Quantum Data 881E Specification Sheet page 2

aPP Li C ati On tests
HDCP Testing
HDMI and DVI
Authentication and encryption of
uncompressed HDMI and DVI signals
HDCP Compliance Testing
For testing sink devices
For testing source devices
HDMI InfoFrames (882 only)
HDMI Verify InfoFrames sent to display
HDMI Pixel Repetition (882 only)
HDMI Test gaming formats with variable
horizontal resolution
HDMI Active Format Descriptor (AFD) (882 only)
HDMI
Verify HDMI content mapping
HDMI Audio Tests
Rate
Vary audio sampling rate to
test sink handling
Frequency Vary audio frequency to test
sink handling
Amplitude Vary audio amplitude to test
sink handling
EDID Read
HDMI, DVI, VGA Auto-configuration of generator
format list
Data channels
Physical I2C per VESA E-DDC
Protocols
DDC2B, E-DDC & DDC/CI
(reads E-EDID Ver 1.3)
EDID Testing
HDMI, DVI, VGA
Reads EDID from display and
presents as displayed image
EDID Compliance Testing (882 only)
HDMI HDMI EDID processing
DV Swing Test
HDMI, DVI Vary TMDS digital video signal
swing in 4mV increments from
150 to 1560 mVp-p (programmable)
Scrolling Image Test
All interfaces Scroll any static image
Special Sync Tool
Trigger scope or inspection camera
anywhere in video
Formats
Format file types XML
Standard formats Over 580 formats for testing IT, CE, military
and other display test applications
Custom formats Graphical format editor
Patterns
Pattern file types Custom object (.o) files, BMP, JPEG, PNG
Standard patterns Over 320 standard static and dynamic
images included for testing CRTs and FPDs
Custom patterns Graphics SDK to create complex patterns
Internal data storage 15 MB
Test Sequences
Create test sequences with unlimited
number of steps; each step defines a
video format, image, sync, gating and
duration (0.1 sec to 24 hours, or frames)
sPeCif iC at iOn
General Specifications
Size (mm)
330 W, 87 H, 284 D
Humidity 30 to 80% RH (non-condensing)
Operating temp. 0 to 40° C
AC Mains
Frequency
47 to 63 Hz
Voltage 90-264 VAC
HDMI (included with HDMI 1.3 option)
Connector One HDMI Type A
TMDS (single link)
225MHz clock; 2.25 Gb/s link rate
Video
TMDS protocols DVI 1.0 and HDMI 1.3
Encoding RGB or YCbCr (only RGB in DVI mode)
Sampling modes
4:4:4 or 4:2:2 (only 4:4:4 in DVI mode)
Color depth (HDMI) 24/30/36-bit 4:4:4 RGB / YCbCr
16/20/24-bit 4:2:2 YCbCr
Color depth (DVI) 24-bits per pixel RGB 4:4:4
Clocks per pixel
1 or 2
Pixel repetition 1 to 10 using interactive test image
TMDS differential swing 150-1560 mVp-p (programmable)
Quantization modes Full with optional gamma correction
ITU-R BT.709-5 Part 1, Sec 6.10
SMPTE 296M Sec 7.12
under/overshoot
Colorimetry Legacy HDTV SMPTE 260M-1999
Table 1, ITU-R BT.601-5 Sec 3.5.1
and ITU-R BT.709-5 Sec 4.2-1125
xvYCC 601 & xvYCC 709 for x.v.Color
Content fitting methods All AFD cases (Shoot & Protect, Overscan,Under-
scan, Letterbox/Pillarbox, Anamorphic Squeeze)
Aspect ratio
Content 4:3, 14:9, 16:9
Embedded 4:3, 16:9
Format (coded) 4:3, 16:9
Format timings All EIA/CEA-861-D formats
All E-EDID sink-requested < 165 MHz
Data (island) packet General control packet, audio samples,
generator types ACR data, InfoFrames, null frame
InfoFrame types AVI, SPD, AUD, MPG, GIF (generic)
Audio
Streams
4
Channels 8
Bits per sample 16, 20, 24
Sampling rates 32.0, 44.1, 48, 88.2, 92, 176.4, 192 kHz
Stream type
IEC 60958-3 Consumer LPCM
Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Other audio formats with exter,nal source
Audio content FL, FR, LFE, FC, RL, RR, RC, FLC, FRC, RLC
and RRC
Mixer mux Sinewave or external audio
Embedded sonic data generator
Channels 8
Waveform
Sinewave
Amplitude -96.3 to 0.0 dBFS
Frequency Change 20 Hz to 20 kHz
Controls Mute, amplitude, frequency
External audio interface
Type SPDIF input (coaxial)
Amplitude As received
Connector BNC with special SPDIF I/O
Cable
75 ohm coax cable
DVI
Connector HDMI output with HDMI-to-DVI cable
Encoding RGB (4:4:4 with 8-bits/component)
TMDS differential swing
150-1560 mVp-p (programmable)
Analog Composite (included with analog video option;
not available with 882E analyzer)
Connectors CVBS (BNC) and S-Video
Encoding
NTSC and PAL
Sample rate 24.55-29.50 MHz
Pixel rate 12.27-14.75 MHz
Pixel aspect ratio Standard or square
Swing
1000 mVp-p fixed with programmable
calibration
Calibration self-calibration with internal reference
881E/882E HDMI
Analog Component (included with analog video option;
not available with 882E analyzer)
Connector VGA
Color encoding RGB, YPbPr (unfiltered)
Video levels
Video swing
0-1000 mV
Sync swing 0-400 mV (bi-level), 0-800 (tri-level)
Video setup 0-100 IRE
Calibration Self-calibration with internal reference
Protection
Buffered with 75 ohm isolation
Internal data storage 15 MB
Digital Sync
Outputs
HS, VS and Special Sync
Swing > 2V fixed into 75 ohm
Pixel Clock
Frequency range
Analog component 5.16-250 MHz
HDMI 25-165 MHz (single-link)
DVI 25-165 MHz (single-link)
Step
Less than 0.1 Hz
Accuracy 50 ppm (electronically adjustable to
<5 ppm with external frequency
counter)
Horizontal Timing
Frequency range (kHz)
Analog composite 15.734 or 15.625
HDMI / DVI 8-1000
Total pixels (max) 65,535
Active pixels (max) 4096
Blank pixels (min)
HDMI 14 (minimum)
DVI 12 (minimum)
Step pixels
HDMI 1
DVI 1
Vertical Timing
Frequency range
1-650 Hz
Total lines (max) 4095 progressive, 8193 interlaced
and segmented
Active lines (max) 4096
Blank lines (min)
1 to Total-1
Step lines 1
Scan types Progressive, interfaced, segmented
Composite sync types ORed, Serrated, Serrated and
Equalized, Tri-level
Video Memory
Size 16,384,000 pixels at 32-bits/pixel
32,768,000 pixels at 8-bits/pixel
Maximum width 16,384 pixels at 32 bits/pixel
16,384 pixels at 8 bits/pixel
Color depth 36 bit up to 165 MHz
32 (24-bit TrueColor) up to 250 MHz
8 bits up to 250 MHz
Administration
Physical user interface (selection keys and display)
Control interfaces RS-232 serial AT
10/100 BaseT Ethernet (TCP/IP, FTP,
Telnet) GPIB
Browser-based virtual control panel to manage
from any network location
Create custom Microsoft Windows-based applications
using Quantum Data SDK (includes API documentation,
sample application & source)
PCMCIA slot Compact Flash card to boot generator,
backup generator configuration,
copy generator configuration to other
generators, and store patterns
