- Page 1 READ ME FIRST 4/8 Channel Network Video Recorder Hardware Quick Start Guide Welcome! Lets get started. QH48_7400040416E | © Swann 2016...
- Page 2 1 Getting to know the NVR Congratulations on your purchase of Swann’s latest NVR security system! This guide will show you how to connect your cameras, HDTV, and other peripherals to the NVR in a few easy steps. For an overview of the NVR hardware connections, see the reverse side of this guide.
-
Page 3: What Does This Mean
2 What does this mean? Here is a quick overview of the various connectors and lights on the NVR: Power LED Lights up when your NVR has power. HDD LED Blinks when hard drive is active. Network LED Blinks when network connection is active. An extra USB port to plug your USB flash drive into the NVR, if necessary, USB port for copying important video files from the NVR’s hard drive or upgrading the... -
Page 4: Connect The Cameras
3 Connect the cameras Plug one end of the long Ethernet cable into the “LAN” connector on a camera and plug the other end into any available network camera port on the back of the NVR. Repeat this step until you have connected all your cameras to the NVR. - Page 5 4 Connect to your router To connect the NVR to the Internet, connect one end of the short Ethernet cable to the LAN port on the back of the NVR, and then connect the other end to a spare port on your Internet- connected router.
-
Page 6: Connect The Mouse
5 Connect the mouse Connect the mouse to the NVR by plugging the mouse USB connector into the USB port on the back of the NVR. eSATA AUDIO DC 48V HDMI... - Page 7 6 Connect to your HDTV Connect one end of the HDMI cable to the HDMI port on the NVR and the other end to a spare HDMI input on your high-definition TV. HDMI IN 1 HDMI IN 2 eSATA AUDIO DC 48V HDMI HDMI cable...
- Page 8 7 (Optional) Connect to your monitor The NVR can also support an additional VGA monitor. Connect the monitor to the NVR with a VGA cable (not supplied) and the NVR will automatically detect the additional display. eSATA AUDIO DC 48V HDMI VGA cable (not supplied)
-
Page 9: Connect The Power Adapter
8 Connect the power adapter Connect one end of the power adapter to the power input on the back of the NVR, and then connect the other end to a power outlet. eSATA AUDIO DC 48V HDMI Congratulations! You have finished the hardware setup of your NVR. Next, follow Welcome to the Setup Wizard! The Setup Wizard directions in the Setup Wizard Guide (red cover) which will walk you through the automatically runs the first time you start your NVR and will... - Page 10 NVR Hardware Connections Overview Camera Reset button Not required Power Adapter Ethernet cable CAMERA PORT Internet Router eSATA AUDIO DC 48V HDMI Mouse Ethernet Ethernet cable Monitor (optional) HDTV HDMI VGA cable cable (not supplied) What are the additional connectors for? Audio Output: Connect to your HDMI IN 1 speakers.
