Protech Systems BU-2509 User Manual

Micro atx motherboard with intel 6th gen. coretm i7/i5/i3 and xeon e3 v5 processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
MANUAL
BU-2509
BU-2509
Micro ATX Motherboard
With Intel ® 6
i7/i5/i3 and Xeon E3 V5
Processor
M1
Gen. Core
TM
th

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BU-2509 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Protech Systems BU-2509

Summary of Contents for Protech Systems BU-2509

  • Page 1 USER’S MANUAL BU-2509 Micro ATX Motherboard With Intel ® 6 Gen. Core i7/i5/i3 and Xeon E3 V5 Processor BU-2509...
  • Page 2 BU-2509 With Intel ® 6 Generation Core Micro ATX Motherboard COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in December 2016. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual…............System Specification…............1-3 Safety Precautions…............. CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table…....Component Locations….…........... How to Set Jumpers…............COM Port and Connectors (COM1-COM6)……………… Clear CMOS Data Selection (JCMOS1)…………………… 2-10 COM3 and COM4 Port RI / Voltage Selection (JPCOM3, 2-11...
  • Page 5 Contents 2-24 Serial ATA (SATA) Connectors (SATA1, SATA2, 2-34 SATA3, SATA4, SATA5, SATA6, SATA7, SATA8)……. 2-25 Internal USB 3.0 Connector (USB1)………………………. 2-35 2-26 Internal USB 2.0 Connectors (USB2, USB3)……………… 2-35 2-27 Display Port Connector (DP1)…………………..………… 2-36 2-28 Power Input Connectors (ATX_PWR1, ATX_PWR2) …… 2-37 2-29 Speaker Connector (JSPEAKER)…………………..………...

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for BU-2509. It also outlines the system specifications. The following sections are included:  About This Manual  System Specifications  Safety Precautions Experienced users can jump to chapter 2 on page 2-1 for a quick start.

  • Page 7: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL ® Thank you for purchasing our BU-2509 Micro ATX Motherboard with Intel ® Generation Core i7/i5/i3 Pentium processor. The BU-2509 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 8: System Specification

    - E3-1225 v5, supports ECC - E3-1268L v5, supports ECC - i3-6100TE, supports ECC - i7-6700(TE), non-ECC - i5-6500(TE), non-ECC - i3-6100, non-ECC - Pentium G4400(TE), non-ECC - Celeron G3900(TE), non-ECC BIOS AMI BIOS Watchdog 1~255 seconds  Page: 1-3 BU-2509 USER S MANUAL...
  • Page 9 / line-in / MIC-in (Rear I/O) 8in/8out (internal connector) API supporting Keyboard/Mouse 2 x PS/2 (Rear I/O) Expansion Bus BU-2509RA-00P/D0P: 1 x PCIe (x16), 2 x PCIe (x4),  1 x PCIe (x1), 1 x mini-PCIe (PCIe, USB)  Page: 1-4 BU-2509 USER S MANUAL...
  • Page 10 Optional function via an additional LPC Daughter Board 1 x CPU FAN (4 pins), 1 x System FAN (4 pins), 1 x System FAN (3 pins) I/O and others Fintek 81866AD-I  Fintek 81216   Page: 1-5 BU-2509 USER S MANUAL...
  • Page 11 15G peak-to-peak, 11ms duration, non-operation Vibration Non-operation: 2G, 5-200Hz, X,Y,Z axis Environment Operating Temp. 0°C ~ 60°C (32°F ~ 140°F) Storage Temp. -40°C ~ 85°C (-40°F ~ 185°F) Humidity Operating: 5% - 95% (non-condensing)  Page: 1-6 BU-2509 USER S MANUAL...

  • Page 12: Safety Precautions

    Disconnect power source when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system.  Page: 1-7 BU-2509 USER S MANUAL...

  • Page 13: Chapter 2 Hardware Configuration

    CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. The following sections are included:  Jumper & Connector Quick Reference Table  Component Locations  Configuration and Jumper Settings  Connector Pin Assignments Page 2-1...

  • Page 14: Jumper & Connector Quick Reference Table

    USB2, USB3 VGA Port RS-232/422/485 (COM2) Selection COM2 Auto Detection Selection Hardware Power Failure Selection Flash Descriptor Override Selection LAN2 Enable / Disable Selection Mini PCI Express Voltage Selection JP13 VCCIO Voltage Selection JP10  Page: 2-2 BU-2509 USER S MANUAL...

  • Page 15: Component Locations

    COM5 COM4 JPCOM3 JPCOM4 BU-2509 Connector, Jumper and Component Locations (Front Side) Note: C236 SKU has SATA1~8, JDIMM1~4, PCI_E1~4 available. Q170 SKU only has SATA1~6, JDIMM1~4, PCI_E1~4 available. H110 SKU only has SATA1~4, JDIMM2/4, PCI_E1~3 available. USB1 is not available for H110 SKU.
  • Page 16 Chapter 2 Hardware Configuration BU-2509 Connector, Jumper and Component Locations (Rear Side)  Page: 2-4 BU-2509 USER S MANUAL...
  • Page 17 Chapter 2 Hardware Configuration BU-2509 I/O View LINE-IN/ LINE-OUT LAN1 LAN2 PS/2 Mouse COM Port VGA Port DVI-D Port 2 x USB 3.0 2 x USB 3.0 PS/2 Keyboard COM Port MIC-IN  Page: 2-5 BU-2509 USER S MANUAL...

  • Page 18: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent.  Page: 2-6 BU-2509 USER S MANUAL...
  • Page 19 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this  Page: 2-7 BU-2509 USER S MANUAL...

