen to slide the ON/OFF switch to the ON position. CAUTION: Always leave the ON/OFF switch in the ON position for normal operation.

  • Page 8: Connecting To Ac Power And Charging The Battery

    1.2 Connecting to AC Power and Charging the Battery Fully charge the battery before using your device for the first time. 1. Slide and click the connector converter onto the AC adapter. 2. Connect the adapter cable to the bottom of your device. 3.

  • Page 9: Using Your Device In A Vehicle

    1.3 Using Your Device in a Vehicle A car holder and a car charger are supplied with your device. Using the Car Holder CAUTION: Select an appropriate location for the car holder. Never place the holder where the driver’s field of vision is blocked. If the car’s windshield is tinted with a reflective coating, an external antenna (optional) may be needed to route the antenna to the top of the car through a window.

  • Page 10: Connecting The Car Charger

    Connecting the Car Charger The car charger supplies power to your device when you are using the device in a car. CAUTION: To protect your device against sudden surges in current, connect the car charger only after the car engine has been started. 1.

  • Page 11: Understanding Hardware Features

    1.4 Understanding Hardware Features NOTE: Depending upon the specific model purchased, the color of your device may not exactly match the device shown in this manual. Front Components Component Description Touch Screen Displays the output of your device. Tap the screen with your fingertip to select menu commands or enter information.

  • Page 12: Back Components

    Back Components Component Description External Antenna This connector (under rubber dust cover) allows use of an Connector optional external antenna with magnetic mount, which may be positioned on top of the car for better signal reception in areas with poor reception. Speaker Sends out music, sounds and voice.

  • Page 13: Top Components

    Top Components Component Description Receives signals from the GPS satellites overhead. Make sure GPS antenna that it has a clear view of the sky. SD/MMC Slot Accepts a SD (Secure Digital) or MMC (MultiMediaCard) card for accessing data such as MP3 music. Bottom Components Component Description...

  • Page 15: Basic Skills

    Basic Skills This chapter familiarizes you with the basic operations of your device such as using the Home screen and the hardware components. 2.1 Turning On and Off Your Device Use the power button on the side of your device to turn on and off your device. When you press the power button to turn off the unit, your device actually enters a suspend state and the system stops operating.

  • Page 16: Using A Sd/Mmc Card

    2.3 Using a SD/MMC Card Your device has a SD/MMC slot where you can insert an optional Secure Digital or MultiMediaCard storage card. NOTE: Make sure that no foreign objects enter the slot. Keep a SD or MMC card in a well-protected box to avoid dust and humidity when you are not using it.

  • Page 17: Bluetooth And Dialer

    Bluetooth and Dialer 3.1 Using Bluetooth Your device incorporates Bluetooth capability. Bluetooth is a short-range wireless communications technology. Devices with Bluetooth capabilities can exchange information over a distance of about 10 meters (30 feet) without requiring a physical connection. A Bluetooth program called BlueSoleil is built into your device. The program includes eight Bluetooth application profiles: Headset, HandFree, Intercom, PAN, DUN, SPP, OPP, and FTP.

  • Page 18: Exploring Bluetooth Devices

    Exploring Bluetooth Devices 1. Tap the Bluetooth icon and tap Bluetooth Manager 2. Tap . You can tap the button to search Explore a Bluetooth Device Refresh nearby devices. 3. Tap the target device to pop up the function menu. 4.

  • Page 19: Transferring Files Via Bluetooth

    5. Tap the service you want to use and tap to connect. Pair Device Transferring Files via Bluetooth You can transfer files between your device and a remote Bluetooth device. 1. Tap the Bluetooth icon and tap Bluetooth Manager 2. Tap .
  • Page 20 3. Tap the target device to establish a FTP (File Transfer Profile) connection. 4. The File Explorer window appears. To access the remote or local device, use the buttons at the bottom of the screen. 5. Tap and hold on an item to display the shortcut menu. You can use download/upload and delete operations.

  • Page 21: Using Activesync Via Bluetooth

    Using ActiveSync via Bluetooth You can use ActiveSync via Bluetooth. 1. Tap the Bluetooth icon and tap Bluetooth Manager 2. Tap . You can tap the button to search nearby ActiveSync via Bluetooth Refresh devices. 3. Tap the target device to pop up the function menu and tap r to start Partne ActiveSync connection.

