Summary of Contents for TCL LIFESENSE DS01
- Page 1 Quick Start Guide CJB1H9002AAA...
-
Page 2: What's In The Box
What's In The Box? LIFESENSE x 1 Quick Start Guide x 1 Double-sided tape x 1... -
Page 3: Specification
Specification Product name LIFESENSE Model name DS01 Operating frequency 2.4 GHz Transmitted power 8±2dbm Battery model CR2032 Battery life >2 years Installation distance <20mm... -
Page 4: Led Indicators
Getting to Know Your LIFESENSE The LIFESENSE sensor is an open/closed sensor for indoor use. With this device, you can monitor the open/closed status of any door or window in your home, garage or cabinet, for example. Note: This device requires a LIFECONNECT in order to work. Magnet LED indicator Reset hole... - Page 5 Adding Your LIFESENSE 1. Make sure that the LIFECONNECT is connected with your router. 2. Open your LIFE App, log in to your account and select “+” in the App. Follow the on-screen instructions in the App to add and configure your LIFESENSE.
- Page 6 Installing Your LIFESENSE Sensor Magnet 1. Remove the protective film of the double-sided tape. 2. Mount the sensor on your door/window frame and the magnet on the door/window itself. (Ensure that the gap between the magnet and the sensor is less than 20mm.) Notes: •...
- Page 7 Disconnecting from current network If you want to remove the LIFESENSE from your current network, use one of the following two methods: • Long press the reset hole until the LED light flashes blue. • Remove from the App as follows: 1.
-
Page 8: Replacing Battery
Replacing Battery To replace the battery, open your LIFESENSE and insert a new CR2032 battery. - Page 9 Q: How long will my LIFESENSE work for? A: Your LIFESENSE uses a coin cell battery, with a lifespan of up to 2 years. (based on 10 open/closed occurrences per day; battery life will vary according to the level of usage). Q: Can my LIFESENSE be used outside? A: The LIFESENSE is for indoor use only.
-
Page 10: Safety And Use
Safety and Use Electronic Devices Turn off your device near high-precision electronic devices. The wireless device may affect the performance of these devices. Such devices include hearing aids, pacemakers, fire alarm systems, automatic gates, and other automatic devices. If you are using an electronic medical device, consult the device manufacturer to confirm whether radio waves affect its operation. - Page 11 ers with strong magnetic fields, such as an induction cooker or a microwave oven. Otherwise, circuit failure, fire, or explosion may occur. • Do not leave your wireless device in a very hot or cold place. Otherwise, malfunction of the product, fire, or explosion may oc- cur.
- Page 12 • Do not use the wireless device in dusty, damp and dirty places or within magnetic fields. Otherwise, malfunction of the circuitry may occur. • The wireless device may interfere with nearby TV sets, radios and PCs. • In accordance with international standards for radio frequency and radiation, use wireless device accessories approved by the manufacturer only.
- Page 13 environmental conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). • When this device is switched on, it should be kept at least 20 cm from the body. • When this device is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc.
- Page 14 Certification This symbol on the device means that these products must be taken to collection points at the end of their life: - Municipal waste disposal centres with specific bins for these items of equipment. - Collection bins at points of sale. They will then be recycled, preventing substances being disposed of in the environment and allowing their components to be reused.
-
Page 15: Radio Waves
Radio Waves THIS DEVICE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. - Page 16 harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
- Page 17 These precautions will help prevent unauthorized access to your device. Choose your apps and updates carefully, and install from trusted sources only. Note that any data shared with TCL Communication Ltd. is stored in accordance with applicable data protection legislation. For these purposes TCL Communication Ltd.
- Page 18 - The technical possibilities available; - The costs for implementing the measures; - The risks involved with the processing of the personal data, and; - The sensitivity of the personal data processed. You can access, review and edit your personal information at any time by logging into your user account, visiting your user profile or by contacting us directly.
-
Page 19: Warranty
Lisense FCC: 2ACCJBC04 Warranty The device is warranted against any deviation from technical specifications for a period of twelve (12) months from the date specified on your original invoice. Batteries and accessories sold with your device are also warranted against any defect which may occur during the first six (6) months from the date of purchase as shown on your original invoice. - Page 20 2) Not being compliant with technical and safety standards applicable in the geographical area where this device is used. 3) Improper maintenance of sources of energy, and of the overall electric installation. 4) Accidents or consequences of theft of the vehicle in which this device is transported, acts of vandalism, lightning, fire, humidity, infiltration of liquids, inclement weather.
- Page 21 All rights reserved © 2017 TCL Communication LTD. Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road, Tsimshatsui, Kowloon, Hong Kong...
