  • Page 1 TP8-96 VI TP8-96 VI TP8-96 VI TP8-96 VI TP8-96 VI 8 TO 96 ZONES EXPANDIBLE CONTROL PANEL WITH INTEGRATED ETHERNET EN 60950-1 EN 50130-4 EN 50081-1 USER MANU USER MANU USER MANU USER MANU USER MANUAL Release: Update March 2011 Language: English FW version...
  • Page 2 The product features can be subject to change without notice. Unauthorized reproduction or distribution of this manual, or any portion of it, on any device and in any form, is prohibited. The contents of this manual may be subject to change without notice User manual TP8-96 VIDEO Ver.1.0 - 03/11...
  • Page 3 CONFORMITY Hereby, Tecnoalarm srl declares that the present equipment is in compliance with the essential requirements and other relevant provisions of the R&TTE 1999/05/EC directive. The declaration of conformity is available on the website: www.tecnoalarm.com. TP8-96 VIDEO User manual Ver.1.0 - 03/11...
  • Page 4 User manual TP8-96 VIDEO Ver.1.0 - 03/11...

  • Page 5: Table Of Contents

    Index 1 - General features TP8-96 VIDEO system....................... Page 7 Master code..........................Page 7 Standard user code........................Page 8 Control by telephone........................Page 8 Functioning...........................Page 8 2 - Console LCD300/S Signaling of the console LCD300/S..................Page 9 Arming - Single and multiple arming..................Page 11 Arming - Direct arming.......................
  • Page 6 Keys menu........................... Page 39 Wireless key menu........................Page 41 Consoles menu..........................Page 43 Keypoint menu..........................Page 45 Exclusion menu..........................Page 46 Test menu.............................Page 47 Option menu..........................Page 49 5 - Controle by telephone Remote control ..........................Page 50 User manual TP8-96 VIDEO Ver.1.0 - 03/11...

  • Page 7: General Features

    General features TP8-96 VIDEO SYSTEM The security system TP8-96 VIDEO is a new generation equipment which is able to control up to 96 zones. The control panel is programmed by the installer using a PC or the console LCD300/S. The end user can make simple settings through the console.

  • Page 8: Standard User Code

    The programs group the zones which are enabled for the detection of the alarms when the program is armed. The programs can be armed one at time (single arming) or several simultaneously. User manual TP8-96 VIDEO Ver.1.0 - 03/11...

  • Page 9: Signaling Of The Console Lcd300/S

    The signaling of alarm memory continues until it is reset. The general alarms are stored in the event buffer. If the LED is blinking slowly, it signals a general alarm. If it is blinking quickly, it signals a GSM trouble. TP8-96 VIDEO User manual Ver.1.0 - 03/11...
  • Page 10 ON - alarm memory. Mains power has been missing. Mains power LED The LED signals the presence of mains power (230V AC). The mains power LED can be: OFF - mains power is missing ON - mains power is present User manual TP8-96 VIDEO 1-10 Ver.1.0 - 03/11...

  • Page 11: Arming - Single And Multiple Arming

    How can all the programs associated to the code be armed simultaneously? (direct arming) The arming procedure described below permits direct arming of all the programs associated to the code. A - Enter the code B - Press YES to confirm arming of the programs TP8-96 VIDEO User manual 1-11 Ver.1.0 - 03/11...

  • Page 12: Disarming - Single And Muultiple Disarming

    The disarming procedure described below permits direct disarming of all the programs associated to the code. A - Enter the code B - Press NO to confirm disarming of the programs User manual TP8-96 VIDEO 1-12 Ver.1.0 - 03/11...

  • Page 13: Arming - Exclusion Of Open Zones

    To release the hold-up alarm, enter a valid code but decrease or increase it by one unit. For example, the master code is 54321. Decrease the last digit by one unit, e.g. 54320. Alternatively, increase the last digit by one unit, e.g. 54322. TP8-96 VIDEO User manual 1-13 Ver.1.0 - 03/11...

  • Page 14: Panic Alarm Release

    The program status (armed/disarmed) does not interfere with the panic alarm release. The alarm can be released anytime. A - To release the panic alarm, press the arrow up and arrow down keys simultaneously on the LCD300/S console. User manual TP8-96 VIDEO 1-14 Ver.1.0 - 03/11...

  • Page 15: Signaling Of The Prox K6N

    The LED blinks for the entire duration of the alarm. Once the alarm has stopped, the LED remains lit to signal alarm memory. The signaling of alarm memory is active until the next arming. Zone status The open zones are signaled only during the arming phase. TP8-96 VIDEO User manual 1-15 Ver.1.0 - 03/11...

  • Page 16: Arming

    B - Within 10 seconds, select the numbers of the programs to be armed. The yellow program LED of the program blinks quickly (arming phase). Then, the LED remains lit signaling that the program is armed. User manual TP8-96 VIDEO 1-16 Ver.1.0 - 03/11...

