Service Manual

Colour Television 68 Cm / 66 Cm WIDE STEREO
CHASSIS : CP-810F / WP-811F
MODEL :
DTL-29U8ZLP / DTL-29U8ZLS
DTL-29U8ZZP / DTL-29U8ZZS
DWL-28W8ZLP / DWL-28W8ZLS
DWL-28W8ZZP / DWL-28W8ZZS
Specifications
THOMSON
28" FLAT : W66EJY011X121
CRT
SAMSUNG
28" FLAT : W66QDE993X ...
SYSTEM
PAL/SECAM-B/G,D/K,PAL-I/I',SECAM-L/L'
230V AC, 50Hz
Main Voltage
Stand-by mode : 2.0Watts
Power Consumption
Normal operating mode : 120 Watts
Sound Output
10 + 10 Watts, 10% THD at RF 60% mod. (1kHz)
12W 8ohm x 2 EA
Speaker
Antenna Impdeance
75 ohm unbalanced input (Din Standard)
Tuning System
Frequency Synthesize(FS) Tuning System
UV1316/A(Philips), DT5-BF18D(Partsnics), EL2782-105-B(Siel)
Tuner
Number of Program
100 programs
21 pin EURO-SCART jack (AV input, TV output, RGB input)
21 pin EURO-SCART jack (AV input, S-VHS input)
RCA type AV input jack
Aux. Terminal
S-VHS jack
Headphone jack
R-22D06 with 2 "AAA" type batteries
Remote Controller
TOP(5 Page memory) & FLOF(7 Page memory)
- West option : English, German/Dutch/Flemish, French, Italian, Spanish/Portuguese,
Teletext
- West : English, German, French, Italian, Spanish, Nethelands, Swedish
OSD Language
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD
http://svc.dwe.co.kr
S/M No: CP810WP811
WP-811F
NTSC-3.58/4.43 (Play back)
Swedish/Finnish/Danish, Hungarian, Rumanian, Turkish
CP-810F
29" FLAT : A68EJZ011X121
29" FLAT : A68QCP893X ...
Apr. 2002