  • Page 20: Com Port And Connectors (Com1-Com6)

    COM1: COM1 Connector, fixed as RS-232. ASSIGNMENT DCD# DTR# DSR# RTS# CTS# COM2/ COM1 COM2: COM2 Connector selectable as RS-232/422/485. The pin assignments are as follows: Signal RS-232 RS-422 RS-485 DCD# RS-485- RS-485+ DTR# DSR# RTS# CTS#  Page: 2-8 BU-2509 USER S MANUAL...
  • Page 21 COM3, COM4, COM5, COM6: COM Connector, fixed as RS-232. ASSIGNMENT ASSIGNMENT DCD# DSR# RTS# CTS# COM3/ DTR# COM4/ Note: Pin 9 is selectable for RI, +5V or +12V for COM5/ COM3 and COM4 only. COM6  Page: 2-9 BU-2509 USER S MANUAL...

  • Page 22: Clear Cmos Data Selection (Jcmos1)

    Note 2: To clear CMOS data, users must power off the computer and set the jumper to “Clear CMOS” as shown above. After five to six seconds, set the jumper back to “NC” and power on the computer.  Page: 2-10 BU-2509 USER S MANUAL...

  • Page 23: Com3 And Com4 Port Ri / Voltage Selection

    Chapter 2 Hardware Configuration 2-6. COM PORT RI / VOLTAGE SELECTION COM3 and COM4 RI & Voltage Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING JPCOM3/JPCOM4 JPCOM3/JPCOM4 JPCOM3/JPCOM4 Note: Manufacturing default is RI.  Page: 2-11 BU-2509 USER S MANUAL...
  • Page 24 2-7. DIGITAL I/O PORT CONNECTOR JDIO1: Digital Input / Output Port Connector ASSIGNMENT ASSIGNMENT VCC5 VCC12 DIN1 DOUT1 JDIO1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5- DIN6 DOUT6 DIN7 DOUT7 DIN8 DOUT8  Page: 2-12 BU-2509 USER S MANUAL...
  • Page 25 Chapter 2 Hardware Configuration 2-8. KEYBOARD & MOUSE PORT KB_MS1: PS/2 Keyboard & Mouse Port Mouse: ASSIGNMENT ASSIGNMENT MSCLK VCC5 MSDATA Keyboard: ASSIGNMENT ASSIGNMENT KBCLK KB_MS1 VCC5 KBDATA  Page: 2-13 BU-2509 USER S MANUAL...
  • Page 26 A DVI-D connector transfer only digital signals, providing faster transfer rates and better quality than their predecessor, the VGA cable. It is most commonly used to connect computer video cards to LCD monitors.  Page: 2-14 BU-2509 USER S MANUAL...

  • Page 27: Vga Port (Vga)

    Chapter 2 Hardware Configuration 2-10. VGA PORT VGA: VGA (Video Graphics Array) Connector The pin assignments are as follows: ASSIGNMENT CRT_RED CRT_GREEN CRT_BLUE CRT_VCC CRT_SDA CRT_HSYNC CRT_VSYNC CRT_SCL  Page: 2-15 BU-2509 USER S MANUAL...

  • Page 28: Front Panel Connector (Fp1)

    Chapter 2 Hardware Configuration 2-11. FRONT PANEL CONNECTOR FP1: Front Panel Connector ASSIGNMENT ASSIGNMENT HDD_LED+ PWR_LED+ HDD_LED- PWR_LED- PWR_BTN RST_BTN VCC5  Page: 2-16 BU-2509 USER S MANUAL...
  • Page 29 No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.0 signals: ASSIGNMENT ASSIGNMENT USB_N1 USB_N2 USB_P1 USB_P2 USB3_RX_N1 USB3_RX_N2 USB3_RX_P1 USB3_RX_P2 USB3_TX_N1 USB3_TX_N2 USB3_TX_P1 USB3_TX_P2  Page: 2-17 BU-2509 USER S MANUAL...
  • Page 30 No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.0 signals: ASSIGNMENT ASSIGNMENT USB_N3 USB_N4 USB_P3 USB_P4 USB3_RX_N3 USB3_RX_N4 USB3_RX_P3 USB3_RX_P4 USB3_TX_N3 USB3_TX_N4 USB3_TX_P3 USB3_TX_P4  Page: 2-18 BU-2509 USER S MANUAL...

  • Page 31: Line-In, Line-Out, Mic-In Port (Audio1)

    Chapter 2 Hardware Configuration 2-13. LINE-IN, LINE-OUT, MIC-IN PORT AUDIO1: Line-In, Line-Out & Microphone The connector can also support only Microphone. Line-In: ASSIGNMENT HD_LINE-IN-L HD_LINE-IN-R Line-Out: ASSIGNMENT LINE-OUT-L AUDIO1 LINE-OUT-R MIC-In: ASSIGNMENT HD_MIC1-L_L HD_MIC1-R_L  Page: 2-19 BU-2509 USER S MANUAL...

  • Page 32: Rs-232/422/485 (Com2) Selection (Jp2)

    2-14. RS-232/422/485 (COM2) SELECTION JP2: RS-232/422/485 (COM2) Selection The selections are as follows: Jumper Setting Selection Jumper Illustration (Pin Closed) RS-232 Open RS-422 1-2, 3-4, 9-10 RS-485 1-2, 5-6, 7-8 ***Manufacturing Default – RS-232.  Page: 2-20 BU-2509 USER S MANUAL...

  • Page 33: Com2 Auto Detection Selection (Jp4)

    Chapter 2 Hardware Configuration 2-15. COM2 Auto Detection Selection JP4: COM2 Auto Detection Selection The selections are as follows: Jumper Setting Selection Jumper Illustration (Pin Closed) Normal Auto ***Manufacturing Default – Auto.  Page: 2-21 BU-2509 USER S MANUAL...