  • Page 17: Bypass

    (the green transponder LED is lit). B - Within 10 seconds enter the numbers of the programs to be partset. The yellow program LED starts blinking slowly signaling that the armed program is partset. TP8-96 VIDEO User manual 1-17 Ver.1.0 - 03/11...

  • Page 18: Panic Alarm Release

    The panic alarm is released by simultaneous pressing of the F1 and F3 keys. The status of the programs (armed/ disarmed) does not have any effect on panic alarm release. The alarm can be released anytime. A - To release the panic alarm, press the F1 and F3 keys simultaneously User manual TP8-96 VIDEO 1-18 Ver.1.0 - 03/11...

  • Page 19: Access To Programming

    If you know the number of the menu you can use the other way, i.e. enter the menu by typing the corresponding number. 3 - Sequence of the menus The opposite figure shows the TP8-96 VIDEO programming menus. The arrow up and arrow down keys permit to scroll the programming menus.

  • Page 20: Clock Menu

    Press YES to enable the zone. Press NO to disable the zone. Repeat the same operations for the other zones. To quit the menu press EXIT. Select another menu or press EXIT to quit programming. User manual TP8-96 VIDEO 1-20 Ver.1.0 - 03/11...

  • Page 21: Program Menu

    Programs Program menu The TP8-96 VIDEO system is able to control up to 8 programs. Each program is composed of a group of zones and has its own functioning parameters. The program menu permits programming of the zones and the functioning parameters.
  • Page 22 Select the submenu, press 7 and YES. Use the number keys to set the minutes. Press the arrow key. Use the number keys to set the seconds. To confirm and quit the submenu press EXIT. User manual TP8-96 VIDEO 1-22 Ver.1.0 - 03/11...

  • Page 23: Time Menu - Timers

    Time - Timers Time Time menu - Timers The TP8-96 VIDEO system provides 16 timers which allow to schedule the automatic operations. For each timer 4 parameters can be programmed: action, attribute, program/remote control and time. TP8-96 VIDEO User manual 1-23 Ver.1.0 - 03/11...
  • Page 24 Select the submenu, press 3 and YES. Select the program. Press YES to associate the program. Press NO to undo the association. N.B. It is possible to associate several programs. To confirm and quit the submenu press EXIT. User manual TP8-96 VIDEO 1-24 Ver.1.0 - 03/11...

  • Page 25: Time Menu - Access Periods

    Time menu - Access periods The TP8-96 VIDEO system provides 8 access periods. The access periods allow to limit enabling of the codes to a precise period of time and thus to regulate the access to the areas protected by the system.
  • Page 26 It determines the frequency of the access period, i.e. how often the access period is started. Select the submenu, press 1 and YES. Select the attribute. To confirm and quit the submenu press EXIT. User manual TP8-96 VIDEO 1-26 Ver.1.0 - 03/11...
  • Page 27 Use the number keys to set the minutes. To confirm and quit the submenu press EXIT. To quit the access period submenu press EXIT. To quit the time menu press EXIT. To quit programming press EXIT. TP8-96 VIDEO User manual 1-27 Ver.1.0 - 03/11...

  • Page 28: Telephone Menu - Gsm

    Telephone menu - GSM The GSM/GPRS telephone interface is integrated inCPU board. The GSM is the main communication channel of the TP8-96 VIDEO system. The GSM menu is composed of a series of submenus which permit parametrization of the GSM interface.
  • Page 29 SIM card of the system. On the display is viewed "Waiting" (blinking). Once the message has been received on the display is viewed "Completed". To confirm and quit the submenu press EXIT. TP8-96 VIDEO User manual 1-29 Ver.1.0 - 03/11...
  • Page 30 Programming of the second number of the white list. Select the submenu, press 17 and YES. Use the number keys to enter the telephone number. To delete use the arrow key. To confirm and quit the submenu press EXIT. User manual TP8-96 VIDEO 1-30 Ver.1.0 - 03/11...

  • Page 31: Telephone Menu - Tecnocell

    Telephone Telephone menu - External GSM communicator The TP8-96 VIDEO system can be equipped with an additional GSM telephone communicator. The Tecnocell menu provides a series of submenus which permit parametrization of the external GSM communicator. Select the telephone menu - Press the YES key Select Tecnocell, press 4 and YES.
  • Page 32 Press NO to disable the digital data channel. To confirm and quit the submenu press EXIT. To quit the Tecnocell submenu press EXIT. To quit the telephone menu press EXIT. To quit programming press EXIT. User manual TP8-96 VIDEO 1-32 Ver.1.0 - 03/11...

  • Page 33: Telephone Menu - Channels

    Telephone menu - Telephone channels The TP8-96 VIDEO system is equipped with 8 telephone channels. Each channel can be programmed with 2 telephone numbers which are called by the system according to programming. These telephone numbers are used to send the associated events.

  • Page 34: Telephone Menu - Call Back

    Telephone Telephone menu - Call back The call back function permits the bidirectional communication between the TP8-96 VIDEO system and the Tecnoalarm software. Thanks to the call back function, the installer is able to check the system's functioning and to modify programming according to the user's needs.

