NVR Quick Start Guide
READ ME
FIRST!
Welcome! Lets get started.
• Getting to know your NVR
• What does this mean?
• Connect your Cameras
• Connect the NVR to your Local Network
• Connect the Mouse
• Connect the NVR to your HDTV
• Connect the NVR to your Monitor
• Connect the Power Adapter
QH_7300H040416E | © Swann 2016
1 1
Advertisement
Table of Contents
Related Manuals for Swann NVRx-7300 series
Summary of Contents for Swann NVRx-7300 series
- Page 1 • Connect your Cameras • Connect the NVR to your Local Network • Connect the Mouse • Connect the NVR to your HDTV • Connect the NVR to your Monitor • Connect the Power Adapter QH_7300H040416E | © Swann 2016...
-
Page 2: Getting To Know Your Nvr
Getting to know your NVR Congratulations on the purchase of your Swann NVR. This quick start guide will assist you on getting your NVR up and running as soon as possible. We recommend that you connect everything and give it a try before you do a permanent installation, to make sure nothing was damaged during shipping. -
Page 3: What Does This Mean
What does this mean? 11) HDD LED Here are explanations for the various connections and - This will flash when the hard drive is lights on the NVR - working. 1) Power - This is where you connect the power adapter. 12) LAN LED - This will flash when there is network activity. -
Page 4: Connect Your Cameras
Connect your Cameras To connect your camera(s) to the NVR, simply connect the supplied Ethernet cable to the LAN connection on the camera then plug the other end of the Ethernet cable into one of the camera inputs on the back of the NVR. eSATA AUDIO DC 48V... - Page 5 Connect the NVR to your Local Network Connect the Ethernet cable (supplied) to the LAN connection on the NVR, and then connect the other end to a spare port on your router or wireless access point. eSATA AUDIO DC 48V HDMI Please note - It’s important that you do this as this allows you to access the NVR from your smartphone or tablet...
-
Page 6: Connect The Mouse
Connect the Mouse Connect the mouse (supplied) to the USB port located at the rear of the NVR. eSATA AUDIO DC 48V HDMI Please note - Bluetooth and wireless mice and trackpad devices are not supported. Not all USB storage devices are supported. - Page 7 Connect the NVR to your HDTV Connect the HDMI cable (supplied) to the HDMI input on the NVR, and connect the other end to a spare HDMI input on the TV. Make sure your HDTV input matches the physical connection used to connect your NVR. HDMI IN 2 HDMI IN 1 eSATA...
- Page 8 Connect the NVR to your Monitor If you have a Monitor with a VGA connection, connect a VGA cable (not supplied) to the VGA output on the NVR, and connect the other end to the VGA input on the Monitor. You can skip this step if you are using the supplied HDMI cable. A VGA cable and monitor are not required when eSATA...
-
Page 9: Connect The Power Adapter
Connect the Power Adapter Connect the power adapter (supplied) to the power input on the NVR. Connect the power cable (supplied) to the power adapter and plug the other end to a wall socket. eSATA AUDIO DC 48V HDMI All connections have now been completed. You’re now ready to run through “The Setup Wizard” to configure your NVR.