  • Page 34: Hardware Power Failure Selection (Jp1)

    Chapter 2 Hardware Configuration 2-16. HARDWARE POWER FAILURE SELECTION JP1: Hardware Power Failure Selection JUMPTER SELECTION JUMPER ILLUSTRATION SETTING Enable Disable Note: Manufacturing default is Disable.  Page: 2-22 BU-2509 USER S MANUAL...

  • Page 35: Flash Descriptor Override Selection (Jp3)

    Chapter 2 Hardware Configuration 2-17. FLASH DESCRIPTOR OVERRIDE SELECTION JP3: Flash Descriptor Override Selection The selections are as follows: Jumper Setting Selection Jumper Illustration (Pin Closed) Disable Open Enable ***Manufacturing Default – Disable.  Page: 2-23 BU-2509 USER S MANUAL...

  • Page 36: Lan2 Enable/Disable Selection (Jp5)

    Chapter 2 Hardware Configuration 2-18. LAN2 ENABLE / DISABLE Selection JP5: LAN2 Enable / Disable Selection The selections are as follows: Jumper Setting Selection Jumper Illustration (Pin Closed) Enable Disable ***Manufacturing Default – Enable.  Page: 2-24 BU-2509 USER S MANUAL...

  • Page 37: Mini Pcie Voltage Selection (Jp13)

    Chapter 2 Hardware Configuration 2-19. Mini PCIE VOLTAGE SELECTION JP13: Mini PCIE Voltage Selection The selections are as follows: Jumper Setting Selection Jumper Illustration (Pin Closed) 3.3V JP13 3.3V_AUX JP13 ***Manufacturing Default –3.3V_AUX.  Page: 2-25 BU-2509 USER S MANUAL...

  • Page 38: Vccio Voltage Selection (Jp10)

    Chapter 2 Hardware Configuration 2-20. VCCIO VOLTAGE SELECTION JP10: VCCIO Voltage Selection The selections are as follows: Jumper Setting Selection Jumper Illustration (Pin Closed) 1.0V JP10 0.95V JP10 ***Manufacturing Default – 0.95V.  Page: 2-26 BU-2509 USER S MANUAL...

  • Page 39: Mini Pci Express Slot (Mpcie1)

    2-21. MINI PCI EXPRESS SLOT MPCIE1: Mini-PCI Express Slot ASSIGNMENT ASSIGNMENT WAKE_N 3.3V_SB 1.5V CLKREQ# REFCLK- REFCLK+ MPCIE1 PERST# PE_RX_N 3.3V_SB PE_RX_P 1.5V SMB_CLK PE_TX_N SMB_DATA PE_TX_P USB_N USB_P 3.3V_SB 3.3V_SB 1.5V 3.3V_SB  Page: 2-27 BU-2509 USER S MANUAL...

  • Page 40: Pci Express Slots

    HSIN1 + 12V HSIP6 HSIN6 HSIP2 HSIN2 HSIP7 HSIN7 + 3.3V HSIP3 + 3.3V HSIN3 RSVD PERST# RSVD HSIP8 REFCLK+ RSVD HSIN8 REFCLK- HSIP4 HSIP0 HSIN4 HSIP9 HSIN0 HSIN9 RSVD HSIP5 HSIN5 HSIP10  Page: 2-28 BU-2509 USER S MANUAL...
  • Page 41 HSON7 SMB_CLK SMB_DATA HSOP3 PRSNT#2 HSON3 + 3.3V HSOP8 RSVD HSON8 + 3.3V_AXU PRSNT#2 WAKE# RSVD HSOP4 HSOP9 HSON4 HSON9 HSOP0 HSON0 HSOP5 HSOP10 PRSNT#2 HSON5 HSON10 HSOP1 HSON1 HSOP6 HSOP11 HSON6 HSON11  Page: 2-29 BU-2509 USER S MANUAL...
  • Page 42 Note1: H110 SKU PCI_E2 only supports PCIE X 1. PCI_E2/PCI_E4 ASSIGNMENT ASSIGNMENT ASSIGNMENT PRSNT#1 + 12V REFCLK+ + 12V REFCLK- HSIP2 HSIN2 HSIP0 HSIN0 HSIP3 RSVD HSIN3 + 3.3V + 3.3V HSIP1 RSVD PERST# HSIN1  Page: 2-30 BU-2509 USER S MANUAL...
  • Page 43 Chapter 2 Hardware Configuration ASSIGNMENT ASSIGNMENT ASSIGNMENT + 12V RSVD HSOP2 + 12V HSON2 + 12V HSOP0 HSON0 SMB_CLK HSOP3 SMB_DATA PRSNT#2 HSON3 + 3.3V HSOP1 RSVD HSON1 PRSNT#2 + 3.3V_AXU WAKE#  Page: 2-31 BU-2509 USER S MANUAL...

  • Page 44: Pci_E3 (X1))

    PRSNT#1 + 3.3V + 12V PERST# + 12V REFCLK+ REFCLK- HSIP0 HSIN0 + 3.3V ASSIGNMENT ASSIGNMENT + 12V + 3.3V_AXU + 12V WAKE# + 12V RSVD SMB_CLK HSOP0 SMB_DATA HSON0 + 3.3V PRSNT#2  Page: 2-32 BU-2509 USER S MANUAL...

