Newport - 2 Door Robe

Assembly Instructions -

Dimensions

Width - 70.5cm

Depth - 50cm

Height - 172cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

Please keep for future reference

244/1409

258/8403

MADE IN

BRITAIN

Issue 4 - 19/01/15

Need help?

Do you have a question about the 244/1409 and is the answer not in the manual?

Questions and answers

Summary of Contents for Newport 244/1409

Page 1 Newport - 2 Door Robe Assembly Instructions - 244/1409 Please keep for future reference 258/8403 Dimensions Width - 70.5cm Depth - 50cm MADE IN Height - 172cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 38.5kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below (DF287) (701 x 496mm) Left End Right End Base (DF285) (DF286B) (DF291) (1703 x 495mm)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the left side Screw 3 metal dowels into the left side Note: Tighten the metal dowels up fully against Finished the panels.
Page 6 Assembly Instructions Step 3 Prepare the base Insert 4 large locking nuts into the base Finished front edge Step 4 Fit the base to the right side Push the base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base...
Page 7 Assembly Instructions Step 6 Fit the plinth Push the plinth onto the right side Use a screwdriver to tighten the large locking fitted to the plinth Step 7 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 3 large locking nuts fitted to...
Page 8 Assembly Instructions Step 9 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the left side and right side Step 10 Fit the back and tap in the plastinails Square up the unit by making sure that The measurement from top corner X to bottom corner X must be...
Page 9 Assembly Instructions Step 11 Fit the hanging rail Push the hanging rail into the rail holders fitted to the side panels. Step 12 Prepare the 2 doors Push fit 3 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
Page 10 Assembly Instructions Step 13 Fit the doors and handles 2 people are needed here Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate Keep the hinge FLAT against the hinge...
Page 11 Assembly Instructions Step 14 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the top (or base) of the unit is level, front-to-back and side- to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any...
Page 12 Assembly Instructions Step 15 Fit the overbalance protector kit Screw To prevent possible Washer Wall fixing Strap overbalancing we (not supplied) Strap recommend that this unit Washer is secured to a suitable wall by fitting of the Screw overbalance protector kit (not supplied) to the unit, or an alternative fixing method...
