Carefully unpack box.
1
START HERE
What's what?
All the important components
labeled for you.
Terminal block
For wiring to gate operator
or door operner
Camera kit mounting location
Camera kit sold separately.
Copyright © Security Brands, Inc.
QU IC K STA RT
2
Unit shown with front panel fully open.
Internal wiring not shown for clarity.
G U I DE
Unlock and open front panel of unit
for access to internal components.
Antenna cable
Reset button and terminals
for performing hard reset
Speaker connector
Speaker can be disconnected temporarily
if unit is intermittently beeping. This is usually
due to a SIM card that is not yet activated.
SIM card
If you have your own SIM card, see page 4
and follow the instructions entitled
Installing Custom SIM Card.
I MP O R TA NT!
r
We recommend mounting Ascent X1 on a
standard gooseneck pedestal.
If using alternate mounting, the optional
Ascent 10' Cable Extension (p/n 16-X-EXT)
must be purchased. Follow the instructions
included with the extension before moving on.
Failure to do so may result in no signal!
Continued on next page...
I MP O R TA NT!
r
Ascent X1 WILL NOT WORK until the
activation process has been completed!
Follow the Activation Guide or call
Summit Control at (844) 259-8265 to
activate your unit.
W A R NI NG!
AUTOMATIC GATES CAN CAUSE
SERIOUS INJURY OR DEATH!
ALWAYS CHECK that the GATE PATH IS
CLEAR BEFORE OPERATING!
Reversing or other safety devices should
ALWAYS BE USED!
QSG-16X1-EN
1 of 4
Rev. D (12/2015)