  • Page 45: Cpu / System Fan Connectors

    Chapter 2 Hardware Configuration 2-23. CPU / SYSTEM FAN CONNECTORS CPU_FAN1: CPU Fan Connector SYS_FAN1: System Fan Connector 1 ASSIGNMENT CPU_FAN1 VCC12 CPU_FANTAC CPU_FANCTRL SYS_FAN1 SYS_FAN2: System Fan Connector 2 ASSIGNMENT VCC12 SYS_FAN2  Page: 2-33 BU-2509 USER S MANUAL...

  • Page 46: Serial Ata (Sata) Connectors (Sata1, Sata2,

    SATA6, SATA7, SATA8: SATA Connectors SATA1-8 Pin Assignment: SATA1/ SATA3/ ASSIGNMENT SATA5/ SATA_TX_P SATA7/ SATA_TX_N SATA_RX_N SATA_RX_P SATA2/ SATA4/ Notes: C236 SKU supports SATA1~SATA8. SATA6/ Q170 SKU supports SATA1~SATA6. SATA8/ H110 SKU supports SATA1~SATA4.  Page: 2-34 BU-2509 USER S MANUAL...

  • Page 47: Internal Usb 3.0 Connector (Usb1)

    Note: USB1 is only available for C236/Q170 SKU, not available for H110 SKU. 2-26. INTERNAL USB 2.0 CONNECTORS USB2, USB3: Internal USB 2.0 Connector ASSIGNMENT ASSIGNMENT USB2_P USB2_P USB2_N USB2_N USB2/ VCC5 VCC5 USB3  Page: 2-35 BU-2509 USER S MANUAL...

  • Page 48: Display Port Connector (Dp1)

    Chapter 2 Hardware Configuration 2-27. DISPLAY PORT CONNECTOR DP1: Display Port Connector ASSIGNMENT ASSIGNMENT VCC5 VCC3 VCC3 AUX+ AUX_EN# DATA3- DATA2- DATA3+ DATA2+ DATA1- DATA0- DATA1+ DATA0+ NOTE: BU-2509RA-D0P / D1P / D6P don’t support DP.  Page: 2-36 BU-2509 USER S MANUAL...
  • Page 49 + 3.3V -12V + 3.3V ATX_PWR1 PSON + 5V + 5V + 5V + 5V_SB + 5V + 12V + 5V + 12V + 3.3V ATX_PWR2: Power Connector ASSIGNMENT ASSIGNMENT +12V +12V ATX_PWR2  Page: 2-37 BU-2509 USER S MANUAL...

  • Page 50: Speaker Connector (Jspeaker)

    JSPEAKER: Speaker Connector ASSIGNMENT SPKR_SIGNAL SPKR_SIGNAL SPKR_SIGNAL JSPEAKER SPKR_VCC 2-30. LPC CONNECTOR JLPC1: LPC Connector ASSIGNMENT ASSIGNMENT DREQ0 SUS_TAT CLK RUN SERIRQ 3VSB SMBDATA SMBCLK LAD0 JLPC1 LAD1 VCC3 LAD2 LAD3 VCC5 RESET FRAME  Page: 2-38 BU-2509 USER S MANUAL...

  • Page 51: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Sound driver. The following sections are included:  Introduction.  ® Intel Chipset Software Installation Utility ®  Intel Trusted Execution Engine Installation Utility  VGA Driver Utility ...
  • Page 52 Chapter 3 Software Utilities 3-1. INTRODUCTION Enclosed with our BU-2509 package are our driver utilities, which come in a DVD- ROM disk. Refer to the following table for driver locations. Filename (Assume that DVD ROM Purpose drive is D :) DOS Win7 Win8.1 Win10...
  • Page 53 Chip Software installer D:\Q170\Driver\Plaform\Win7(64- ®    Intel HD Graphics installer bit)\VGA ® D:\Q170\Driver\Plaform\Win7(64- Intel Network Connections    bit)\LAN Software D:\Q170\Driver\Plaform\Win7(64- Realtek High Definition    bit)\Sound Audio System Software  Page:3-3 BU-2509 USER S MANUAL...
  • Page 54 Intel USB 3.0 eXtensible    bit)\USB3.0 Host Controller ® D:\Q170\Driver\Plaform\Win10(64- Intel Management Engine    bit)\ME Components installer ® D:\Q170\Driver\Plaform\Win10(64- Intel Rapid Storage    ® bit)\RAID Technology (Intel RST).  Page:3-4 BU-2509 USER S MANUAL...
  • Page 55 OS installation. Please follow the steps below: Insert the driver disk into a DVD-ROM device. Under Windows system, go to the directory where the Utility driver is located. Run the application with administrative privileges.  Page:3-5 BU-2509 USER S MANUAL...

  • Page 56: Intel Trusted Execution Engine Installation Utility

    Device Manager. 3-3-2. Installation Instructions for Windows 7/8.1/10 Insert the driver disk into a DVD-ROM device. Under Windows system, go to the directory where the driver is located. Run the application with administrative privileges.  Page:3-6 BU-2509 USER S MANUAL...

  • Page 57: Vga Driver Utility

    Chapter 3 Software Utilities 3-4. VGA DRIVER UTILITY 3-4-1. Introduction The VGA interface embedded with our BU-2509 can support a wide range of display. 3-4-2. Installation of VGA Driver To install the VGA Driver, simply follow the following steps: Insert the driver disk into a DVD-ROM device.

  • Page 58: Lan Driver Utility

    Chapter 3 Software Utilities 3-5. LAN DRIVER UTILITY 3-5-1. Introduction BU-2509 is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: For more details on Installation procedure, please refer to Readme.txt file found on LAN Driver Utility.

