KneeRover PRO User Manual page 3

Step 3: Install Steering Column
The steering column will be in a folded position when unpacking. When
facing the front of the KneeRover
push the security pin in the clamp to the left to allow the column to lock
into place. Raise the clamp lever upward and tighten by turning it
clockwise. Finally, push clamp lever down firmly to secure the steering
column. Reverse these steps when needing to lower steering column for
transport.
Step 4: Install Knee Platform & Inflate Tires
The knee platform is designed to be used with either the right or left leg.
Insert the knee platform post into the receptacle tube and set the knee
platform at your desired height for use by inserting the locking pin
through the aligned holes. Finally, tighten the clamp to secure the knee
platform in place.
The pneumatic tires come partially inflated. It is important to inflate all
three tires to the correct pressure (a maximum of 40 psi) the same way
you inflate a bike tire. Be careful not to over inflate the tires.
Clamp
scooter, raise the steering column and
®
To Lower Steering Column:
1) Lift Clamp Lever & Pull
Toward You
2) Push Clamp Lever to Left
to Release Security Pin
Locking Pin
Step 5: Brake Operation & Adjustment
To engage the brake, squeeze the brake lever on handle bar. Your
KneeRover scooter comes equipped with a brake lock / parking brake.
®
Simply squeeze brake handle firmly and press the button to engage the
lock. To release the lock, squeeze the brake handle again.
If needed, the brake can be adjusted to avoid brake pad(s) from rubbing
a spinning back wheel with a disengaged brake. Use the provided
smaller allen wrench to make adjustments. Approaching the scooter
from behind you can loosen or tighten the brake cable by loosening the
top right bolt, adjusting brake cable, and re-tightening bolt.
Brake Lock
Ongoing Maintenance
With routine use, nuts and bolts on the steering column, tie rod steering
mechanism, and brake assembly can become loose. To ensure safe
continuous operation of this KneeRover
periodically inspect the scooter for loose nuts and bolts and re-tighten
as appropriate. Also, check the tire pressure routinely to ensure that
tires are properly inflated up to 40 psi maximum. Be careful not to over
inflate the tires. Please visit kneerover.com/pages/kneerover-
maintenance-videos for additional support in maintaining your
KneeRover..
Top Right Bolt –
Use Allen
Wrench
scooter, it is important to
®
