OUTDOOR SPEED BOME CAMERA
MINI HIGH SPEED DOME CAMERA
User's Manual
Before attempting to connect or operate this product, please
read these instructions completely
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC-D2410-AW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tiandy TC-D2410-AW

Summary of Contents for Tiandy TC-D2410-AW

  • Page 1 OUTDOOR SPEED BOME CAMERA MINI HIGH SPEED DOME CAMERA User’s Manual Before attempting to connect or operate this product, please read these instructions completely...

  • Page 2: Table Of Contents

    Contents Important Safety Instructions………………………………………3 … ……………………………………………………………………… Caution … ………………………………………………………………… Introduction …7 … Drawing………………………………………………………… Connection……………………………………………………………8 Installation ……………………….……………………………………9 ID code setting……………………………………………………... 10 Protocol setting………………………………...…………………… 11 …………………………………………………………….12 Setting Baud Rate Setting Protocol of zoom camera …..…………………………….. 12 Operation…………………………………………………….…….. . 13 Camera OSD menu…..………………………………………………16 Operation of zoom camera…………………………………….……17 The OSD menu setting………………………...………………..…20 B01 Protocol………………………………………………………..…..32...

  • Page 3: Important Safety Instructions

    Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 4 required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or been dropped.

  • Page 5: Caution

    CAUTION To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to rain or moisture. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and 2) This device must accept any interference that may cause undesired operation.
  • Page 6 Horizontal 360°unlimited continuous rotation and rotation rate can be adjusted from 0.1 ~240°per second continuously（Manual speed）. Vertical rotation range 0~90°and rotation rate achieve0.1~90°/s. 3：Intelligent power-off memory operation Design ideally ,Auto-flip to follow object。 Provides 128 preset points. Provide setting of scanning track and select scanning track function.

  • Page 7: Drawing

    DRAWING...

  • Page 8: Connection

    CONNECTIONS Precautions • The following connections should be made by qualified service personnel or system installers in accordance with all local codes. 1、 Before installing please read the instructions, of the unknown, please contact seller. 2、 Connections (Figure) Green RS485+ RS485 data Yellow RS485- Yellow &...

  • Page 9: Installation

    Installation On shield of protection, is trying to gain and installation to avoid scratches spherical transparent and clean. Choose the appropriate installation method. Speed dome camera must be installed at the scaffold on a stable and reliable, the installation should be in accordance with the requirements of surveillance scenes to make the largest screen monitor, and monitor the clearest images.

  • Page 10: Id Code Setting

    ID CODE SETTING The ID code setting set by 8 digital-switch, address of speed dome camera is from 1~255, about the Stir code of addresses 1~128, pls see the Appendix Ⅰ. There are the parts of Stir code of addresses .Setting as below picture (Other, please turn on and so forth in accordance with the binary)：...

  • Page 11: Protocol Setting

    If the Control Wire parallel connection many speed dome camera NOTE: the forest dome camera ,you should connect JM1 which is in RS485 interface of main control board .If the distance is very far ,you also should do as above operation .Detail connect ,according to white line on the main control board.

  • Page 12: Setting Baud Rate

    Setting Baud Rate of Dome Camera Set baud rate of this speed dome camera by the six key switches section 4 and 5 to select. Set as following: SETTING PROTOCOL OF ZOOM CAMERA Set zoom camera’s protocol of this speed dome camera by six of the last switch.

  • Page 13: Operation

    PELCO-D/2400) OPERATION Default protocol The speed dome camera can be controlled remotely horizontal and vertical movement. It is used with a system controller, separately. It is controlled remotely from the controller through a serial connection to the RS-485 connector using a twisted-pair cable.
  • Page 14 The preset memory function will memories camera positions and zoom, focus, etc. Setting up to 128 preset camera positions can be memorized. Later, you can easily recall any of the preset camera positions by entering its corresponding number, and the camera will move the memorized position with all the preset settings. 3.1 To set a preset position SET + N + ENTER N: the number of preset position: 1~128...
  • Page 15 Adjust the position of dome camera which you need. Setting finish scanning track point： [SET] + [52] + ENTER] Adjust the position of dome camera which you need. 3． Calling scanning： [PRESET]+51+ [ENTER] Note: Setting begins and finishes scanning track point first. 4．...