  • Page 59: Sound Driver Utility

    Run the application with administrative privileges. Follow the instructions on the screen to complete the installation. Once the installation is completed, shut down the system and restart it in order for the changes to take effect.  Page:3-9 BU-2509 USER S MANUAL...

  • Page 60: Chapter 4 Bios Setup

    CHAPTER BIOS SETUP This chapter describes how to set up the AMI BIOS. The following sections are included:  Introduction  Entering Setup  Main  Advanced  Chipset Boot   Security  Save & Exit Page: 4-1...

  • Page 61: Introduction

    Chapter 4 AMI BIOS Setup 4-1. INTRODUCTION The system BU-2509 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-On Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 62: Entering Setup Utility

    <Del> or <Esc> immediately while the POST message is running before the operating system is loading. 4-2. ENTERING SETUP UTILITY After the system is powered on, BIOS will enter the Power-On Self-Test (POST) routines and the POST message will be displayed: POST Screen  Page: 4-3 BU-2509 SERIES USER S MANUAL...
  • Page 63 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen.  Page: 4-4 BU-2509 SERIES USER S MANUAL...

  • Page 64: Main

    Month, day, year Sets the system date. The format is [Day Month/ Date/ Year]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. The “Day” is automatically changed.  Page: 4-5 BU-2509 SERIES USER S MANUAL...

  • Page 65: Advanced

    This menu provides advanced configurations such as Trusted Computing, ACPI Settings, PCH-FW Configuration, F81866 Super IO Configuration, Hardware Monitor, F81866 Watchdog, CPU Configuration, SATA Configuration, Network Stack Configuration and USB Configuration. Advanced Screen  Page: 4-6 BU-2509 SERIES USER S MANUAL...
  • Page 66 F81866 Watchdog Sub-Menu F81866 Watchdog Parameters. CPU Configuration Sub-Menu CPU Configuration Parameters. SATA Configuration Sub-Menu SATA Device Options Settings. Network Stack Sub-Menu Network Stack Settings. Configuration USB Configuration Sub-Menu USB Configuration Parameters.  Page: 4-7 BU-2509 SERIES USER S MANUAL...
  • Page 67 Enables or Disables BIOS support for security Support - Enabled device. O.S will not show security Device. TCG EFI protocol and INT1A interface will not be available. Security Device No changeable Security Device Information. Status options  Page: 4-8 BU-2509 SERIES USER S MANUAL...
  • Page 68 SUSPEND button is pressed. Lock Legacy - Disabled Enables or Disables Lock of Legacy Resources - Enabled Resources. S3 Video Repost - Disabled Enables or Disables S3 Video Repost. - Enabled  Page: 4-9 BU-2509 SERIES USER S MANUAL...
  • Page 69 ME FW Version No changeable options Displays the ME Firmware Version. ME Firmware No changeable options Displays the ME Firmware Mode. Mode ME Firmware No changeable options Displays the ME Firmware Type. Type  Page: 4-10 BU-2509 SERIES USER S MANUAL...
  • Page 70 F81866 Super IO Configuration Screen BIOS Setting Options Description/Purpose Serial Port 1 Sub-menu Sets parameters of Serial Port 1 (COMA). Configuration Serial Port 2 Sub-menu Sets parameters of Serial Port 2 (COMB).  Page: 4-11 BU-2509 SERIES USER S MANUAL...
  • Page 71 Sets parameters of Serial Port 5 (COME). Configuration Serial Port 6 Sub-menu Sets parameters of Serial Port 6 (COMF). Configuration Menu Path Advanced > F81866 Super IO Configuration > Serial Port 1 Configuration Serial Port 1 Configuration Screen  Page: 4-12 BU-2509 SERIES USER S MANUAL...
  • Page 72 Serial Port 1. - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Menu Path Advanced > F81866 Super IO Configuration > Serial Port 2 Configuration Serial Port 2 Configuration Screen  Page: 4-13 BU-2509 SERIES USER S MANUAL...
  • Page 73 Serial Port 2. - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; Menu Path Advanced > F81866 Super IO Configuration > Serial Port 3 Configuration Serial Port 3 Configuration Screen  Page: 4-14 BU-2509 SERIES USER S MANUAL...
  • Page 74 Serial Port 3. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Menu Path Advanced > F81866 Super IO Configuration > Serial Port 4 Configuration Serial Port 4 Configuration Screen  Page: 4-15 BU-2509 SERIES USER S MANUAL...