  • Page 35: Code Menu - Master Code

    Warning - The code length can be 4, 5 or 6 digits (according to programming) and cannot be changed. To confirm and quit the submenu press EXIT. TP8-96 VIDEO User manual 1-35 Ver.1.0 - 03/11...
  • Page 36 To confirm and quit, press EXIT. To quit the attribute submenu press EXIT. To quit the master submenu press EXIT. To quit the code menu press EXIT. To quit programming press EXIT. User manual TP8-96 VIDEO 1-36 Ver.1.0 - 03/11...

  • Page 37: Code Menu - Standard User Codes

    Compared with the master code, the functions of the standard user codes are limited. They cannot access to the programming menus. The TP8-96 VIDEO system manage up to 200 user codes. For each of them it is possible to define a personal functioning profile.
  • Page 38 To confirm and quit the submenu press EXIT. To quit the attribute submenu press EXIT. To quit the user code submenu press EXIT. To quit the code menu press EXIT. To quit programming press EXIT. User manual TP8-96 VIDEO 1-38 Ver.1.0 - 03/11...

  • Page 39: Keys Menu

    Transponders Keys Key menu The TP8-96 VIDEO system is able to manage up to 100 transponders. For each of them it is possibile to define a personale functioning profile. Select the key menu - Press the YES key 1 - Select the transponder On the display are viewed the name and the number of the transponder.
  • Page 40 Repeat the same operations for the other transponders. To confirm and quit the learning submenu press EXIT. To quit the transponder press EXIT. To quit the key menu press EXIT. To quit programming press EXIT. User manual TP8-96 VIDEO 1-40 Ver.1.0 - 03/11...

  • Page 41: Wireless Key Menu

    WL keys Wireless key menu The TP8-96 VIDEO system is able to manage up to 100 wireless keys. For each of them it is possible to define a personale functioning profile. Select the WL key menu - Press the YES key "...
  • Page 42 Repeat the same operations with the other wireless keys. To confirm and quit the learning submenu press EXIT. To quit the wireless key press EXIT. To quit the wireless key menu press EXIT. To quit programming press EXIT. User manual TP8-96 VIDEO 1-42 Ver.1.0 - 03/11...

  • Page 43: Consoles Menu

    On the display is viewed the number of the console. Select the console and press YES. 6 - Volume Set the volume of the console. To confirm and quit the submenu press EXIT. TP8-96 VIDEO User manual 1-43 Ver.1.0 - 03/11...
  • Page 44 Repeat the same operations for the other LED. To quit the LED submenu press EXIT. To quit the console press EXIT. To quit the console menu press EXIT. To quit programming press EXIT. User manual TP8-96 VIDEO 1-44 Ver.1.0 - 03/11...

  • Page 45: Keypoint Menu

    Repeat the same operations for the other LED. To quit the LED submenu press EXIT. To quit the keypoint press EXIT. To quit the keypoint menu press EXIT. To quit programming press EXIT. TP8-96 VIDEO User manual 1-45 Ver.1.0 - 03/11...

  • Page 46: Exclusion Menu

    Press NO to include the zone Repeat the same operations for the other zones. To confirm and quit the submenu press EXIT. Exclusion submenus The procedure is the same as the one illustrated in the zone submenu. User manual TP8-96 VIDEO 1-46 Ver.1.0 - 03/11...

  • Page 47: Test Menu

    Select the submenu, press 4 and YES. This function verifies the correct functioning of the outdoor sirens. It makes them sound until they are interrupted by pressing EXIT. To quit the submenu press EXIT. TP8-96 VIDEO User manual 1-47 Ver.1.0 - 03/11...
  • Page 48 On the display are viewed in sequence all three items. The informations are viewed until the test is interrupted by pressing EXIT. To quit the submenu press EXIT. To quit the test menu press EXIT. To quit the programming press EXIT. User manual TP8-96 VIDEO 1-48 Ver.1.0 - 03/11...

  • Page 49: Option Menu

    Menu Options Options Option menu The option menu... TP8-96 VIDEO User manual 1-49 Ver.1.0 - 03/11...

  • Page 50: Controle By Telephone

    RDV zones, etc. System status check After entering the access code, select the menu 1. The system announces system OK or lists the stored alarms. User manual TP8-96 VIDEO 1-50 Ver.1.0 - 03/11...
  • Page 51 RDV detector, the system announces "RDV verification refused". If you select a zone which is protected by an RDV detector, the system transmits the detected movement for 30 seconds. TP8-96 VIDEO User manual 1-51...
  • Page 52 Recording - To record the opening message press 1. 2 beeps signal recording; maximum recording time is 10 seconds. The expiry of the recording time is signaled by 2 other beeps. Listening - To listen to the recorded message press 2. The opening message is then reproduced by the system. User manual TP8-96 VIDEO 1-52 Ver.1.0 - 03/11...
  • Page 53 TP8-96 VIDEO User manual 1-53 Ver.1.0 - 03/11...