  • Page 16: Camera Osd Menu

    Camera OSD menu Show Menu on display and setting other parameter of zoom camera. Operation as follow: Call No.57 preset position { [PRESET]+57+[ENTER]} to show the main menu on display, and use [TELE]、[WIDE] to choose item, then press [FAR]、[NEAR] to set and confirm .If you want to set other items, you should come back main menu first.

  • Page 17: Operation Of Zoom Camera

    Operation of camera The definition of key Control object PRESET+N+ENTER SET+N+ENTER Power supply Come back Initial value Backlight compensation Min. illumination Menu/ Screen Display Digital Zoom Focus AUTO MANUAL IRIS AUTO MANUAL White Balance AUTO MANUAL Image congeal Static image Normal image Mirror image Image mirror...
  • Page 18 Index Diagram of the Screen Menu...
  • Page 19 Index Diagram of the Screen Menu This is the camera’s OSD function, which include the menu while opening and the menu while operating. Open it, and see the start of image, the order of showing is: Waiting for image Waiting… The image of system information : 1.02 Version...

  • Page 20: The Osd Menu Setting

    The Menu Setting ● The major menu setting {[PRESET] +8+ [ENTER]} After checking itself, please , then it will show the image as the No.1-0-1: →（Pic.1-1-1） System Info System Setup →（Pic.1-2-1） Camera Control →（Pic.1-3-1） Preset Control →（Pic.1-4-1） Special Function Factory Default →（Pic.1-5-1）...
  • Page 21 control，then turn right to enter to the function menu of camera. Back Light: OFF Digital Zoom: OFF Focus Mode : AUTO IRIS Adjust : AUTO White Balance: AUTO Image Freeze : OFF Next EXIT Pic.1-2-1 Remark ：The menu of this page is to set the function of integration camera.
  • Page 22 2） Set the rest item as step 1； 3） All finished , turn up or down the rocker to point to exit, then turn right the rocker and exit if it point to next ， turn right and enter to next image, it will show as Pic.1-2-2: Image Reverse : OFF...
  • Page 23 preset position（Pic.1-3-1）: NO. : Setting Call Delete EXIT Pic.1-3-1 Explain ：Above menu is used to set, call and delete preset positions. （Pic.1-3-1） ： ◆ NO.: Display the No. of preset position. （No.:1-128） ； ◆ Setting: Setting preset position ◆ Call: Call preset position（Pic.1-3-2） ◆...
  • Page 24 Setting Call Delete EXIT PRESS CLOSE TO SAVE PRESS OPEN TO ESC Pic.1-3-2 3）Select the No. of preset position before Call preset position，move rocker down or up to let cursor points “call”, then move rocker on right to confirm, the camera will adjust to the preset position（Note: If the No. Of preset position haven’t been set.
  • Page 25 Pic.1-4-1 Note： Brush （Function of rain strip） ： If system have this function, Default display “OFF”；If not have it, default display “NONE” and will not be change. Auto Back : Return automatically（Pic.1-4-1-4） ：Study function（Pic.1-4-1-5） Auto Learn ：Pic.1-4-1-8 Cover offset Explain： The menu of Pic.1-4-1 is setting function.
  • Page 26 Step of operation： （1）Move rocker to “Set”， Move rocker on right ,the system will show as the pic.1-4-1-2,then set the begin point and the end point of track. AUTORUN CONTROL MENU ： BEGIN ： Run ： SCAN Seqno： Run ： EXIT Press close to save Press open to esc...
  • Page 27 （4）The second Run (SEQ)：call track ●.Privacy Zone Select in menu of Pic.1-4-1，Move rocker down or up to select “Privacy Zone”， then move rocker on right to come into the menu of privacy zone (Pic.1-4-11). No. of privacy zone, （Select NO.: 1-12）. NO : Enter setting menu.→（1-4-12）...
  • Page 28 Pic.1-4-12 Pic.1-4-13 Note： After setting privacy zone ,must save it. If not the dome camera will be not memory. ◆ . Return automatically Auto Back”， Move rocker down or up to “ move rocker on right to come into menu, as pic.1-4-1-4 AUTO BACK MENU ：...
  • Page 29 ： Explain AUTO BACK MODE： Default OFF ，select ON ： 0-9MIN TIME SET AUTO BACK BEGIN ：Set begin point AUTO BACK SET ： SEQ1、SEQ2、SEQ3、SEQ4、SCAN、 PRE1 Note: SEQ is track；SCAN is scanning；PRE is preset point. When “AUTOBACK MODE” set “ON”, during this time, if the speed dome camera doesn’t do any actions, it will return to set mode.
  • Page 30 AUTO LEARN MENU TIME : 00SEC AUTO LEARN NO: 1 LEARN BEGIN LEARN EXIT PRESS CLOSE TO RUN PRESS OPEN TO CANCEL Pic.1-4-1-6 Explain：Press “CLOSE” ,screen will show “WAITTING” . “WAITTING” disappear after a few seconds, the interface automatically self-learning. Time is Max. 60s. Then the system will show “LEARN FINISHED”；press “OPEN”...
  • Page 31 second. ◆ Focus on correcting the functional coverage Move rocker down or up to “Cover offset”， move rocker on right come into as pic.1-4-1-8 Cover offset OFFSET MODE : OFF OFFSET LEVEL : 01 LV Pic.1-4-1-8 Explain： OFFSET MODE ：Focus on correcting the functional coverage model. Default OFF ，select ON OFFSET LEVEL ：Focus-level settings.