  • Page 75 Serial Port 4. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Menu Path Advanced > F81866 Super IO Configuration > Serial Port 5 Configuration Serial Port 5 Configuration Screen  Page: 4-16 BU-2509 SERIES USER S MANUAL...
  • Page 76 Serial Port 5. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Menu Path Advanced > F81866 Super IO Configuration > Serial Port 6 Configuration Serial Port 6 Configuration Screen  Page: 4-17 BU-2509 SERIES USER S MANUAL...
  • Page 77 - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; Device Mode - Disables IR1 function Enables or Disables IR - Enables IR1 function, active pulse 1.6uS Mode function. - Enables IR1 function, active pulse 3/16 bit time  Page: 4-18 BU-2509 SERIES USER S MANUAL...
  • Page 78 Displays the processor's temperature. System Temperature No changeable options Displays the system's temperature. CPU Fan Speed No changeable options Displays CPU Fan speed. System Fan1 Speed No changeable options Displays System Fan 1 speed  Page: 4-19 BU-2509 SERIES USER S MANUAL...
  • Page 79 Displays the voltage level of VCC3V in VCC3V No changeable options supply. Displays the voltage level of VSB3V in VSB3V No changeable options supply. Displays the voltage level of VSB5V in VSB5V No changeable options supply.  Page: 4-20 BU-2509 SERIES USER S MANUAL...
  • Page 80 - Auto Duty-Cycle Mode fan 1. Manual Duty Mode - Numeric (from 1 to 100) Manual mode fan control. Users can write the expected duty cycle (PWM fan type) from 1 to 100.  Page: 4-21 BU-2509 SERIES USER S MANUAL...
  • Page 81 Selects 1s (second) or 60s (minute) as Watchdog timer unit - 60s the time unit of Watchdog timer. Sets the timeout for Watchdog timer. Count for Timer Numeric (from 1 to 255) (Max. value: 255 seconds or minutes)  Page: 4-22 BU-2509 SERIES USER S MANUAL...
  • Page 82 Processor Cores No changeable options Displays the number of cores of the processor. Hyper Threading No changeable options Reports if Intel Hyper-Threading Technology Technology is supported by the processor. Hyper Threading is Intel’s  Page: 4-23 BU-2509 SERIES USER S MANUAL...
  • Page 83 - 1 to n (depends on CPU) processor package. Hardware Prefetcher - Disabled Turns on/off the MLC streamer - Enabled prefetcher. Adjacent Cache Line - Disabled Turns on/off prefetching of adjacent Prefetch - Enabled cache lines.  Page: 4-24 BU-2509 SERIES USER S MANUAL...
  • Page 84 Enabling Intel(R) Speed Shift Technology - Enabled Technology will expose the CPPC v2 interface to allow for hardware controlled P-states. Intel(R) SpeedStep(tm) - Disabled Allows more than two frequency - Enabled ranges to be supported.  Page: 4-25 BU-2509 SERIES USER S MANUAL...
  • Page 85 SATA controller is enabled. The following screen indicates the functions available when the SATA controller is enabled and the AHCI mode is selected. SATA Configuration Screen  Page: 4-26 BU-2509 SERIES USER S MANUAL...
  • Page 86 1, the PCH starts a COMRESET initialization sequence to the device. SATA Device Type - Hard Disk Drive Identifies the SATA port is - Solid State Drive connected to Solid State Drive or Hard Disk Drive.  Page: 4-27 BU-2509 SERIES USER S MANUAL...
  • Page 87 A PXE-enabled workstation connects its NIC to the LAN via a jumper, which keeps the workstation connected to the network even when the power is turned off. Network Stack Configuration Screen  Page: 4-28 BU-2509 SERIES USER S MANUAL...
  • Page 88 Number of seconds to wait for PXE boot to time abort after the Esc key is pressed. Media detect Numeric (from 1 to 50) Number of times that the media presence count will be checked.  Page: 4-29 BU-2509 SERIES USER S MANUAL...
  • Page 89 - Disabled Enables/Disables USB mass storage Support - Enabled driver support. Port 60/64 Emulation - Disabled This should be enabled for the complete - Enabled USB keyboard legacy support for non-USB- aware OSes.  Page: 4-30 BU-2509 SERIES USER S MANUAL...
  • Page 90 Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Device power-up delay Numeric The time range for power-up delay is from 1 in seconds (from 1 to 40) to 40 seconds in one-second increment.  Page: 4-31 BU-2509 SERIES USER S MANUAL...

