Selecting Images
Selecting Images
Press the Image button to select from list of
available test images (patterns).
You cannot modify the images, or add your own
images.
Gating Outputs
Press the Gating button to gate outputs, and to switch sync types.
Note: Color gating works for all images except Ramp.