  • Page 32: B01 Protocol

    PROTOCOL CODE FUNCTION 1. B01 PROTOCOL ： Ⅰ .To set up cruise tracks [SHOT] + N + [ON] The LCD displays Input Tour No. N N: The number of track ON The LCD displays Track = N1 Sum = N2 : track number : sum of preset positions Press TELE, the LCD displays No.N3 point...
  • Page 33 Ⅲ . Accessional Function [F1] + N + [ON] / [OFF] Display：Input No. Explain Function [F1]+N+[ON] [F1]+N+[OFF] Camera power Min. illumination Menu/Display Digital zoom Reposition Enantiomorphous FOCUS Auto Manual IRIS Auto Manual White Balance Auto Manual Image Enantiomorphous Normal STATIC STATE Congeal Normal COLOR/BW...

  • Page 34: Debugging

    Debugging Before the installing must be pre-set communication protocol, baud rate, zoom camera’s protocol and ID code. A system of speed dome camera, keyboard, and matrix must be used, such as unified communications and unified communications protocol baud rate, and ensure that each speed dome camera has a unique same address.

  • Page 35: General Failure Analysis Table

    General Failure Analysis （1） . At this time should check After power on, no motion and no image whether the normal power supply, if it is 24V AC power supply, power supply with the carrying capacity is adequate, and have to view the amount of current, voltage should not just look at;...
  • Page 36 of twisted pair; (b) Wire diameter is too small resulting in weak signals. RS-485 as far as the transmission distance 1200 meters, can detect a valid signal to the minimum range 200mV, below the rate of invalid signal; (c) Wiring topology structure is irrational. RS-485 communication norms require wiring type topology, and a lot of engineering to use the star topology;...
  • Page 37 zoom down the most, up and down around the mandatory speed limit in order to guarantee the state at low speed to see enlarged details of each object. （9） Camera iris, focus, zoom, etc. should not work. Should check the camera protocol on the speed dome camera. （10）...

  • Page 38: Routine Maintenance

    Routine maintenance Speed dome camera are compact equipment, often on their maintenance is also necessary to avoid the question of further expansion. （1） Often clean the cover. At present the speed dome camera do not have self-cleaning ability so it is necessary to periodically and manually clean the cover.

  • Page 39: Specification

    SPECIFICATION Panning range 360°endless Pan speed 0.1~240°/sec 90°（180°Reversal auto-flip ） Tilt range Tilt speed 0.1~90°/sec Communication RS485 Preset position Track 4 cruising tracks and 2scanning track Baud Rate 1200/2400/4800/9600/19200bps AC24V/DC12V Power 45W/ 15W Operating 0℃~40℃ temperature ≥48dB S/N Ratio Video output 1.0Vp-p/75Ω...

  • Page 40: Appendixⅰ

    AppendixⅠ 开关位 球机地址...
  • Page 43 … … Explain：DIP1 means 1, DIP2 means 2, DIP3 means 4, DIP5 means 16, DIP6 means 32, DIP7 means 64, DIP8 means 128; For example: Address 241=128+64+32+16+1， So set the DIP1,DIP5 DIP6, DIP7,DIP8 for “ON”, other switches for “OFF”...