  • Page 91: Chipset

    This menu allows users to configure advanced Chipset settings such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Sub-menu System Agent (SA) parameters. Configuration PCH-IO Configuration Sub-menu PCH parameters.  Page: 4-32 BU-2509 SERIES USER S MANUAL...
  • Page 92 Intel's Virtualization Technology (VT) roadmap by providing hardware assists for virtualization solution, and helps end users improve security and reliability of the systems and also improves performance of I/O devices in virtualized environment.  Page: 4-33 BU-2509 SERIES USER S MANUAL...
  • Page 93 VT-d Enables or Disables VT-d function. - Enabled Graphics Configures Graphics configurations. Sub-menu Configuration PEG Port Sub-menu PEG Port Configuration Configuration (PCI_E1) Memory Displays the DRAM information on the Sub-menu Configuration platform.  Page: 4-34 BU-2509 SERIES USER S MANUAL...
  • Page 94 Displays the IGFX VBIOS version. Version Primary Display - Auto Selects IGFX, PEG or PCI Graphics device - IGFX as the Primary Display or selects SG for - PEG Switchable Gfx. - PCIE  Page: 4-35 BU-2509 SERIES USER S MANUAL...
  • Page 95 The LCD Control allows users to select the primary and secondary display device. LCD Control Screen BIOS Setting Options Description/Purpose Primary IGFX - VGA Selects Primary Display device. Boot Display - EDP - LVDS  Page: 4-36 BU-2509 SERIES USER S MANUAL...
  • Page 96 Configuration (PCI_E1) The PEG Port Configuration allows users to display the PEG status, enable Root Port and configure the maximum link speed and width, control ASPM support, etc. PEG Port Configuration Screen  Page: 4-37 BU-2509 SERIES USER S MANUAL...
  • Page 97 PEG is not the currently - ASPM L0s active device. - ASPM L1 - ASPM L0sL1 Detect Non- - Disable Detects Non-Compliance PCI Express Compliance - Enable Device in PEG. Device  Page: 4-38 BU-2509 SERIES USER S MANUAL...
  • Page 98 Displays the Frequency of Memory. Frequency Total Memory No changeable options Displays the total system memory. No changeable options Displays the Memory Voltage (mV). DIMM#1 No changeable options Displays the size of DIMM#1.  Page: 4-39 BU-2509 SERIES USER S MANUAL...
  • Page 99 This usually needs to be greater than or equal to the sum of the previous three latencies (tRAS = tCL + tRCD + tRP).  Page: 4-40 BU-2509 SERIES USER S MANUAL...
  • Page 100 Intel PCH SKU No changeable options Displays the Intel PCH SKU Name. Name Intel PCH Rev ID No changeable options Displays the Intel PCH Revision ID. PCI Express Sub-menu PCI Express Configuration settings. Configuration  Page: 4-41 BU-2509 SERIES USER S MANUAL...
  • Page 101 Chipset > PCH-IO Configuration > PCI Express Configuration The PCI Express Configuration allows users to configure the settings for PCI Express Root Port 1, 7, 9 and Mini-PCI Express Root Port 1. PCI Express Configuration Screen  Page: 4-42 BU-2509 SERIES USER S MANUAL...
  • Page 102 Configures PCI Express Root Port 7 settings. PCI Express Root Port 9 (PCI_E2) Sub-menu Configures PCI Express Root Port 9 settings. Mini-PCI Express Root Port 1 Sub-menu Configures Mini-PCI Express Root Port 1 settings.  Page: 4-43 BU-2509 SERIES USER S MANUAL...
  • Page 103 Management) Level. The option - L1 allows users to set the lower power - L0sL1 mode that activates when the bus is - Auto not being used. Force L0s – Force all links to L0s  Page: 4-44 BU-2509 SERIES USER S MANUAL...
  • Page 104 The PCI Express Root Port 7 (PCI_E3) function allows users to enable/disable PCI Express Root Port 7, select the PCIe port’s speed, configure ASPM support and detect the non-compliance device. PCI Express Root Port 7 Configuration Screen  Page: 4-45 BU-2509 SERIES USER S MANUAL...
  • Page 105 Disable – Disables ASPM Detect Non-Compliance - Disabled Detects a Non-Compliance PCI Express Device - Enabled device that is connected to the PCI Express port. If enabled, it will take more time during POST.  Page: 4-46 BU-2509 SERIES USER S MANUAL...
  • Page 106 - Disabled Sets the ASPM (Active-State Power - L0s Management) Level. The option allows - L1 users to set the lower power mode that - L0sL1 activates when the bus is not being  Page: 4-47 BU-2509 SERIES USER S MANUAL...
  • Page 107 The Mini-PCI Express Root Port 1 function allows users to enable/disable Mini-PCI Express Root Port 1, select the PCIe port’s speed, configure ASPM support and detect the non-compliance device. Mini-PCI Express Root Port 1 Configuration Screen  Page: 4-48 BU-2509 SERIES USER S MANUAL...
  • Page 108 Detect Non-Compliance - Disabled Detects a Non-Compliance PCI Express Device - Enabled device that is connected to the Mini PCI Express root port. If enabled, it will take more time during POST.  Page: 4-49 BU-2509 SERIES USER S MANUAL...

  • Page 109: Security

    Heed that a user password does not provide access to most of the features in the Setup utility. Security Screen BIOS Setting Options Description/Purpose Administrator Password can be 3-20 Specifies the administrator password. Password alphanumeric characters.  Page: 4-50 BU-2509 SERIES USER S MANUAL...

  • Page 110: Boot

    BBS option priorities, and setting CSM (Compatibility Support Module) configuration parameters to support legacy BIOS operation systems, various VGA, bootable devices and add-on devices for achieving better compatibility. Boot Screen  Page: 4-51 BU-2509 SERIES USER S MANUAL...
  • Page 111 Hard Drive BBS Sub-Menu Defines the boot order for all the hard drives Priorities connected to the system, e.g. SATA, USB drive. CSM Configuration Sub-Menu CSM configuration: Enable/Disable, Option ROM execution settings, etc.  Page: 4-52 BU-2509 SERIES USER S MANUAL...
  • Page 112 <↑> or <↓ > arrow keys to select the device. Another way is to press <+> or <-> to move the selected device up/down in the priority list.  Page: 4-53 BU-2509 SERIES USER S MANUAL...
  • Page 113 CSM Configuration Screen BIOS Setting Options Description/Purpose CSM Support - Disabled Enables or Disables CSM Support. - Enabled CSM16 Module No changeable options Displays the CSM 16 Module version.  Page: 4-54 BU-2509 SERIES USER S MANUAL...
  • Page 114 Controls the execution of UEFI and Legacy - UEFI Video Option ROM. - Legacy Other PCI - Do not launch Determines Option ROM execution policy devices - UEFI for devices other than Network, Storage or - Legacy Video.  Page: 4-55 BU-2509 SERIES USER S MANUAL...

  • Page 115: Save & Exit

    No changeable Resets the system without saving any Reset options changes configured in BIOS settings. No changeable Saves the changes done so far to any of Save Changes options the setup options.  Page: 4-56 BU-2509 SERIES USER S MANUAL...
  • Page 116 Save as User Defaults options Defaults. No changeable Restores the User Defaults to all the BIOS Restore User Defaults options settings. Forces to boot the system from selected Boot Override - [Drive(s)] [drive(s)].  Page: 4-57 BU-2509 SERIES USER S MANUAL...
  • Page 117 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. The following sections are included:  Block Diagram  Interrupt Map  DMA Channel Map  I/O Map  Memory Map  Watchdog Timer Configuration  Flash BIOS Update Page: A-1...

  • Page 118: Appendix A Technical Summary

    ALC 888S-VD2 High Definition Codec SPI FLASH ROM LOW PIN COUNT 80 PORT for Debug COM 1/3/4/5/6 RS232 FINTEK Connector COM3/4 support 5V/12V LPC SIO HW monitor COM 2 F81866AD-I RS232/422/485 PS/2 Keyboard Mouse  Page: A-2 BU-2509 USER S MANUAL...