  • Page 22: Partnering With A Hands-Free Device

    5. Tap . You can tap the button to search nearby Intercom via Bluetooth Refresh devices. 6. Tap the target device to establish an ICP connection. 7. A dialog box will appear on your device and the recipient’s device. The recipient can choose to answer or ignore your call.
  • Page 23 3. Tap the target device to partner with it. 4. Enter the passkey requested and tap...

  • Page 24: Configuring Bluetooth Settings

    Configuring Bluetooth Settings Tap the Bluetooth icon and tap Bluetooth Manager Tools Bluetooth Settings There is a total of eight pages to configure the Bluetooth server’s and client’s attributes. Page Descriptions General This page lets you edit local device information. Paired Device This page lets you view paired devices.
  • Page 25 Page Descriptions Serial Port This page lets you configure the SPP attributes such as security and COM port. File Transfer This page lets you configure the FTP attributes such as security, shared folder, and read/write option. Object Exchange This page lets you configure the OPP attributes such as security and business card location.

  • Page 26: Using My Shortcuts

    Page Descriptions Personal Network This page lets you configure the PAN attributes such as security. Hands-free This page lets you configure the hands-free device attributes such as functionality and security. Using My Shortcuts Once you have established a Bluetooth connection with a remote device, it will be saved as a shortcut.

  • Page 27: Viewing Active Connections

    3. Tap and hold the desired item. Tap to establish a connection again. Connect Viewing Active Connections To view active outgoing and incoming connections: 1. Tap the Bluetooth icon and tap Bluetooth Manager 2. Tap Tools Active Connections...
  • Page 28 3. When you tap and hold an item, you can disconnect it or view the status of the connection.

  • Page 29: Dialer

    3.2 Dialer The Dialer program allows you to use your device as a hands-free device for a Bluetooth-enabled mobile phone. You can tap your device to place and receive calls instead of pressing the phone’s keypad. Connecting a Bluetooth Mobile Phone 1.

  • Page 30: Placing A Call

    Placing a Call After pairing with your mobile phone, you can place a call using any of the four buttons ( , and ) on the main screen. Keypad Contacts Call History Redial Keypad Tap the button on the main screen and you can enter the telephone number Keypad with the onscreen keypad.
  • Page 31 If there is more than one telephone number for a contact, tapping the contact opens the detailed screen where you can select a number. Call History Tap the button on the main screen to display the recent incoming, Call History outgoing, or missed calls together with information such as date, time, and duration of each call.

  • Page 32: Operations During A Call

    Redial Tap the button on the main screen to dial the last number you called or Redial received. Operations During a Call During a call, four functions are available: If you need to input other numbers, such as an extension number, tap open the keypad and tap the desired digits.

  • Page 33: Receiving A Call

    to switch the call to your mobile phone. To switch back to your device, tap the same button again. Receiving a Call When you have a call after pairing with your mobile phone, you will see the “Incoming Call” screen. To accept the call, tap To reject the call, tap To mute the ring tone before receiving or rejecting, tap...

  • Page 34: Miscellaneous Buttons

    Miscellaneous Buttons In addition to buttons for placing a call, there are Connect Pair Mode Others , and Exit buttons on the main screen as described below. Connect By tapping the button on the main screen, you can manually search the last Connect paired mobile phones for an available connection.
  • Page 35 Others By tapping the button on the main screen, you can run the BlueSoleil Others program. (See section 6.3 for information on BlueSoleil.) Exit To close the Dialer screen, tap the button on the main screen. Exit...

  • Page 37: Regulatory Information

    Regulatory Information NOTE: Marking labels located on the exterior of your device indicate the regulations that your model complies with. Please check the marking labels on your device and refer to the corresponding statements in this chapter. Some notices apply to specific models only. 4.1 Regulations Statements Class B Regulations Federal Communications Commission Radio Frequency Interference Statement...
  • Page 38 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Please note: The use of a non-shielded interface cable with this equipment is prohibited.

  • Page 39: European Notice

    Canada Canadian Department Of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. European Notice Products with the CE marking comply with Radio &...

  • Page 40: Safety Precautions

    The manufacturer cannot be held responsible for modifications made by the User and the consequences thereof, which may alter the conformity of the product with the CE Marking. 4.2 Safety Precautions About Charging Use only the AC adapter (PHIHONG, PSC05R-050 or ADP-5FH) supplied with your device.

  • Page 41: About The Battery

    About the Battery Use a specified charger approved by the manufacturer. CAUTION: This unit contains a non-replaceable internal Lithium Ion battery. The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush, puncture, or dispose of in fire or water.