  • Page 119: Interrupt Map

    Microsoft ACPI-Compliant System IRQ 86 Microsoft ACPI-Compliant System IRQ 87 Microsoft ACPI-Compliant System IRQ 88 Microsoft ACPI-Compliant System IRQ 89 Microsoft ACPI-Compliant System IRQ 90 Microsoft ACPI-Compliant System IRQ 91 Microsoft ACPI-Compliant System  Page: A-3 BU-2509 USER S MANUAL...
  • Page 120 Microsoft ACPI-Compliant System IRQ 112 Microsoft ACPI-Compliant System IRQ 113 Microsoft ACPI-Compliant System IRQ 114 Microsoft ACPI-Compliant System IRQ 115 Microsoft ACPI-Compliant System IRQ 116 Microsoft ACPI-Compliant System IRQ 117 Microsoft ACPI-Compliant System  Page: A-4 BU-2509 USER S MANUAL...
  • Page 121 Microsoft ACPI-Compliant System IRQ 138 Microsoft ACPI-Compliant System IRQ 139 Microsoft ACPI-Compliant System IRQ 140 Microsoft ACPI-Compliant System IRQ 141 Microsoft ACPI-Compliant System IRQ 142 Microsoft ACPI-Compliant System IRQ 143 Microsoft ACPI-Compliant System  Page: A-5 BU-2509 USER S MANUAL...
  • Page 122 Microsoft ACPI-Compliant System IRQ 164 Microsoft ACPI-Compliant System IRQ 165 Microsoft ACPI-Compliant System IRQ 166 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168 Microsoft ACPI-Compliant System IRQ 169 Microsoft ACPI-Compliant System  Page: A-6 BU-2509 USER S MANUAL...
  • Page 123 Microsoft ACPI-Compliant System IRQ 189 Microsoft ACPI-Compliant System IRQ 190 Microsoft ACPI-Compliant System ® Intel Ethernet Connection (2) I219-V 4294967294 ® Intel USB 3.0 eXtensible Host Controller 4294967292 ® Intel HD Graphics 510 4294967293  Page: A-7 BU-2509 USER S MANUAL...

  • Page 124: Memory Map

    Motherboard resources 0xFED18000-0xFED18FFF Motherboard resources 0xFED19000-0xFED19FFF Motherboard resources 0xE0000000-0xEFFFFFFF Motherboard resources 0xFED20000-0xFED3FFFF Motherboard resources 0xFED90000-0xFED93FFF Motherboard resources 0xFED45000-0xFED8FFFF Motherboard resources 0xFF000000-0xFFFFFFFF Motherboard resources ® 0xFF000000-0xFFFFFFFF Intel 82802 Firmware Hub Device 0xFEE00000-0xFEEFFFFF Motherboard resources  Page: A-8 BU-2509 USER S MANUAL...
  • Page 125 0xFE410000-0xFE7FFFFF Motherboard resources ® 0xDE000000-0xDEFFFFFF Intel HD Graphics 510 ® 0xC0000000-0xCFFFFFFF Intel HD Graphics 510 ® Intel 100 Series/C230 Series Chipset Family 0xDF04E000-0xDF04EFFF Thermal subsystem - A131 ® 0xFE40F000-0xFE40FFFF Intel Management Engine Interface  Page: A-9 BU-2509 USER S MANUAL...

  • Page 126: I/O Map

    0x00000A00-0x00000A0F Motherboard resources 0x00000A10-0x00000A1F Motherboard resources 0x00000A20-0x00000A2F Motherboard resources 0x0000002E-0x0000002F Motherboard resources 0x0000004E-0x0000004F Motherboard resources 0x00000061-0x00000061 Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000065-0x00000065 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000092-0x00000092 Motherboard resources  Page: A-10 BU-2509 USER S MANUAL...
  • Page 127 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller 0x00000038-0x00000039 Programmable interrupt controller 0x0000003C-0x0000003D Programmable interrupt controller 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller  Page: A-11 BU-2509 USER S MANUAL...
  • Page 128 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer  Page: A-12 BU-2509 USER S MANUAL...

  • Page 129: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode.  Page: A-13 BU-2509 USER S MANUAL...
  • Page 130 ;-------------------------- Set second as counting unit -------------------------------------- al, 0f5h dx, al al, dx al, 30h dx, al ; ---------------- Set timeout interval as 30seconds and start counting ----------- al, 0f6h dx, al  Page: A-14 BU-2509 USER S MANUAL...
  • Page 131 Appendix A Technical Summary al, 1Eh dx, al ;---------------------------------Exit the extended function mode ---------------------- al, 0aah dx, al  Page: A-15 BU-2509 USER S MANUAL...

  • Page 132: Flash Bios Update

    (4) Select [Boot] menu. (5) Select [Hard Drive BBS Priorities], set the USB bootable device to be the boot device. (6) Press <F4> key to save the configuration and exit the BIOS setup menu.  Page: A-16 BU-2509 USER S MANUAL...
  • Page 133 The recommended options for BIOS ROM update consist of following parameters: program main BIOS image program Boot Block program NVRAM don’t check ROM ID /REBOOT: Reboot after programming  Page: A-17 BU-2509 USER S MANUAL...
  • Page 134 After BIOS update procedures is completed, the following messages will be shown: Restart the system and boot up with the new BIOS configurations. The BIO Update is completed after the system is restarted.  Page: A-18 BU-2509 USER S MANUAL...
  • Page 135 Appendix A Technical Summary Reboot the system and verify if the BIOS version shown on the initialization screen has been updated.  Page: A-19 BU-2509 USER S MANUAL...

Table of Contents
